IMPORTANT The quick demisting/de-
frosting function will stay on for approxi-
mately 3 minutes after the engine coolant
temperature is warm enough to ensure
rapid window demisting.
When the function is on, the LED on the
rear window demister button will light up
and the message FULL AUTOwill go
out on the display.
You may only adjust the fan speed and
switch the rear window demister off man-
ually when this function is running.
To restore running operations before this
function was activated, press either but-
ton B, air recirculation button G, com -
pressor button For button AUTO A.Switching the system off (E)
Press Eto switch the climate control sys-
tem off. The display will go out as a con-
sequence.
The following climate control conditions
will be established when the system is off:
display off;
temperature not shown;
air recirculation on,
passenger com-
partm ent isolated from the outside
(recirculation LED on);
climate control compressor off;
fan off.Press AUTOto switch the automatic cli-
mate control system back on.





50
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 50LINEA Owner HAND BOOK RHD.pdf 508/21/09 2:16:06 PM8/21/09 2:16:06 PM

EXTERNAL LIGHTS
Th e left-hand stalk fig. 36operates
most of the external lights.
The external lights can only be switched
on when the ignition key is at MAR.
The instrument panel and the various
dashboard controls will come on with the
external lights.
LIGHTS OFF
Knurled ring turned to symbol O.
SIDELIGHTS - TAILLIGHTS
Turn the knurled ring to .
The warning light on the instrument
cluster will come on at the same time.
DIPPED BEAM HEADLIGHTS
Turn the knurled ring to .
The warning light on the instrument
cluster will come on at the same time.MAIN BEAM HEADLIGHTS
When the knurled ring is at , pull the
lever towards the steering wheel (2
ndun-
stable position).
The warning light 1on the instrument
cluster will come on at the same time.
To turn the main beams off,
pull again the
lever towards the steering wheel (dipped
beams will turn on again).FLASHING THE HEADLIGHTS
Pull the stalk towards the steering wheel
(1
stunstable position) regardless of the po-
sition of the knurled ring. The warning
light on the instrument cluster will
come on at the same time.
fig. 36F0R0037m
51
SAFETY
DEVICES CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 51LINEA Owner HAND BOOK RHD.pdf 518/21/09 2:16:06 PM8/21/09 2:16:06 PM

DIRECTION INDICATORS fig. 37
Push the stalk to (stable) position:
up (position 1): right-hand indicator;
down (position 2): left-hand indicator;
Warning light or will blink on the in-
strument panel.
Indicators are switched off automatically
when the steering wheel is straightened.
If you want the indicator to flash briefly to
show that you are about to change lane,
move the stalk up or down without click-
ing into position (unstable position). When
released the stalk will return to its home
position.“FOLLOW ME HOME” DEVICE
This function allows the illumination of the
space in front of the car for a preset pe-
riod of time.
Activation
With the ignition key at STOPor re-
moved, pull the left-hand stalk towards the
steering wheel within 2 minutes from
when the engine is turned off.
At each single movement of the stalk, the
lights will remain on for an extra 30 sec-
onds up to a maximum of 210 seconds;
then the lights are switched off automati-
cally. Warning light on the instrument pan-
el will light up and the corresponding mes-
sage will appear on the display
(see
“Warning lights and messages”) as long as
the function is on.
The warning light will
go out when the lever is operate and stay
on until the function is automatically de-
activated. Time for which the lights stay
on can only be increased by operating the
lever.
Deactivation
Keep the stalk pulled towards the steer-
ing wheel for more than 2 seconds.
fig. 37F0R0038m


52
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 52LINEA Owner HAND BOOK RHD.pdf 528/21/09 2:16:06 PM8/21/09 2:16:06 PM

WINDSCREEN WASHING
The right stalk fig. 38controls front wind-
screen wiper/washer operation.
WINDSCREEN WASHER/
WIPER
The device can only work when the igni-
tion key is at MAR.
The stalk ring nut can be moved to four
different positions:
Owindscreen wiper off;
intermittent;
continuous slow;
continuous fast.
Move the lever to position A(unstable)
to limit operation for the time for which
the lever is held in this position. The lever
will return to position and the wiper will
be automatically stopped when released.Do not use the windscreen
wiper to remove layers of
snow or ice from the wind-
screen. In such conditions, the
windscreen wiper may be subjected to
excessive stress and the motor protec-
tion which prevents operation for a few
seconds may trip. If operation is not re-
stored, even after turning the key and
restarting the engine, go to a Fiat
Dealership.
With the ring in position the wind-
screen wiper will automatically adapt to
the speed of the car.
IMPORTANT Replace wiper blades as
specified in section “Car maintenance”.
fig. 38F0R0039m
“Smart washing” function
Pull the stalk towards the steering wheel
(unstable position) to operate the wind-
screen washer.
Keeping the stalk pulled for more than half
a second, with just one movement it is
possible to operate the washer jet and the
wiper at the same time.
The wiper stops working three strokes af-
ter releasing the stalk.
A further stroke after 6 seconds
com-
pletes the wiping operation.
53
SAFETY
DEVICES CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 53LINEA Owner HAND BOOK RHD.pdf 538/21/09 2:16:06 PM8/21/09 2:16:06 PM

54
CEILING LIGHTS
FRONT CEILING WITH SPOT
LIGHTS fig.39/a AND WITH
DIFFUSED LIGHTIING LED
(where provided) fig.39/b
Switch Aturn on/off these lights.
With switch Ain central position, lights
Cand Dwill turn on/off when opening/
closing the front doors.
With switch Apressed on the left side,
lights Cand Dwill always stay off. With
switch Apressed on the right side, lights
Cand Dwill always stay on.
Light turning on/off is gradual.
Switch Bperforms the spot function; with
light off, it will turn on:
light Cif pressed on the left side;
light Dif pressed on the right side.
IMPORTANT Before getting out of the
car, make sure the switch is at central po-
sition: lights off with doors closed in or-
der to avoid draining the battery.
In any case, if the switch is left inadver-
tently to the on position, the lights will
turn off automatically 15 minutes after
turning the engine off.
fig. 39/aF0R0043m
REAR CEILING LIGHT WITH
MOVABLE LENS
The light will turn on/off by pressing the
movable lens rightwards or leftwards as
shown in fig. 40.
fig. 39/bF0R0240m
fig. 40F0R0042m
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS


LINEA Owner HAND BOOK RHD.pdf 54LINEA Owner HAND BOOK RHD.pdf 548/21/09 2:16:06 PM8/21/09 2:16:06 PM

55
Ceiling light timing
On certain versions to facilitate getting
in/out of the car at night or with poor
lighting, 2 different timed switching
on
modes have been provided.
LIGHT TIMING WHEN GETTING INTO THE CAR
Lights will turn on as follows:
for about 10 seconds when
opening
front doors;
for about 3 minutes when opening one
of the side doors;
for about 10 seconds when closing the
doors.
Timing will stop when turning the ignition
key to MAR.
LIGHT TIMING WHEN GETTING OUT
OF THE CAR
After removing the key from the ignition
switch, the ceiling lights will turn on as fol-
lows:
within 2 minutes from turning the en-
gine off for about 10 seconds;
when opening one of the side doors for
about 3 minutes;
when closing one of the doors
for
about 10 seconds.
Timing will stop automatically when lock-
ing the doors.
SAFETY
DEVICES CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS




LINEA Owner HAND BOOK RHD.pdf 55LINEA Owner HAND BOOK RHD.pdf 558/21/09 2:16:06 PM8/21/09 2:16:06 PM

56
COURTESY LIGHTS
(where provided) fig. 42
Lights Bby the side of the courtesy
mir-
ror will light up when cover Aon the sun
visor on driver’s or passenger’s side is
raised with the key at MAR. The lights al-
lows to use the courtesy mirror also
in
poor conditions of light.
IMPORTANT The lights may only be op-
erated for 15 minutes when the key is
turned to stop STOP. They will be au-
tomatically switched off after this to pro-
tect the battery charge.
fig. 41F0R0044mfig. 42
B
B
A
F0R0216m
BOOT LIGHT (where provided)
fig. 41
For versions fitted with boot light, it will
turn on automatically when opening the
tailgate and it will turn off at closing.
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 56LINEA Owner HAND BOOK RHD.pdf 568/21/09 2:16:06 PM8/21/09 2:16:06 PM

57
CONTROLS
HAZARD LIGHTS fig. 43
They turn on by pressing switch A, r e -
gardless of the position of the ignition key.
When the device is on, the switch is flash-
ing and warning lights e on the pan-
el come blink.
Press the switch again to turn the lights
off.
The use of hazard lights is governed by the
Highway Code of the country you are in.
Keep to the rules.FRONT FOG LIGHTS
(where provided) fig. 44
To turn front fog lights on, press button
, to activate these lights it is necessary
to have the side/taillights switched on.
The warning light on the instrument
cluster will come on at the same time.
Press the button again to turn the lights off.
The use of fog lights is governed by the
Highway Code of the country you are in.
Keep to the rules.
REAR FOG LIGHTS fig. 45
Press button to turn these lights on
providing the dipped beam headlights or
the front fog lights (where provided) are
switched on.
The warning light on the instrument
panel will light up.
Either press the button again or switch the
dipped beam headlights and/or fog lights
(where provided) off.
The use of fog lights is governed by the
Highway Code of the country you are in.
Keep to the rules.
fig. 43F0R0047m
fig. 44F0R0048mfig. 45F0R0049m
SAFETY
DEVICES CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 57LINEA Owner HAND BOOK RHD.pdf 578/21/09 2:16:07 PM8/21/09 2:16:07 PM

58
DOOR LOCK fig. 47
To open: pull lever A.
To close: close the door and press lever
A. Also the rear doors will be locked in
this way (centralised door locking system).
Warning light will light up with the cor-
responding message on the multifunctional
display (see chapter “ Warning lights and
Messages”).
fig. 46F0R0035m
HEATED REAR WINDOW
(where provided) fig. 46
Press button Ato switch the device on.
The device will be switched off automati-
cally after approximately 20 minutes. PARKING LIGHTS
These lights can only be turned on with ig-
nition key at STOPor removed, by mov-
ing the left stalk knurled ring first to Oand
then to position or .
The warning light
on the instrument
panel will come on at the same time.
fig. 47F0R0023m
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 58LINEA Owner HAND BOOK RHD.pdf 588/21/09 2:16:07 PM8/21/09 2:16:07 PM

59
Door unlocking in the event
of a crash
If the fuel cut-off switch trips following an
accident, the doors will be automatically
unlocked to let you leave the car and the
ceiling lights will be switched on at the
same time. The doors can always be
opened from the inside of the car by
means of the specific levers.
Proceed as follows if no fuel leakage is
found and and the car is in condition to be
driven to rearm the fuel cut-off switch.FUEL CUT-OFF SWITCH
The car is fitted with a safety switch that
in the event of a crash comes into opera-
tion by cutting off fuel and turning off the
engine as a consequence.
This device therefore prevents fuel
leaks
due to fuel piping breaking.
IMPORTANT After the accident,
re-
member to remove the electronic key
from the ignition device to prevent drain-
ing the battery.The message “FPS on” will appear on the
digital display when the switch trips. The
mess ag e “F ue l cu t of f swi tch , see ha nd-
book” will appear on the multifunctional
display.
If, after a crash, you smell fu-
el or see leaks from the fuel
system, do not reset the switch to
avoid fire risk.
WARNING
If the centralised door lock-
ing system was operated
from inside the car and the fuel cut-
off switch did not manage to auto-
matically release the doors, it will not
be possible to access the passenger
compartment from the outside after
an accident. The possibility of open-
ing the doors from the outside de-
pends on the conditions of the doors
themselves after the accident: if may
not be possible to open a damaged
door. In this case, try to open the oth-
er doors of the car.
WARNING
SAFETY
DEVICES CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 59LINEA Owner HAND BOOK RHD.pdf 598/21/09 2:16:07 PM8/21/09 2:16:07 PM
