TOYOTA SIENNA 2007 Service Repair Manual

PREPARATION – U151F AUTOMATIC TRANSAXLEPP–37
PP
SSM
08833-00070 Adhesive 1324,
THREE BOND 1324 or equivalent
08833-00080 Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalent

PREPARATION – TRANSFERPP–37
PP
RECOMMENDED TOOLS
09040-00011 Hexagon Wrench Set
(09043-20060) Socket Hexagon Wrench 6
09904-00010 Expander Set
(09904-00020) No. 1 Claw
09905-00013 Snap Ring Pliers
(09904-00090) Claw Set

PP–38PREPARATION – TRANSFER
PP
EQUIPMENT
To r q u e w r e n c h
Dial gauge with magnetic base
V-block
Universal engine lifter

PREPARATION – TRANSFERPP–39
PP
LUBRICANT
Item Capacity Classification
Transfer oil 0.9 litters (0.95 US qts, 0.71 lmp.qts) Hypoid gear oil SAE 90 (GL-5)

PP–40PREPARATION – TRANSFER
PP
SSM
08826-00090 Seal Packing 1281,
THREE BOND 1281 or equivalent
(FIPG)

PP–40PREPARATION – PROPELLER SHAFT
PP
EQUIPMENT
To r q u e w r e n c h
Dial gauge with magnetic base
V-block

PP–42PREPARATION – DRIVE SHAFT
PP
RECOMMENDED TOOLS
HINT:
Torx is a registered trademark of Textron Inc.
09011-12301 Socket Wrench 30 mm
09040-00011 Hexagon Wrench Set
09042-00010 Torx Socket T30
(09043-20060) Socket Hexagon Wrench 6
09904-00010 Expander Set
(09904-00050) No. 4 Claw
09905-00012 Snap Ring No.1 Expander
09905-00013 Snap Ring Pliers

PREPARATION – DRIVE SHAFTPP–43
PP
EQUIPMENT
Torque wrench
Dial gauge with magnetic base

PREPARATION – BRAKEPP–57
PP
EQUIPMENT
Slide calipers
Torque wrench

PP–58PREPARATION – BRAKE
PP
LUBRICANT
Item Capacity Classification
Brake fluid - SAE J1703 or FMVSS No. 116 DOT3
