Page 21 of 90
20
BLUE&ME
™
in conjunction with Instant Nav
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 20
Page 22 of 90
21
BLUE&ME
™
in conjunction with Instant Nav
To get familiar with all the functions and
the capabilities of the multimedia player,
refer to the MULTIMEDIA PLAYER
FUNCTIONS chapter.
If you have any difficulties using the
multimedia player, consult the “PROBLEM
SOLVING - MULTIMEDIA PLAYER”
chapter. To start playing digital audio saved on
your USB device, proceed as follows:
– Copy the tracks on your USB device
(the system recognizes the following for-
mats .wma, .mp3, .wav, .aacfor the audio
files and .wpl and .m3ufor the playlists).
– For USB devices without a USB lead,
simply connect the device to the USB port
in the car (directly or with the help of an
extension) (see fig. 1).
– For USB devices with a lead, connect
one end to your USB device and the oth-
er to the USB port in the car (see fig. 1).– Turn the ignition key to MAR. The sys-
tem will automatically start playing your
digital tracks (if the AUTO PLAY option
is activated), selecting them from a library
that is created when the UBS device is
connected.
– After the system has created a library
of your digital audio files, you can select
and listen to tracks, albums, artists and
playlists interacting manually or vocally. If
your USB device contains a lot of files it
may take a few minutes to create the li-
brary.
– iPod player - see dedicated paragraph.
– You can decide whether the playing of
the audio files should start automatically
when the USB device is inserted or
whether it should only start when you give
the command.
M M
U U
L L
T T
I I
M M
E E
D D
I I
A A
P P
L L
A A
Y Y
E E
R R
Q Q
U U
I I
C C
K K
G G
U U
I I
D D
E E
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 21
Page 23 of 90
22
BLUE&ME
™
in conjunction with Instant Nav
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 22
Page 24 of 90
23
BLUE&ME
™
in conjunction with Instant Nav
CONTROLS ON THE STEERING
WHEEL
The controls on the steering wheel (see
fig.1) are designed to use the hands free
function, activate the voice recognition,
the multimedia player functions or to se-
lect an option from the system Menu.
Other controls have different functions
depending on the system status at any giv-
en moment.
The function selected in response to
pressing a button in some cases depends
on how long the button is pressed (long
or short press).
DISPLAY AND CONTROLS ON
THE STEERING WHEEL.
Note
The instructions for using the system via
the manual controls are shown by the
symbol
?.INSTANT NAV CONTROLS
The
N/O/¯/˙butttons that activate
the Media Player mode are on the front of
the Instant Nav:
NOSelection of previous/next fold-
er/artist/genre/album depending on
the selection mode activated
¯˙Play previous/ next trackVOICE COMMANDS
It is possible to use voice commands
without the need to change your normal
driving position to be recognized by the
system. The microphone is in the correct
position for this purpose.
The words that are recognized by the
system are identified as “voice com-
mands”.
The hands free system recognizes and
responds to a predefined list of voice com-
mands. The list of available voice com-
mands depends on where you are in the
hands free system menu. The list of voice
commands available at any time can always
be accessed by pressing
‘and saying
“Help” or by saying “Help” after a system
message. The system also recognizes per-
sonalized voice command versions, such
as, for example, the names in your phone
list.
U U
S S
I I
N N
G G
T T
H H
E E
S S
Y Y
S S
T T
E E
M M
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 23
Page 25 of 90
24
BLUE&ME
™
in conjunction with Instant Nav
To use the voice commands with this
hands free system there is no need for any
learning stage for the system with your
voice.
To give the system a voice command,
press
‘and wait for the acoustic signal
that indicates that the voice recognition
system is activated; you can now give the
command in your normal voice, not too
quickly but without a break. When the
system recognizes the command, it will re-
spond or carry out an action.
The voice commands are organized in
three levels: 1
stlevel, 2ndlevel and 3rdlev-
el.
When a 1
stlevel valid* voice command is
given, the system is prepared to recognize
2
ndlevel voice commands; when a 2ndlev-
el voice command is given, the system is
activated to recognize 3
rdlevel voice com-
mands.
If the user gives a valid * 1
stlevel voice
command, the submenu for that command
remains activated until a voice command
that leads to another level is given or the
interaction is interrupted; the same rule is
valid for the lower levels (2 and 3).
For a list of all the available voice com-
mands, refer to the LIST OF AVAILABLE
VOICE COMMANDS chapter.
To listen to the last message given by the
system again, press
‘for more than 1
second or press
‘for a short while and
say “Repeat”.
The hands free system can provide in-
formation vocally.
A voice announcement is a voice mes-
sage proposed directly by the system. To
end a voice announcement, press ESCor
press
‘and say “Cancel”.
A voice interaction is an exchange of
communications/commands between the
hands free system and the user. To start
a voice interaction, press
‘and make a
command. To interrupt an interaction and
start a new interaction, press
‘at any
time during the interaction and give a
voice command.
To end an interaction, press ESC. You
will hear an acoustic signal that means that
the voice recognition has been deactivat-
ed.The help function can provide you, at any
time, with a list of commands available at
the level you are at. To use the help sys-
tem, say “Help”, listen to the list of com-
mands available and decide which com-
mand you want to give the system.
Adjust the volume to the level that is
best for you with the car moving. To
adjust the pre-set system volume, refer
to the description in the “EXTERNAL
AUDIO VOL function” paragraph in the
Instant Nav instruction manual. To tem-
porarily adjust the volume of the phone
call in profress, press +or –or adjust the
position of the Instant Nav control. The
volume will return to the original level at
the end of the call.
You can also press +of –to adjust the
volume of a voice announcement whilst
it is being given by the system.
Remember that to interrupt a voice an-
nouncement, you can press
‘at any time
during a voice interaction and give a new
voice command.
* Valid means that the voice command is part of the system vocabulary and therefore recognizable at a given level.
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 24
Page 26 of 90
25
BLUE&ME
™
in conjunction with Instant Nav
Notes
– The instructions for using the system
via the voice commands are shown by the
symbol
}.
– After having pressed
‘, if you do not
give a voice command within a few sec-
onds the system will ask you to give a
voice command. If you do not answer, the
voice recognition will be deactivated. This
also happens if you do not respond to a
question from the system. In such cases
you will hear an acoustic signal that means
that the voice recognition has been deac-
tivated.
– When the system does not manage to
recognize your voice command, it will give
you another chance to make a voice com-
mand. If you are not sure that the voice
command is correct, say “Help”. Use of voice recognition
The voice recognition system can some-
times make a mistake in recognizing a
voice command. To make sure that your
voice commands are always recognized,
stick to the following guide lines:
– After having pressed
‘, make the
voice command after the system has pro-
vided the acoustic signal that indicates that
the voice recognition is activated.
– After the system has asked a question,
wait for a second before giving the answer
to be sure that the voice recognition is ac-
tivated.
– If you want to make a command with-
out waiting for the system to finish its
message or question, you can press the
‘again briefly to interrupt the system
and give your command.
– Speak at a normal voice volume.
– Say the words clearly, not too quick-
ly but without a break.
– If possible, try and keep the noise in
the passenger compartment to a mini-
mum.– Before giving voice commands, ask
your companions not to talk. Since the
system recognizes words irrespective of
who is speaking, if several people are
speaking at the same time, the system
make recognize different words or addi-
tional words to those you have spoken.
– For optimum operation it is advisable
to close the sun roof if your car has one.
Notes
For countries where a mother tongue
version is not available, voice recognition
of commands and especially contacts in
the phone list may prove difficult. We ad-
vise adopting pronounciation that con-
forms to the language in the system.
To change the voice recognition lan-
guage, refer to a Fiat Dealership consult
the dedicated area in www.fiat.com.
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 25
Page 27 of 90
26
BLUE&ME
™
in conjunction with Instant Nav
DISPLAY
Various functions are shown on the con-
trol panel and the Instant Nav (see fig. 1).The control panel display shows various
types of information (fig. 2 and fig. 3):
– Information on the status of the mo-
bile phone connected via Bluetooth
®:
–
;this means that the system is con-
nected to a mobile phone with Blue-
tooth
®
– NO BLUETOOTH - indicates that the
connection with the mobile phone is in-
terrupted (versions with multifunction dis-
play)
– If there is no symbol
;this indicates
that the connection with the mobile
phone is interrupted (versions with re-
configurable multifunction display)
– The symbol
Ãindicates that the call
activated is the first one answered, this
symbol is only present in the case of call
waiting (versions with reconfigurable mul-
tifunction display).
– The symbol
Àindicates that the
call activated is the second one answered,
this symbol is only present in the case of
call waiting (versions with reconfigurable
multifunction display).–The
‰symbol means that a Tele-
phone Conference is activated (versions
with reconfigurable multifunction display).
– Name of the telephone operator ac-
tive on your mobile phone (if not available,
“- - - - - ” is displayed)
– Information relating to an SMS text
message having been received, the tele-
phone number or the contact name (if
stored in the directory) of the SMS mes-
sage sender.
– Information relating to the system
function activated or the menu option se-
lected (see figs. 2 and 3).
– The Instant Nav display will show the
following information relating to:
– the TEL function
– the incoming/outgoing calls (only if
the Privacy function is deactivated)
– the audio tracks
– the Multi Media Player settings.
For more information, see the de-
scription in the Instant Nav manual.
fig. 3F0L5402g
fig. 2F0L5401g
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 26
Page 28 of 90
27
BLUE&ME
™
in conjunction with Instant Nav
AUDIO
The system audio function (hands free,
multimedia player, voice announcements,
acoustic signals) is played via the audio sys-
tem installed on your car. For this reason
any Instant Nav audio source activated is
interrupted for the time required.
The audio volume can always be adjust-
ed using the Instant Nav controls. SYSTEM FUNCTIONS MENU
The system Main Menu shows the op-
tions in a list which is shown on the con-
trol panel multifunction display. The sys-
tem settings can be changed or the func-
tions activated using the available options.
Note
The settings menu can only be navigated
using the controls on the steering wheel
when the car is stationary.The Main Menu includes the following
options:
– LAST CALLS. - a list of recent calls,
made or received, can be viewed through
this submenu. This list is downloaded from
your mobile phone memory, udated when
the hands free is used or it is obtained
from both operations.
– DIRECTORY - this submenu allows
you to see the telephone numbers in your
phone list and to select one to make a call.
If your phone list contains a lot of names,
they will be grouped in alphabetic sub-
menus. The number of people within a
submenu depends on the number of
names in your phone directory.
– SMS TEXT message reader (Function
only available with compatible mobile
phones). This submenu allows you to read
the last SMS text message received, call
the sender of the SMS text message or
delete the last SMS text message received.
Up to 20 SMS text messages can be stored
in a dedicated list and listened to later on,
the sender called or they can be deleted.
It is also possible to choose the way of re-
ceiving notification of SMS text messages
received.
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 27
Page 29 of 90
28
BLUE&ME
™
in conjunction with Instant Nav
– M.M. PLAYER - this submenu makes it
possible to select digital audio tracks in the
library by folder, artist, genre, album or
playlist. This submenu can also be used to
access the multimedia player iPod settings
- see dedicated paragraph.
– SETTINGS - this submenu makes it
possible to manage the names in your
phone list, register a new device or access
the hands free system identification code.Launching the Main Menu
To activate the system Main Menu, press
ßafter which you can start to interact
with the system using the controls on the
steering wheel.
Navigation through menu options
To navigate through menu items, press
Qor Z.
When the names in the directory are
displayed, if the number of characters ex-
ceeds the maximum permitted, the name
will be shortened.
To select the option shown on the dis-
play, press OKor
ß.
To exit the item shown on the display or
a submenu, press ESC.INSTANT NAV FUNCTIONS
MENU
– M.M. PLAYER
Select the “M.M. PLAYER” source and
press MUSIC to access the information
screen, press the OK button to access the
Multi Media Player menu, select the de-
sired item turning the OK knob and press
again to confirm the selection.
–TEL
Press the TEL button to access the in-
formation screen, press the OK knob to
access the TEL menu, select the desired
item by turning the actual knob and press
it again to confirm the selectin.
For more information, see the de-
scription in the Instant Nav manual.
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 28
Page 30 of 90
29
BLUE&ME
™
in conjunction with Instant Nav
The system allows phone calls to be
made and received via your mobile phone
with Bluetooth
®using voice recognition
or the controls on the steering wheel.
You can call the names in your phone list
through voice controls by saying the name
and/or surname or you can call numbers
that are not listed by saying the digits of
the desired phone number or call back the
sender of an SMS text message received.
You can call the names in your phone list
using the controls on the steering wheel
or call up a list of calls that you have made
or received, selecting the desired name
from the Last calls or Directory submenu.
You can also answer incoming calls, call
back a number that is engaged, receive a
call notification, read an SMS text message
received or delete it.
If you have had difficulties in using the
telephone functions via the car’s hands
free system, consult the PROBLEM
SOLVING - HANDS FREE chapter. Notes
– Before you can make and receive calls
using the hands free system you must reg-
ister your mobile phone in the system.
SETTING FUNCTIONS - REGISTER-
ING YOUR MOBILE PHONE,
– To activate the car’s hands free sys-
tem the igntion key must be in the MAR
position.
– If you turn the ignition key to the
STOP position during a phone conversa-
tion you can continue the conversation for
another 15 minutes via the hands free sys-
tem.MAKING A CALL
You can make a call in one of the fol-
lowing ways:
– Call a name in the list
– Call a number using voice commands
– Call a number using the mobile phone
keypad
– Call a number in the call log
– Call the sender of an SMS text mes-
sage received
For further information, refer to the
SMS TEXT MESSAGE READER FUNC-
TIONS chapter - Management of SMS
messages.
H H
A A
N N
D D
S S
F F
R R
E E
E E
F F
U U
N N
C C
T T
I I
O O
N N
S S
603_97_160 CROMA_BLUE INSTANT NAV_GB_1ed 5-05-2009 15:51 Pagina 29
