Hyundai Azera 2005 Owner's Manual

1FEATURES OF YOUR HYUNDAI
84FRONT/REAR WINDOW DE- FROSTER SWITCH
B380A01TG
With Automatic A/C
With Manual A/C
B380A02HP-AAT (If Installed)
The front/rear window defroster is turned on by pushing in on the switch. At thesame time, the front/rear window de- froster indicator light on the switch is turned on. To turn the defroster off,push in on the switch a second time. The front/rear window defroster auto- matically turns itself off after about 20minutes. To restart the defroster cycle, push in on the switch again after it has turned itself off. CAUTION:
Do not clean the inner side of thefront/rear window glass with an abrasive type of glass cleaner or use a scraper to remove the foreigndeposits from the inner surface of the glass as this may cause dam- age to the defroster elements. NOTE: The ignition must be in the "ON" position for the front/rear window defroster to operate.
!
The hazard warning system should be used whenever you find it necessaryto stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road asfar as possible. The hazard warning lights are turned on by pushing in on the hazard switch.This causes all turn signal lights to blink. The hazard warning lights will operate even though the key is not inthe ignition. To turn the hazard warning lights off, push in on the switch a second time.

1
FEATURES OF YOUR HYUNDAI
85CIGARETTE LIGHTER
B420A02A-AAT For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position.To use the cigarette lighter, push it all the way into its socket. When the element has heated, the lighter willpop out to the "ready" position. Do not hold the cigarette lighter pressed in. This can damage the heating ele-ment and create a fire hazard. If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundaireplacement or its approved equiva- lent. B420A01TGINSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)
B410A01A-AAT The instrument panel lights can be made brighter or dimmer by turning the instrument panel light control knob. B410A01TG
B410A01TG-R
Left-Hand Drive type
Right-Hand Drive type
DIGITAL CLOCK
B400A01TG-GAT There are three control buttons for the digital clock. Their functions are: H - Push "H" to advance the hour indi-
cated. M - Push "M" to advance the minute
indicated. R - Push "R" to reset minutes to ":00"
to facilitate resetting the clock to the correct time. When this is done: Pressing "R" between 11 : 01 and 11 :29 changes the readout to 11 : 00. Pressing "R" between 11 : 30 and 11 : 59 changes the readout to 12 : 00.Push the "R" button for 4 seconds to display a 12 or 24-hour clock. B400A01TG

1FEATURES OF YOUR HYUNDAI
86POWER OUTLET
B500D01TG-GAT These supply 12V electric power to operate electric accessories or equip- ment only when the key is in the "ON"or "ACC" position. B500D01TG
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.
!! CAUTION:
o Use when the engine is running and remove a plug from the power outlet after using the electric ap- pliance. Using when the enginestops or leaving the electric ap- pliance plugged in for many hours may cause the battery todischarge.
o Do not use the power outlet to
connect electric accessories orequipment other than those de- signed to operate on 12 volts.
o Some electronic devices can cause electronic interference when plugged into the poweroutlet. These devices may cause excessive audio noise and mal- functions in other electronic sys-tems or devices used in your vehicle.

1
FEATURES OF YOUR HYUNDAI
87DRINK HOLDER
HTG2183
The drink holder is located on the main console for holding cups or cans. The drink holder can be opened by pushingat its top edge.
B450A01LZ-GAT Front Drink Holder
ASHTRAY
B430A02NF-GAT Front Ashtray The front ashtray may be opened by pushing and releasing the ashtray lid.To clean the ashtray, the plastic recep- tacle should be removed by lifting the plastic ash receptacle upward and pull-ing it out. The ashtray light will only illuminate when the external lights are on. B430A01TG
B440A01TG-AAT Rear Ashtray The rear ashtray may be opened by pulling the ashtray lid out. To clean the ashtray, the plastic receptacle shouldbe removed by lifting the plastic ash receptacle upward and pulling it out.
HTG2177

1FEATURES OF YOUR HYUNDAI
88
!
CAUTION:
Place the drink holder in its closed position while not in use. HTG2184
B450B01NF-GAT Rear Drink Holder The rear drink holder for holding cups or cans is located in the center of the rear seat armrest.
!
CAUTION:
Place the drink holder in its closed position when not in use.
WARNING:
o Use caution when using the drink holders. A spilled beverage that isvery hot can injure you or your passengers. Spilled liquids candamage interior trim and electri- cal components.
o Do not place objects other than cups or cans in the drink holder.The objects can be thrown out in the event of a sudden stop or anaccident, possibly injuring the pas- sengers in the vehicle.!!WARNING:
o Use caution when using the drink holders. A spilled beverage that is very hot can injure you or your passengers. Spilled liquids can damage interior trim and electri-cal components.
o Do not place objects other than
cups or cans in the drink holder.These objects can be thrown out in the event of a sudden stop or an accident, possibly injuring thepassengers in the vehicle.

1
FEATURES OF YOUR HYUNDAI
89
B460B01TG-GAT Opening the Sunroof System If your vehicle is equipped with this feature, you can slide or tilt your sunroof with the sunroof control buttons lo-cated on the overhead console. The sunroof can only be opened, closed, or tilted when the ignition switchis in the "ON" position. B460B01TG
!
SEATBACK POCKET
B540B01E-GAT
HTG2042
The seatback pockets are located on the backside of the front seats for holding papers.SUNROOF
B460A02Y-AAT (If Installed) Sun Shade
B460A01TG
Your HYUNDAI is equipped with a slid- ing sunshade which you can manuallyadjust to let in light with the sunroof closed, or to block sunlight.
WARNING:
Never adjust the sunshade while driving. This could result in loss ofcontrol and an accident that may cause death, serious injury, or prop- erty damage.

1FEATURES OF YOUR HYUNDAI
90
!
Auto slide open To use the auto slide feature, momen- tarily (more than 1 second) press theSLIDE OPEN button on the overhead console. The sunroof will slide all the way open. To stop the sunroof sliding atany point, press any sunroof control button. Manual slide open Press the SLIDE OPEN button on the overhead console for less than 0.5second. Auto slide close To close the sunroof, press the TILT UP button on the overhead console for more than 1 second. The sunroof will slide all the way close.To stop at the desired point, press any sunroof control button. Auto reverse If an object or part of the body is detected while the sunroof is closingautomatically, it will reverse direction, and then stop. Auto reverse function does not work ifa tiny obstacle is blocked between the sliding glass and the sunroof sash. You should always check that all passen-gers and objects are away from the sunroof before closing it.
WARNING:
Be careful that someone’s head, hands and body are not trapped by aclosing sunroof. Manual slide close Press the TILT UP button on the over- head console for less than 0.5 second.B460C01TG-GAT Tilting the Sunroof System Auto tilt up To use the auto tilt feature, momen- tarily (more than 1 second) press theTILT UP button on the overhead con- sole. The sunroof will tilt all the way open. To stop the sunroof tilting at anypoint, press any sunroof control but- ton. Manual tilt up Press the TILT UP button on the over- head console for less than 0.5 second. B460B01TG

1
FEATURES OF YOUR HYUNDAI
91
!
! WARNING:
o Do not close a sunroof if anyone's hands, arms or body are between the sliding glass and the sunroof sash, as this could result in in-jury.
o Do not place your head or arms
out of the sunroof opening at anytime.
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that
may have accumulated on theguide rails.
o Do not press any sunroof control
button longer than necessary.Damage to the motor or system components could occur.
B460D01NF-GAT Manual Operation of Sunroof If the sunroof does not electrically op- erate:
1. Open the spectacle case.
2. Remove the two mounting screws of the front overhead console with a(+) driver. HTG2029
Manual tilt down To close the sunroof, press the SLIDE OPEN button on the overhead consoleand hold it until the sunroof is closed. NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before oper- ating it.

1FEATURES OF YOUR HYUNDAI
92
3. Insert the hexagonal head wrench
provided with the vehicle into the socket. This wrench can be found in the vehicle's trunk or glove box.
4. Turn the wrench clockwise to open or counterclockwise to close thesunroof. HTG2030
!
B460E01TG-GAT Resetting the sunroof Whenever the vehicle battery is dis- connected or discharged, or you usethe emergency handle to operate the sunroof, you have to reset your sunroof system as follows:
1. Turn the ignition key to the "ON"
position.
2. Press the TILT UP button for more than 1 second to tilt up the sunroof completely when the sunroof is fullyclosed. Then, release the button.
3. Press and hold the TILT UP button
once again until the sunroof hasreturned to the original position of TILT UP after it is raised a little higher than the maximum TILT UPposition. Then, release the button.
4. Press and hold the TILT UP button
within 5 seconds until the sunroof isoperated as follows; TILT DOWN SLIDE OPEN
SLIDE CLOSEThen, release the button. CAUTION:
If the sunroof is not reset, it may not operate properly.

1
FEATURES OF YOUR HYUNDAI
93
B490A02NF-GAT Interior Light The interior courtesy light has two but- tons. The two buttons are:
o DOOR In the "DOOR" position, the interior courtesy light comes on when any door is opened regardless of the igni- tion key position. The light goes outgradually 30 seconds after the door is closed.
B490A01TG
B485A01TG-GAT Rear Map Light Push in the map light switch to turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as a personal light for rearpassengers. B485A01TGB480B01TG-AAT Front Map Light Push in the map light switch to turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as a personal lightfor the driver and the passenger. HTG2113
INTERIOR LIGHT
Without sunroof
With sunroof
