TOYOTA SIENNA 2007 Service Repair Manual

PREPARATION – 2GR-FE LUBRICATIONPP–17
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent
Toyota Genuine Seal Packing Black, Three Bond 1207B or Equivalent
Toyota Genuine Seal Packing 1282B, Three Bond 1282B or
Equivalent

PREPARATION – U151E AUTOMATIC TRANSAXLEPP–25
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm
09031-00030 Pin Punch
09031-00040 Pin Punch .
09040-00011 Hexagon Wrench Set
(09043-20050) Socket Hexagon Wrench 5
(09043-20060) Socket Hexagon Wrench 6
(09043-20100) Socket Hexagon Wrench 10
09070-20010 Moulding Remover
09090-04020 Engine Sling Device
09216-00021 Belt Tension Gauge
09905-00012 Snap Ring No.1 Expander

PP–26PREPARATION – U151E AUTOMATIC TRANSAXLE
PP
09905-00013 Snap Ring Pliers

PREPARATION – U151E AUTOMATIC TRANSAXLEPP–27
PP
EQUIPMENT
Straight edge
Torque wrench
Vernier calipers
Dial indicator with magnetic base
Slide calipers
Chain block
Feeler gauge
Plastic hammer
Press
Seal packing 2403, THREE BOND 2403 or equivalent
Seal packing 2430, THREE BOND 2430 or equivalent

PP–28PREPARATION – U151E AUTOMATIC TRANSAXLE
PP
LUBRICANT
Automatic transaxle fluid
Dry fill
Drain and refill8.8 liter (9.3 US qts, 7.7 lmp.qts)
3.5 liter (3.7 US qts, 3.1 lmp.qts)ATF type T-IV

PREPARATION – U151E AUTOMATIC TRANSAXLEPP–29
PP
SSM
08833-00070 Adhesive 1324,
THREE BOND 1324 or equivalent
08833-00080 Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalent

PREPARATION – U151F AUTOMATIC TRANSAXLEPP–33
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm
09031-00030 Pin Punch
09031-00040 Pin Punch .
09040-00011 Hexagon Wrench Set
(09043-20050) Socket Hexagon Wrench 5
(09043-20060) Socket Hexagon Wrench 6
(09043-20100) Socket Hexagon Wrench 10
09070-20010 Moulding Remover
09090-04020 Engine Sling Device
09216-00021 Belt Tension Gauge
09905-00012 Snap Ring No.1 Expander

PP–34PREPARATION – U151F AUTOMATIC TRANSAXLE
PP
09905-00013 Snap Ring Pliers

PREPARATION – U151F AUTOMATIC TRANSAXLEPP–35
PP
EQUIPMENT
Straight edge
Torque wrench
Vernier calipers
Dial indicator with magnetic base
Slide calipers
Chain block
Feeler gauge
Plastic hammer
Press
Seal packing 2403, THREE BOND 2403 or equivalent
Seal packing 2430, THREE BOND 2430 or equivalent

PP–36PREPARATION – U151F AUTOMATIC TRANSAXLE
PP
LUBRICANT
Automatic transaxle fluid
Dry fill
Drain and refill9.0 liter (9.5 US qts, 7.9 lmp.qts)
3.6 liter (3.8 US qts, 3.2 lmp.qts)ATF type T-IV
