YAMAHA YZ426F 2000  Betriebsanleitungen (in German) SPEC
CHEMINEMENT DES CABLES
KABELFÜHRUNG
ðDas TPS-Kabel mit einem Einweg-Kabelbinder
unter der Steckverbindung befestigen.
ñDen Vergaser-Entlüftungsschlauch und den
Auslaufschutzschlauch zwischen

Page 132 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) 2 - 23
SPEC
ôFit the brake hose into the guide on
the protector.
çFasten the ignition coil lead (in the
sub wire harness) on the upper
inside of the frame and cut off the tie
end.
óPass the ignitio

Page 133 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) SPEC
CHEMINEMENT DES CABLES
KABELFÜHRUNG
ôDen Bremsschlauch in die Führung am Protek-
tor einsetzen.
çDas Zündspulenkabel (im Nebenkabelbaum) mit
einem Einweg-Kabelbinder an der Oberseite
des Rah

Page 134 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) 2 - 24
SPECCABLE ROUTING DIAGRAM
1Clamp
2Ignition coil
3High tension cord
4CDI unit
5CDI unit band
6Throttle cable (pull)
7Throttle cable (return)
8Radiator (left)
9Radiator breather hose
0Radiator (r

Page 135 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) SPEC
CHEMINEMENT DES CABLES
KABELFÜHRUNG
1Kabelbinder
2Zündspule
3Hochspannungskabel
4CDI-Zündbox
5CDI-Zündbox-Befestigungsband
6Drosselklappenzug (Ziehen)
7Drosselklappenzug (Rückführen)
8Kühl

Page 136 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) 2 - 25
SPECCABLE ROUTING DIAGRAM
1Throttle cable
2Clamp
3Decompression cable
4Clutch cable
5Brake hose
6Hose guide
7“ENGINE STOP” button leadFasten the “ENGINE STOP” button lead to the handleb

Page 137 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German) SPEC
CHEMINEMENT DES CABLES
KABELFÜHRUNG
1Gaszug
2Kabelbinder
3Dekompressionszug
4Kupplungszug
5Bremsschlauch
6Kabelführung
7Motorstoppschalter-Kabel
Das Motorstoppschalter-Kabel mit mehrf. ver-
wen

Page 138 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German)
3 - 1
INSP
ADJ

MAINTENANCE INTERVALS
EC300000
REGULAR INSPECTION AND ADJUSTMENTS
EC310022
MAINTENANCE INTERVALS
The following schedule is intended as a general guide to maintenance and lubric

Page 139 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German)
3 - 2
INSP
ADJ

MAINTENANCE INTERVALS
SHIFT FORK, SHIFT CAM, GUIDE BAR
Inspect
c
Inspect wear
ROTOR NUT
Retighten
cc
MUFFLER
Inspect
Clean
Replace
cc
cc
* Whichever comes first
CRANK
Inspect

Page 140 of 608

YAMAHA YZ426F 2000  Betriebsanleitungen (in German)
3 - 3
INSP
ADJ

MAINTENANCE INTERVALS
FRONT FORK OIL SEAL AND DUST
SEAL
Clean and lube
cc
Lithium base grease
REAR SHOCK ABSORBER
Inspect and adjust
Lube and retighten
c
cc
c
Lithium base gre
