Hyundai Azera 2005 Owner's Manual

1FEATURES OF YOUR HYUNDAI
94
oON In the "ON" position, the light stays on at all times.
CAUTION:
Do not leave this button pressed foran extended period of time when the vehicle is not running.
!
!
SPECTACLE CASE
B491A03O-GAT (If Installed) The spectacle case is located on the front overhead console. Push the end of the cover to open thespectacle case. WARNING:
o Do not keep objects such as sharp or unsuitable things inside thespectacle case. Such objects can be thrown out in the event of a sudden stop or an accident, pos-sibly injuring the passengers in the vehicle.
o Do not open the spectacle case while the vehicle is moving. Therear view mirror of the vehicle can be blocked by an open spectaclecase.
HTG2182

1
FEATURES OF YOUR HYUNDAI
95
B500A01TG-GAT ACCESSORY BOX
The accessory box may be opened by pushing at its top edge (Type A) or pushing the knob downward (Type B). It is used for storing small articles. B500A01TG
B500B01NF-GAT Illuminated Glove Box Opening the glove box will automati- cally turn on the light when the multi- function switch is turned to the firstposition.
NOTE: Information about use of the trunk lid control button located in the glove box is beginning on the trunk lidsection.
B541A01TG
Type A
B500A02TG
Type B
!
STORAGE BOX
B500A01TG-AAT GLOVE BOX
WARNING:
To avoid the possibility of injury in case of an accident or a suddenstop, the glove box door should be kept closed when the car is in mo- tion.
o To open the glove box, pull on the glove box release lever.
o The glove box door can be locked
(and unlocked) with the key.
HTG2178

1FEATURES OF YOUR HYUNDAI
96
B505A01NF-GAT CENTER CONSOLE BOX
HTG2179
The center console box is used for storing cassette tape or small articles. To use the center console box, pull up the button and lift the lid to open it. HTG2179-1
!WARNING:
To avoid the possibility of injury in case of an accident or a sudden stop, the center console box lidshould be kept closed when the car is in motion.
The outside rearview mirrors can be adjusted to your preferred rear vision, both directly behind the vehicle, and tothe rear of the left and right sides. The remote control outside rearview mirror switch controls the adjustmentsfor both right and left outside mirrors. NOTE: Before driving away, always check that your mirrors are positioned so you can see behind you, both to the left and right sides, as well as di-rectly behind your vehicle. B510B01TG
OUTSIDE REARVIEW MIRROR
B510B01TG-AAT

1
FEATURES OF YOUR HYUNDAI
97
!
CAUTION:
o Do not operate the switch continu- ously for an unnecessary length of time.
o Scraping ice from the mirror face
could cause permanent damage.To remove any ice, use a sponge, soft cloth or approved de-icer.!
WARNING:
Be careful when judging the size or distance of any object seen in the passenger side rearview mirror. It is a convex mirror with a curvedsurface. Any objects seen in this mirror are closer than they appear.
To adjust the position of either mirror:
1. Move the selecting switch to the
right or left to activate the adjustable mechanism for the correspondingdoor mirror.
2. Adjust mirror angle by depressing
the appropriate perimeter switch asillustrated.
B510B02TG
! CAUTION:
If the mirror is jammed with ice, do not adjust the mirror by force. Use an approved spray de-icer (not radiatorantifreeze) to release the frozen mechanism or move the vehicle to a warm place and allow the ice to melt.

1FEATURES OF YOUR HYUNDAI
98
The outside rearview mirror heater is actuated in connection with the front/ rear window defroster. To heat the outside rearview mirror glass, push inthe switch for the front/rear window defroster. The rearview mirror glass will be heated for defrosting or defog-ging and will give you improved rear vision in inclement weather conditions.
B510D02HP-AAT OUTSIDE REARVIEW MIRROR HEATER (If Installed)
B380A01TG
With Manual A/C With Automatic A/C
Push the switch again to turn the heater off. The outside rearview mirror heaterautomatically turns itself off after 20 minutes.
B510C01TG-AAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS (Manual Type) (If Installed) To fold the outside rearview mirrors, push them towards the rear. The outside rearview mirrors can be folded rearward for parking in narrowareas.
B510C01TG
!WARNING:
Do not adjust or fold the outside rearview mirrors while the vehicle is moving. This could result in loss of control, and an accident causingdeath, serious injury or property damage. CAUTION:
If the mirror is jammed with ice, do not adjust the mirror by force. Use anapproved spray de-icer (not radiator antifreeze) to release the frozen mechanism or move the vehicle to awarm place and allow the ice to melt.
!

1
FEATURES OF YOUR HYUNDAI
99DAY/NIGHT INSIDE REAR- VIEW MIRROR
B520A01A-AAT Manual type Your Hyundai is equipped with a day/ night inside rearview mirror. The "night" position is selected by flipping the tab at the bottom of the mirror toward you.In the "night" position, the glare of headlights of cars behind you is re- duced. HTG2079
!
B510E01TG-AAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS (Electric Type)
Both left and right outside rearview mirrors can be folded by pressing theoutside rearview mirror folding switch. The outside rearview mirrors can be folded rearward for parking in narrowareas. B510E01TGCAUTION:
o If the mirror is jammed with ice, do not adjust the mirror by force.Use an approved spray de-icer (not radiator antifreeze) to release the frozen mechanism or move thevehicle to a warm place and allow the ice to melt.
o Do not attempt to fold the outside
rearview mirrors manually.If the mirrors are not completely folded out, the mirrors may bevibrate.
!
WARNING:
Do not adjust or fold the outside rearview mirrors while the vehicle ismoving. This could result in loss of control, and an accident which could cause death, serious injury or prop-erty damage.

1FEATURES OF YOUR HYUNDAI
100
B520B02O-GAT Electric type (If Installed) The electric type day/night inside rear- view mirror automatically controls the glare of headlights of the car behindyou.
1. Pressing the button turns the
auto-dimming function OFF which is indicated by the green status indi- cator LED turning off.
2. Pressing the button again turns the auto-dimming function ON whichis indicated by the green status indi- cator LED turning on.
NOTE: The mirror defaults to the "ON" posi- tion each time the vehicle is started. HTG2080B530A01TG-GAT
B530A01TG
PARKING BRAKE
Always engage the parking brake be- fore leaving the car. This also turns onthe parking brake indicator light when the key is in the "ON" or "START" position. Before driving away, be surethat the parking brake is fully released and the indicator light is off.
o To engage the parking brake, de- press the parking brake pedal.
o To release the parking brake, de- press the parking brake pedal a sec- ond time.
NOTE: The parking brake pedal should be checked periodically for proper stroke.
TRUNK LID
B540A01S-GAT Remote Trunk Lid Release To open the trunk lid without using the key, pull up the lid release lever. HTG2014
HTG2017
To close, lower the trunk lid, then press down on it until it locks.

1
FEATURES OF YOUR HYUNDAI
101
!
B541A01TG-GAT Trunk Lid Control Button The trunk lid control button located in the vehicle glove box is used to preventunauthorized access to the trunk. Locking To activate the trunk lock system so that the trunk can only be opened with the master key, perform the following: 1. Open the glove box. 2. Set the trunk lid control button to
"OFF" position (not depressed).
3. Close the glove box and lock the glove box with the master key. B541A01TG
When leaving the key with a parking lot attendant or valet, perform steps 1 to 3above and leave the sub key with the attendent. Sub key can start the engine and operate door locks only. Releasing To release the trunk lock feature, open the glove box with master key and setthe trunk lid control button to "ON" position (depressed). In this position the trunk will open with trunk lid releaselever or transmitter. The trunk can never be opened with the sub key.
!WARNING:
The trunk lid should be always kept completely closed while the vehicle is in motion. If it is left open or ajar, poisonous exhaust gases may en-ter the car and serious illness or death may result. See additional warnings concerning exhaust gases on page 2-2. To be sure the trunk lid is securely fastened, always check by trying to pullit up again.
WARNING:
Doors and trunk should be keptlocked and keys be kept out of thereach of children. Parents also should teach their children about the dan- gers of playing in trunks.

1FEATURES OF YOUR HYUNDAI
102
HTG2018
B540B02E-AAT Trunk Lid Emergency Latch Re- lease Your vehicle is equipped with a glow- in-the dark emergency trunk releaselever located inside the trunk. It will glow after the trunk is closed. When pulled, this lever will release the trunklatch mechanism and open the trunk.
!WARNING:
o If a person is locked in the trunk, pull the emergency trunk release lever on the driver's side of the inside panel of the trunk to openthe trunk lid.
o HYUNDAI recommends that cars be kept locked and keys be kept out of the reach of children, and that parents teach their children about the dangers of playing intrunks.
o Parents should teach children about the emergency trunk re-lease lever in their vehicle and how to open the trunk lid if they are accidentally locked in the trunk.
HTG2012
B540C01Y-AAT To unlock using the key To open the trunk lid, insert the key and turn it clockwise to unlock. The trunkcompartment light comes on when the trunk lid is opened.

1
FEATURES OF YOUR HYUNDAI
103
!WARNING:
o Fuel vapors are dangerous. Be- fore refueling, always stop the engine and never allow sparks oropen flames near the filler area. If you need to replace the filler cap, use a genuine Hyundai replace-ment part. If you open the fuel filler cap during high ambient tempera-tures, a slight "pressure sound" may be heard. This is normal and not a cause for concern.Whenever you open the fuel filler cap, turn it slowly. HTG2023
REMOTE FUEL-FILLER LID RELEASE
B560A02NF-GAT The fuel-filler lid may be opened from inside the vehicle by pushing on thefuel-filler lid opener located on the driver side door. NOTE: If the fuel-filler lid will not open because ice has formed around it, tap lightly or push on the lid tobreak the ice and release the lid. Do not pry on the lid. If necessary, spray around the lid with an ap-proved de-icer fluid (do not use radiator anti-freeze) or move the vehicle to a warm place and allowthe ice to melt. HTG2022HIGH-MOUNTED REAR STOP LIGHT
B550A01A-AAT In addition to the lower-mounted rear stop lights on either side of the car, the high mounted rear stop light in thecenter of the rear window also lights when the brakes are applied. B550A01TG
