FORD MUSTANG 2003 Workshop Manual

Disconnect the battery ground cable and wait at least one minute. For additional information,
refer to
Section 414 - 01 .
2. Remove the steering column opening lower finish panel. 1. Remove the screws.
2. Pull out to release the retaining clips and remove the steering column opening lower finish panel.
3. Remove the steering column opening lower reinforcement. 1. Remove the bolts.
2. Remove the steering column opening lower reinforcement.
4. Pushing in on the release tab, disconnect the clockspring electrical connector at the base of the steering column.
5. Attach the restraint system diagnostic tool to the vehicle harness side of the clockspring electrical connector. Klj . 2 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

6. Open the glove compartment, push in on the tabs and open the glove compartment door to its
fullest extent.
7. Remove the right hand A/C register duct. zRemove the two screws retaining the duct to the A/C register.
z Separate the A/C duct at the air plenum and remove the duct.
8. Disconnect the passenger air bag module.
9. Attach the restraint system diagnostic tool to the vehicle harness side of the passenger air bag electrical connector. Klj . 3 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

10. Connect the battery ground cable. For additional information, refer to
Section 414 - 01 .
11. With the restraint system diagnostic tools installed at all deployable devices, prove out the supplemental restraint system (SRS). For additional information, refer to Section 501 - 20B .
12. Disconnect the battery ground cable and wait at least one minute. For additional information, refer to Section 414 - 01 .
Reactivation WARNING: To reduce the risk of serious personal injury, read and follow all warnings,
cautions, and notes at the beginning of the deactivation procedure.
1. Disconnect the battery ground cable and wait at least one minute. For additional information, refer to Section 414 - 01 .
2. Remove the restraint system diagnostic tool from the passenger air bag module electrical connector.
3. Connect the passenger air bag module electrical connector. Klj . 4 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

4. Install the right hand A/C register duct.
zConnect the A/C duct at the air plenum.
z Install the duct at the A/C register and install the two screws.
5. Close the glove compartment.
6. Remove the restraint system diagnostic tool from the clockspring electrical connector.
7. Connect the clockspring electrical connector at the base of the steering column.
8. Install the steering column opening lower reinforcement. 1. Position the steering column opening lower reinforcement.
2. Install the bolts.
9. Install the steering column opening lower finish panel. 1. Align the steering column opening lower finish panel and push in, seating the retaining
clips.
2. Install the screws. Klj . 5 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

10. Connect the battery ground cable. For additional information, refer to
Section 414 - 01 .
11. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
With all the restraint system diagnostic tools removed, prove out the supplemental restraint
system (SRS). For additional information, refer to Section 501 - 20B . Klj . 6 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Ignition Switch Lock Cylinder —
Functional
Removal and Installation 1. Disconnect the battery ground cable. For additional information, refer to Section 414 - 01 .
2. Remove the ignition switch lock cylinder (11582). 1. Insert the ignition key and turn to the RUN position.
2. Using a 1/8- inch drift, press the ignition switch lock cylinder release pin through the
access hole while pulling out the ignition switch lock cylinder.
3. To install, reverse the removal procedure. zVerify ignition switch lock cylinder operation.
SECTION 211-
04: Steering Column 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Klj . 2 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Ignition Switch Lock Cylinder —
Non-Functional
Removal and Installation 1. NOTE: Make sure the front wheels are in the straight- ahead position.
Disconnect the battery ground cable (14301) and wait at least one minute to allow the depletion
of the restraint system backup power supply. For additional information, refer to Section 414 -
01 .
2. WARNING: To avoid the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the deactivation procedure.
Deactivate the supplemental restraint system (SRS). For additional information, refer to
Supplemental Restraint System (SRS) Deactivation and Reactivation in this section.
3. WARNING: To reduce the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the steering wheel removal and installation
procedure.
Remove the steering wheel assembly. For additional information, refer to Wheel in this section.
4. Twist off the cap from the ignition switch cylinder.
5. NOTE: The lock cylinder is repaired by discarding the inoperative lock cylinder and building a
new lock cylinder using the appropriate lock repair package (F85Z-11582- AA). The lock repair
package includes a detailed instruction sheet to build the new lock cylinder to the current key
code of the vehicle.
SECTION 211-
04: Steering Column 2003 Mustang Workshop Manual Klj . 1 ba
32003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Remove the ignition switch lock cylinder.
zUse a 1/8- inch diameter drill bit to drill out the lock cylinder retaining pin.
z Use a 3/8- inch drill bit to drill down the middle of the ignition lock key slot until the ignition
switch lock cylinder breaks loose.
z Remove and discard the ignition switch lock cylinder and clean the drill shavings from the
steering column.
6. Remove the bearing retainer.
7. Remove the bearing and gear. zThoroughly clean all drill shavings from the steering column and inspect it for damage.
8. To install, reverse the removal procedure. zInstall a new ignition switch lock cylinder.
z Verify ignition switch lock cylinder operation. Klj . 2 ba
32003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

9.
WARNING: To avoid the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the reactivation procedure.
Reactivate the supplemental restraint system (SRS). For additional information, refer to
Supplemental Restraint System (SRS) Deactivation and Reactivation in this section. Klj . 3 ba
