FORD MUSTANG 2003 Workshop Manual

37. Remove the power steering hose bracket.
38. Disconnect the supercharger degas hose.
39. Remove the bolts and the supercharger degas bottle.
40. Disconnect the radiator lower hose. Klj . 9 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

41. Disconnect the supercharger coolant hoses.
42. Disconnect the cooling fan electrical connector.
43. Remove the LH cooling fan shroud bolt.
44. Remove the RH cooling fan shroud bolt, and remove the fan, motor and shroud as an
assembly. Klj . 10 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

45. Disconnect the power steering hose.
46. Remove the power steering bracket bolt.
47. Remove the power steering hose from the grommet.
48. Remove the bolts and the battery tray. Klj . 11 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

49. Remove the auxiliary crankshaft pulley. For additional information, refer to
Crankshaft Pulley —
Auxiliary in this section.
50. Remove the clutch. For additional information, refer to Section 308 - 01 .
51. Remove the transmission wiring harness. 1. Remove the RH oxygen sensor connector from the bracket.
2. Disconnect the transmission wiring connector and remove the harness.
52. NOTE: LH is shown, RH is similar.
Remove the right and left exhaust manifold flange nuts, and position the exhaust manifold
aside.
53. Drain the engine oil. zInstall the drain plug when finished. Klj . 12 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

54. Remove the nut and the wiring harness bracket.
55. Disconnect the oil pressure sender electrical connector.
56. Disconnect the generator electrical connector.
57. Remove the generator B + nut and disconnect the B + cable. Klj . 13 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

58. Remove the nut and the engine ground cable.
59. Disconnect the hose from the oil filter adapter.
60. Disconnect and remove the lower hose from the radiator.
61. Remove the ground strap bolt. Klj . 14 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

62. Remove the degas bottle support bracket.
63.
NOTE: RH side shown, LH side similar.
Remove the two engine mount nuts.
64. Lower the vehicle.
65. Remove the two screws and position the clutch cable aside. Klj . 15 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

66.
NOTE: RH is shown LH is similar.
Remove the right and left ignition coil covers.
67. Install the special tool.
68. Install the special tool.
69. Attach the special tool to a floor crane and the engine, and remove the engine from the vehicle. Klj . 16 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Klj . 17 ba
172003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

DISASSEMBLY
Engine
SECTION 303-
01C: Engine — Cobra 4.6L (4V) 2003 Mustang Workshop Manual Special Tool(s)
Slide Hammer
100-
001 (T50T-100- A) Remover, Crankshaft Vibration
Damper
303-
009 (T58P-6316- D) Holding Tool, Crankshaft
303-
448 (T93P-6303- A) Installer, Connecting Rod
303-
442 (T93P-6136- A) Remover, Crankshaft Rear Oil
Seal
303-
519 (T95P-6701- EH) Remover, Crankshaft Rear Oil
Slinger
303-
514 (T95P-6701- AH) Compressor, Valve Spring
(Intake)
303-
452 (T93P-6565- AR) Compressor, Valve Spring
(Exhaust) Klj . 1 ba
