HONDA PRELUDE 1992 Service Manual

Controls Near the Steering Wheel
Instrument Panel Brightness
The dial

on the dashboard to the
left of the instrument panel con- trols the brightness of the instru-
ment panel lights. Turn the dial to
adjust the brightness.
To reduce glare at night, the fuel and temperature gauges dim when
you turn on the parking lights or
headlights. You then adjust their
brightness when you adjust the instrument panel brightness. Turn the dial up as far as it will go to
return the fuel and temperature
gauges to their daytime brightness.

Turn Signals

Signal a turn or lane change with
this lever. Push down on the lever
to signal a left turn, and up to
signal a right turn. If you push it up
or down all the way, the turn signal
continues to blink even when you
release the lever. It shuts off auto-
matically as you complete the turn. To signal a lane change, push
lightly on the turn signal lever in
the proper direction and hold it.
The lever will return to the center position as soon as you release it.

Instruments and Controls

TURN SIGNAL LEVERProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Windshield Wipers
The right lever controls the wind-
shield wipers and washers. The
rotary switch at the end of the
lever has three positions:

INT — intermittent

LO — low speed

HI — high speed

In intermittent, the wipers operate

every few seconds. In low speed

and high speed, the wipers run

continuously.
To operate the wipers in mist mode,

push the control lever down. The

wipers run at high speed until you
release the lever. This gives you a
quick way to clear the windshield. Windshield Washers
To clean the windshield, pull back
on the wiper control lever. The
washers spray until you release the
lever.
The wipers run at low speed while
you're pulling the lever, then
complete one more sweep of the
windshield after you release it.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Steering Wheel Adjustment

You can adjust the steering wheel height to suit your preference. Do
this before you begin driving.
1. Adjust the seat so you are acomfortable distance from the
pedals.

2. The lever to tilt the steering
wheel is under the steering column to the left. Push this
lever all the way down.

3. Move the steering wheel up or
down to the desired position.

Position the wheel so you can see

all the instrument panel gauges
and warning lights. Push the
lever up to lock the steering
wheel in that position.
4. Make sure you have securely locked the steering wheel inplace by trying to move it up and

down.

Instruments an d
Controls

Adjusting the steering wheel
position while driving may
cause you to lose control of
the car and be seriously injured in a crash.
Adjust the steering wheel only
when the car is stopped.ProCarManuals.comMain Menu Table of Contents s t

Steering Wheel Controls

Cruise Control

Cruise control
allows you to
maintain a set speed above 25 mph
(40 km/h) without keeping your
foot on the accelerator pedal. It is
for cruising on straight, open
highways. It is not recommended
for conditions such as city driving,
winding roads, slippery roads,
heavy rain, or bad weather. You should have full control of the car
under those conditions. The cruise control, as it operates,
moves the accelerator pedal. You
can damage your car's accelerator
mechanism by resting your foot
under the pedal and blocking the movement. Using the Cruise Control

1. Push in the Cruise Control

Master Switch to the left of the
steering column. The indicator in
the switch will light.

2. Accelerate to the
desired
cruising speed above 25 mph (40

km/h).

Instruments an d
Controls

Improper use of the cruise con-
trol can lead to a crash.
Use the cruise control only
when traveling on open high-
ways in good weather.
NOTICEProCarManuals.comMain Menu Table of Contents s t

Steering Wheel Controls

3. Press and hold the SET/decel button on the steering wheel
until the CRUISE CONTROL
light on the instrument panelcomes on. This shows the system
is now activated.
The set speed may vary slightly,
particularly on
hills.
Changing the Set Speed

You can increase the set cruising speed in either of two ways:
Press and hold the accel/
RESUME button. The car will

accelerate slowly. When you

reach the desired cruising speed,

release the button.

Push on the accelerator pedal.
Accelerate to the desired
cruising speed and press the SET

/decel button.
Yo
u can decrease the set cruising
speed in either of two ways: Press and hold the SET/decel
button. The car will decelerate. Release the button when you
reach the desired speed.
Tap the brake or clutch pedal
lightly with your foot. The
CRUISE CONTROL light on the
instrument panel will go out.
When the car slows to the desired speed, press the SET/
decel button. The car will then
maintain the desired speed.
CONTINUED

Instruments and Controls

accel/

RESUME

SET/decelProCarManuals.comMain Menu Table of Contents s t

Steering Wheel Controls

Even with the cruise control turned
on, you can still use the accelerator pedal to speed up for passing. After
completing the pass, take your foot
off the accelerator pedal. The car
will return to the set cruising speed.
Resting your foot on the brake or
clutch pedal will cause the cruise
control to cancel.
Turning off the Cruise Control

Either of these actions take the car

out of cruise control:
Tap the brake or, if manual trans-mission, clutch pedal.
Press the Cruise Control Master

Switch.
When you tap the brake or clutch
pedal, the CRUISE CONTROL
light on the instrument panel will
go out and the car will begin to
slow down. You can use the acceler-
ator pedal in the normal way. The
system retains the previously-set
cruising speed. To return to that
speed, accelerate to above 25 mph
(40 km/h) and then press the
RESUME/accel button until the
CRUISE CONTROL light comes on. The car will accelerate to the

same cruising speed as before.

Pressing the Cruise Control Master
Switch turns the system completely
off. This erases the previous
cruising speed from memory. To
use the system again, you must set
the system up as explained in Using the Cruise Control.
Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Steering Wheel Controls, Keys and Locks

Horn

Press either of the buttons on the
steering wheel spokes to sound the

horn.
Key
s

Your
car comes with two kinds of

keys: a master key and a valet key.

The master key fits all locks on
your car: Ignition
Doors

Trunk
Trunk release handle
Rear seat trunk access
Center console compartment
The valet key only works the
ignition and the door locks. You
can keep the trunk, trunk release
handle, center console compart-
ment and rear seat trunk access
locked when you leave your car and valet key at a parking facility.
Each key has a number stamped in
one side. You will need this number
if you have to get a lost key re-
placed. Record this number and
keep it in a safe place.

Instruments and Controls

HORN
VALET KEYMASTER KEY
ProCarManuals.comMain Menu Table of Contents s t

Keys and Locks

Ignition Switch

The ignition switch is on the right
side of the steering column. It has

four positions: LOCK (0), ACCES-
SORY (I), ON(II), and START (III).
LOCK (0) — You can insert or
remove the key only in this position.
When you turn the key from LOCK
to ACCESSORY, you may have to
turn the steering wheel to release
the anti-theft lock. To switch from
ACCESSORY to LOCK, you must push the key in slightly as you turn
it. If your car has an automatic
transmission, it must also be in
Park. The anti-theft lock will lock
the steering column when you
remove the key. ACCESSORY (I) — In this

position, you can operate the audio

system and cigarette lighter.
ON (II) — This is the normal key

position when driving. All features

and accessories on the car are
usable. Several of the lights on the instrument panel come on as a test
when you turn the ignition switch
from ACCESSORY to ON (see
page 31).

START (III) — Use this position
only to start the engine. The switch
returns to ON when you let go of
the key.
You will hear a reminder beeper if
you open either front door with the
key in the LOCK or ACCESSORY position. Remove the key to turn it
off.
Instruments and Controls
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control.
Remove the key from the igni-
tion switch only when parked.ProCarManuals.comMain Menu Table of Contents s t

Keys and Locks

Door Locks
Each door has a lock tab next to
the inside door handle. Push the tab
in to lock the door and pull it out to
unlock.
To lock the passenger's door when
getting out of the car, push the lock
tab in and close the door. To lock
the driver's door, pull the door
handle and push the lock tab in.
Release the handle then close the

door.
The doors can also be locked and

unlocked from the outside with the

key. Power Door Locks

Available only on Si and Si 4WS models in the U.S., and SR and SR 4WS
models in Canada

Each door has a master door lock
switch. Either switch locks and
unlocks both doors. Push the
switch down to lock and up to
unlock.

CONTINUED

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Keys and Locks

Both doors lock when you push in
the lock tab on the driver's door, or
lock the driver's door from the outside with the key. Only the
driver's door unlocks when you use
the key or lock tab. To unlock the
passenger's door, use the master
door lock switch or pull out the
lock tab on passenger's door.

Lockout Prevention

If you forget and leave the key in
the ignition switch, Lockout
Prevention will not allow you to
lock the driver's door. With either
door open and the key in the
ignition, the master door lock
switches are disabled. If you try to
lock the driver's door by pushing in
the lock tab, the tabs on both doors immediately pop up.
Trunk

You can open the trunk in two
ways:
Pull the trunk release handle to
the left of the driver's seat. Use the master key to open the
trunk lock. The valet key does
not work in this lock.
To close the trunk, press down on

the trunk lid.

See page 106 fo
r cargo loading and
weight limit
information. Keep the
trunk lid closed at all times while
driving to avoid damaging the lid
and getting exhaust gas in the
interior. See Carbon Monoxide
Hazard on page 25.

Instruments and Controls
MASTER KEY

TRUNK RELEASE
HANDLEProCarManuals.comMain Menu Table of Contents s t
