ACURA CSX 2006 Service Repair Manual

(#'
/)
Transaxle
...............................................................
...............................................................
Clutch . 12-1
Manual Transmission
.................... ....................
5-speed Manual Transmission . 13-1
....................
....................
6-speed Manual Transmission . 13-69
.................................
.................................
Automatic Transmission . 14-1
..................................................
..................................................
Driveline/Axle . 16-1
08/08/21 14:42:18 61SNR030_120_0001
ProCarManuals.com
DYNOMITE -2009-

(#'
/)
08/08/21 14:42:18 61SNR030_120_0002
ProCarManuals.com
DYNOMITE -2009-

(#'

/)
Clutch
Clutch
.............................................................................................
.............................
.........................................................
.......................
........................
........................
.............................
.............................
........................................... ...............................
....................................................
................................................................
.............................
.............................
.........................................................
.......................
........................
........................
.............................
.............................
........................................... ...............................
....................................................
Special Tools . 12-2
Component Location Index
(5-speed Manual Transmission) . 12-3
(6-speed Manual Transmission) . 12-4
System Description (6-speed Manual Transmission) . 12-5
Clutch Hydraulic System Bleeding . 12-7
Clutch Pedal, Clutch Pedal Position Switch, and Clutch Interlock Switch Adjustment . 12-8
Clutch Pedal Assembly Replacement . 12-10
Clutch Master Cylinder Replacement . 12-11
Slave Cylinder Replacement (5-speed Manual Transmission) . 12-14
(6-speed Manual Transmission) . 12-15
Clutch Hose Replacement . 12-17
Clutch Pedal Cover Replacement . 12-18
Clutch Replacement . 12-19
08/08/21 14:42:18 61SNR030_120_0003
ProCarManuals.com
DYNOMITE -2009-









(#'

%)Ref. No. Tool Number Description Qty
12-2
Clutch
Special Tools
07JAF-PM7011A
Clutch Alignment Disc 1
07LAB-PV00100 Ring Gear Holder 1
07ZAF-PR8A100 Clutch Alignment Shaft 1
07936-KC10500 Bearing Remover Shaft 1
07741-0010201 Slide Hammer 1
07746-0010800 Bearing Driver Attachment, 22 x 24 mm 1
07749-0010000 Driver Handle, 15 x 135L 1
07936-3710100 Remover Handle 1
08/08/21 14:42:19 61SNR030_120_0004
ProCarManuals.com
DYNOMITE -2009-

Î
(#'

) 5-speed Manual Transmission
12-3
Component Location Index
O-RINGLOCK PIN
FLYWHEEL
O-RING
ROLL PINS
CLUTCH DISC CLUTCH HOSE
CLUTCH LINE CLUTCH INTERLOCK
SWITCH
CLUTCH MASTER
CYLINDER SEAL
CLUTCH PEDAL
POSITION SWITCH
CLUTCH LINE
RELEASE FORK
CLUTCH ASSIST
SPRING
RELEASE BEARING CLUTCH PEDAL
CLUTCH PEDAL ASSEMBLY
CLUTCH MASTER
CYLINDER
RETAINING CLIP
RESERVOIR HOSE
SLAVE CYLINDER
CRANKSHAFT
PILOT BUSHING
CLUTCH
RESERVOIR
CLUTCH HOSE CLIPS PRESSURE PLATE
CLEVIS PIN
Replace.
Inspection,page 12-21
Replacement, page 12-21
Replace.
Replace.
Inspection and Removal,page 12-20
Installation, page 12-23 Replacement,
page 12-17 Test, page 4-8
Adjustment,
page 12-8
Replace.
Test, page 4-50
Adjustment,page 12-8
Removal, page 12-24
Inspection, page 12-24
Installation, page 12-24 Adjustment,
page 12-8
Replacement, page 12-10
Replacement, page 12-11
Replace.
Replacement, page 12-14
Inspection,
page 12-22
Replacement,
page 12-22
Replace. Inspection
and Removal,
page 12-19
Installation,
page 12-23
08/08/21 14:42:24 61SNR030_120_0005
ProCarManuals.com
DYNOMITE -2009-

Î
(#'

)
6-speed Manual Transmission
12-4Clutch
Component Location Index (cont’d)
O-RING
FLYWHEEL
O-RING
ROLL PINS
CLUTCH DISC CLUTCH HOSE
CLUTCH LINE
CLUTCH LINE
RELEASE FORK
CLEVIS
PIN
CRANKSHAFT
PILOT BUSHING CLUTCH PEDAL
CLUTCH MASTER
CYLINDER RESERVOIR HOSE
SLAVE CYLINDER CLUTCH HOSE CLIPSLOCK PIN
CLUTCH INTERLOCK
SWITCH
CLUTCH MASTER
CYLINDER SEAL
CLUTCH PEDAL
POSITION SWITCH
CLUTCH PEDAL ASSEMBLY
RETAINING CLIP CLUTCH ASSIST
SPRING
RELEASE BEARING CLUTCH PEDAL COVER
CLUTCH
RESERVOIR
PRESSURE PLATE
Replace.
Inspection,page 12-21
Replacement, page 12-21
Replace.
Replace.
Inspection and Removal,page 12-20
Installation, page 12-23 Replacement, page 12-17
Inspection,
page 12-22
Replacement, page 12-22 Adjustment, page 12-8
Replacement, page 12-11
Replacement, page 12-15
Replace. Test, page 4-8
Adjustment,
page 12-8
Replace.
Test, page 4-50
Adjustment,page 12-8
Replacement, page 12-10
Replace.
Removal, page 12-24
Inspection, page 12-24
Installation, page 12-24Replacement, page 12-18
Inspectionand Removal,
page 12-19
Installation, page 12-23
08/08/21 14:42:29 61SNR030_120_0006
ProCarManuals.com
DYNOMITE -2009-

Î
(#'

)
Delay Orifice Mechanism (6-speed Manual Transmission)
Function
12-5
System Description
DELAY ORIFICE MECHANISM
SLAVE CYLINDER PISTONPISTON CYLINDER
The delay orifice mechanism improves clutch operation by delaying the slave cylinder release speed when the clutch
pedal is suddenly released. The delay orifice mechanism is built into the slave cylinder.
(cont’d)
08/08/21 14:42:29 61SNR030_120_0007
ProCarManuals.com
DYNOMITE -2009-

Î
ÎFluid Flow Operation
12-6Clutch
System Description (cont’d)
FILTER PART of FLOW (Blocked)
ONE-WAY VALVE
ORIFICE PART of FLOW
FLUID from
MASTER CYLINDER FLOW to PISTON CYLINDER
FILTER PART of FLOW (Blocked)
FLUID to
MASTER CYLINDER ONE-WAY VALVE
ORIFICE PART of FLOW
FLUID from PISTON CYLINDER
When the clutch pedal is pressed, the fluid pressure from the master cylinder moves the one-way valve in the
direction shown in the illustration. The fluid flows through two passages: the orifice part and the filter part. It then
flows out to the piston cylinder to release the pressure plate and clutch disc joint.
When the clutch pedal is released, the fluid pressure from the piston cylinder moves the one-way valve in the direction
shown in the illustration. The one-way valve blocks the filter-part passage and delays the clutch release speed by
returning the fluid to the master cylinder through only the orifice-part passage.
08/08/21 14:42:29 61SNR030_120_0008
ProCarManuals.com
DYNOMITE -2009-




(#'

!) 5-speed manual transmission
6-speed manual transmission
12-7
Clutch Hydraulic System Bleeding
B
A A
8N·m
(0.8 kgf·m,
5.8 lbf·ft)
A
8N·m
(0.8 kgf·m,
5.8 lbf·ft)
NOTE:  Do not reuse the drained fluid. Always use Acura DOT 3 Brake Fluid from an unopened container.
Using a non-Acura brake fluid can cause corrosion
and shorten the life of the system.
 Do not mix different brands of brake fluid; they may not be compatible.
 Make sure the brake fluid is not contaminated with dirt or other foreign matter.
 Do not spill brake fluid on the vehicle; it may damage the paint or plastic. If brake fluid does contact the
paint or plastic, wash it off immediately with water.
 If may be necessary to limit the movement of the release fork with a block of wood to remove all the air
from the system.
 Use fender covers to avoid damaging painted surfaces.
1. Make sure the brake fluid level in the clutch reservoir (A) is at the MAX (upper) l evel line (B).2. Attach the one end of a clear tube to the bleeder
screw (A), and put the other end into a container.
Loosen the bleeder screw to allow air to escape
from the system.
3. Make sure there is an adequate supply of fluid in the reservoir, then slowly push the clutch pedal all
the way down. Before releasing the pedal, have an
assistant temporarily tighten the bleeder screw.
Loosen the bleeder screw, and push the pedal
down again. Repeat this step until no more bubbles
appear at the clear tube.
NOTE: Make sure the fluid level on the reservoir
does not go below MIN.
4. Tighten the bleeder screw securely.
5. Refill the brake fluid in the reservoir to the MAX (upper) l evel line.
08/08/21 14:42:30 61SNR030_120_0009
ProCarManuals.com
DYNOMITE -2009-

Î
(#'



") µµ
F Clutch Pedal Height:
Except Type S model: 159.3 mm (6.27 in.)
Type S model: 161.3 mm (6.35 in.)
G Clutch Pedal Stroke: 130 140 mm (5.12 5.51 in.)
12-8Clutch
Clutch Pedal, Clutch Pedal Position Switch, and Clutch Interlock Switch
Adjustment
B
A F
G
A
D E
B
C
NOTE:  For a cruise control problem, check the clutch pedal position switch (see page 4-50).
 For an engine cranking problem, check the clutch interlock switch (see page 4-8).
 The clutch is self-adjusting to compensate for wear.
 If there is no clearance between the master cylinder piston and the pushrod, the release bearing will be
held against the diaphragm spring, which can result
in clutch slippage or other clutch problems.
1. Lift up the carpet (A). At the insulator cutout, measure pedal height from the right side of the
pedal pad (B). 2. Loosen the clutch pedal position switch locknut (A),
and back off the clutch pedal position switch (B)
until it no longer touches the clutch pedal (C).
3. Loosen the clutch pushrod locknut (D), and turn the pushrod (E) in or out to get the specified height (F)
and stroke (G) at the clutch pedal. If adjusting the
pushrod causes the clutch pedal to contact the
clutch pedal position switch, back off the switch
further.
