INFINITI FX35 2008 User Guide

ACS-4
< SERVICE INFORMATION >[ICC]
DTC INDEX
SERVICE INFORMATION
DTC INDEX
DTC 11 - 65INFOID:0000000001544468
DTC 74 - 109INFOID:0000000001544469
DTC Items (CONSULT screen terms) Reference
11 CONTROL UNIT ACS-36, "
DTC 11 CONTROL UNIT"
20 CAN COMM CIRCUIT ACS-36, "DTC 20 CAN COMM CIRCUIT"
31 POWER SUPPLY CIR
ACS-37, "DTC 31 POWER SUPPLY CIR, DTC 34 POWER SUPPLY CIR 2"34 POWER SUPPLY CIR 2
41 VHCL SPEED SE CIRCACS-37, "
DTC 41 VHCL SPEED SE CIRC"
43 ABS/TCS/VDC CIRCACS-38, "DTC 43 ABS/TCS/VDC CIRC"
45 BRAKE SW/STOP L SWACS-38, "DTC 45 BRAKE SW/STOP L SW"
46 OPERATION SW CIRCACS-40, "DTC 46 OPERATION SW CIRC"
61 PRESS SEN SIRCUITACS-41, "DTC 61 PRESS SEN CIRCUIT"
62 BOOSTER SOL/V CIRCUITACS-42, "DTC 62 BOOSTER SOL/V CIRCUIT"
63 RELEASE SW CIRCUITACS-43, "DTC 63 RELEASE SW CIRCUIT"
65 PRESSURE CONTROLACS-45, "DTC 65 PRESSURE CONTROL"
DTC Items (CONSULT screen terms) Reference
74 LASER BEAM OFF CNTR ACS-45, "
DTC 74 LASER BEAM OFF CNTR"
90 STOP LAMP RLY FIXACS-46, "DTC 90 STOP LAMP RLY FIX"
92 ECM CIRCUITACS-50, "DTC 92 ECM CIRCUIT"
96 NP RANGEACS-51, "DTC 96 NP RANGE"
97 AT CIRCUITACS-52, "DTC 97 AT CIRCUIT"
98 GEAR POSITIONACS-52, "DTC 98 GEAR POSITION"
102 RADAR STAIN ACS-53, "DTC 102 RADAR STAIN"
103 LASER SENSOR FAILACS-53, "DTC 103 LASER SENSOR FAIL"
104 LASER AIMING INCMPACS-54, "DTC 104 LASER AIMING INCMP"
107 LASER COMM FAILACS-54, "DTC 107 LASER COMM FAIL"
109 LASER HIGH TEMPACS-54, "DTC 109 LASER HIGH TEMP"
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

PRECAUTIONSACS-5
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001612901
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SUPPLEMENTAL RESTRAINT SYS-
TEM” and “SEAT BELTS” of this Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SUPPLEMEN TAL RESTRAINT SYSTEM”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
Precaution for ICC System ServiceINFOID:0000000001328803
 Never look straight into the laser beam discharger when adjusting laser beam aiming.
 Turn the MAIN switch OFF in conditions similar to dr iving, such as free rollers or a chassis dynamometer.
 Do not use the ICC sensor removing from v ehicle, disassemble, or remodel the sensor.
 Erase DTC when replacing parts of ICC system, then c heck the operation of ICC system after adjusting laser
beam aiming if necessary.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-6
< SERVICE INFORMATION >[ICC]
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000001328804
The actual shapes of Kent-Moore tools may differ fr
om those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
KV99110100
(J-45718)
ICC target board Uses for laser beam aiming adjustment
PKIA0358J
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DESCRIPTIONACS-7
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
DESCRIPTION
OutlineINFOID:0000000001328805
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function).
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
With vehicle-to-vehicle distance control mode, the driver can maintain the same speed as other vehicles with-
out the constant need to adjust the set speed as the driver would with a normal cruise control system.
The system is intended to enhance the operation of the vehicle when following the vehicle traveling in the
same lane and direction.
If the distance sensor detects a sl ower moving vehicle ahead, the system wil l reduce speed so that the vehicle
ahead can be followed at the selected distance.
The system automatically controls the throttle and applie s the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 120 m (390 ft) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise contro l mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the Brake Assist is activated and generates a
greater braking force than that of a convent ional brake booster even with light pedal force.
When the Preview Function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver depress
the brake pedal and improves brake re sponse by reducing its free play.
Refer to Owner's Manual for BRAKE ASSIST (W ITH PREVIEW FUNCTION) operating instructions.
Functional DiagramINFOID:0000000001328806
Items of input/output signal to be checked with CONSULT-III
PKIC8700E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-8
< SERVICE INFORMATION >[ICC]
DESCRIPTION
DATA MONITOR INPUT ITEM LIST
DATA MONITOR OUTPUT ITEM LIST
InputData monitored
Item [unit] CAN Description
ECM THRTL OPENING
[%]
×Indicates throttle angle read by ICC unit through CAN communication (ECM transmits
throttle angle through CAN communication).
ENGINE RPM
[rpm] ×
Indicates engine speed read by ICC unit through CAN communication (ECM transmits
engine speed through CAN communication).
MAIN SW
[On/Off] ×Indicates [On/Off] status as judged from steering switch signal (ECM transmits steering
switch signal through CAN communication).
SET/COAST SW
[On/Off] ×Indicates [On/Off] status as judged from steering switch signal (ECM transmits steering
switch signal through CAN communication).
CANCEL SW
[On/Off] ×
Indicates [On/Off] status as judged from steering switch signal (ECM transmits steering
switch signal through CAN communication).
RESUME/ACC SW
[On/Off] ×Indicates [On/Off] status as judged from steering switch signal (ECM transmits steering
switch signal through CAN communication).
IDLE SW
[On/Off] ×Indicates [On/Off] status of idle switch read by ICC unit through CAN communication
(ECM transmits ON/OFF status through CAN communication).
TCM VHCL SPD AT
[km/h] or [mph]
×Indicates vehicle speed calculated from AT vehicle speed sensor by ICC unit through
CAN communication (TCM transmits AT vehicle speed sensor signal through CAN com-
munication).
GEAR
[1, 2, 3, 4, 5] ×Indicates AT gear position read by ICC unit through CAN communication (TCM transmits
gear position through CAN communication).
D RANGE SW
[On/Off] ×
Indicates [On/Off] status of “D” position read by ICC unit through CAN communication
(TCM transmits ON/OFF condition of “D” position through CAN communication).
NP RANGE SW
[On/Off] ×Indicates PNP switch signal read by ICC unit through CAN communication (TCM trans-
mits PNP switch signal through CAN communication).
ABS actuator
and electric
unit (control
unit) VHCL SPEED SE
[km/h] or [mph]
×Indicates vehicle speed calculated from wheel sensor by ICC unit through CAN commu-
nication (ABS actuator and electr
ic unit (control unit) transmits wheel speed sensor signal
through CAN communication).
BCM WIPER SW
[Off/Low/High]
×Indicates wiper [Off/Low/High] status (BCM transmits front wiper request signal through
CAN commun
ication).
Brake pres-
sure sensor PRESS SENS
[bar]
Indicates brake fluid pressure value calculated from signal voltage of pressure sensor.
Release
switch RELEASE SW NO
[On/Off]
Indicates [On/Off] status as judged from release switch signal.
ON when brake is depressed.
OFF when brake is not depressed.
RELEASE SW NC
[On/Off] Indicates [On/Off] status as judged from release switch signal.
ON when brake is not depressed.
OFF when brake is depressed.
ICC brake
switch BRAKE SW
[On/Off]
Indicates [On/Off] status as judged from ICC brake switch signal.
Sto p l am p
switchSTOP LAMP SW
[On/Off]
Indicates [On/Off] status as judged from stop lamp switch signal.
Output Data monitored
Item [unit] CAN Description
ICC warning
chime BUZZER O/P
[On/Off]
×
Indicates [On/Off] status of ICC warning chime output.
ICC brake hold
relay STP LMP DRIVE
[On/Off]
Indicates [On/Off] status of brake hold relay drive output.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DESCRIPTIONACS-9
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
ACTIVE TEST ITEM LIST
Component DescriptionINFOID:0000000001328807
CAN CommunicationINFOID:0000000001328808
CAN (Controller Area Network) is a serial communication li ne for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and eac h control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-43, "CAN System Specification Chart".
Output CONSULT-III ICC
[ACTIVE TEST]
Item CAN Description
Combination
meter ICC BUZZER 1
×Able to start ICC warning chime with a driving signal from ICC unit.
METER LAMP ×Able to turn ICC system display ON with a driving signal from ICC unit.
ICC brake hold
relay STOP LAMP Able to start ICC brake hold relay with a driving signal from ICC unit.
Booster sole-
noid BOOSTER SOL/V
3
Able to start booster solenoid with a driving signal from ICC unit.
ComponentVehicle-to-
vehicle
distance
control mode Conventional
(fixed speed)
cruise
control mode Brake assis
(with preview function) Description
ICC unit ××× Operates electric throttle control actuator and brake
booster based on that sensor signals and CAN commu-
nication data, then controls vehicle distance.
ICC sensor ×× Irradiates laser beam, and receives reflected laser beam
to measure distance from preceding vehicle.
ECM ××× Transmits throttle position signal and ICC steering switch
signal to ICC unit through CAN communication.
ABS actuator and electric
unit (control unit) ××× Transmits wheel speed sensor signal to ICC unit through
CAN communication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure, based on command from
ICC unit.
BCM × Transmit front wiper request signal to ICC unit through
CAN communication.
TCM ×× Transmits gear position signal and output shaft revolu-
tion signal to ICC unit through CAN communication.
Unified meter and A/C amp. ××× Receives ICC system display signal, ICC warning lamp
signal and buzzer output signal from ICC unit through
CAN communication.
ICC brake switch, stop lamp
switch ××× Transmit operating signal to ICC unit when touching
brake pedal. ICC unit cancels cruise system at driver's
brake operation.
ICC brake hold relay × Receives stop lamp driving signal from ICC unit, and
turns stop lamp ON.
Parking brake switch ×× The cruise system is cancelled when applied.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-10
< SERVICE INFORMATION >[ICC]
DESCRIPTION
Switch Operation
INFOID:0000000001328809
The system is operated by MAIN switch and four control switches, all mounted on the steering wheel.
ICC System DisplayINFOID:0000000001328810
No. Switch name Description
1 RESUME/ACCELERATE switch Resumes set speed or increases speed incrementally.
2 SET/COAST switch Sets desired cruise speed, reduces speed incrementally.
3 CANCEL switch Deactivates system without erasing set speed.
4 MAIN switch Master switch to activate the system
5 DISTANCE switch Changes the following distance from: Long, Middle, Short.
SKIB8558E
SKIA6177E
No. Display items Description
1 Set vehicle speed indicator Indicates the set vehicle speed.
 For CANADA models: km/h
 For US models: MPH
2 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead.
3 Set distance indicator Display the selected distance between vehicles set with the DISTANCE switch.
4 Own vehicle indicator Indicates the base vehicle.
5 MAIN switch indicator lamp (Green) Indicates that the MAIN switch is ON.
6 Intelligent cruise control system warning lamp
(Orange) The light comes on if there is a malfunction in the ICC system.
7 SET switch indicator lamp Indicates that the conventional cruise control mode is controlled.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACTION TESTACS-11
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
ACTION TEST
ICC System Running TestINFOID:0000000001328811
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Set Checking
1. Press the MAIN switch for less than 1.5 seconds.
2. Drive the vehicle between 40 km/h (25 MPH) and 144 km/h (90 MPH).
3. Push the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
 When there is no vehicle ahead, drive at the set speed steadily.
 When there is a vehicle ahead, control to maintain distance from the vehicle ahead, watching its speed.
 The set vehicle speed is displayed on the ICC system indicator in the combination meter.
Check For Increase Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed increases by 1 km/h (1 MPH) as RESUME/ACCELERATE switch is pushed.
NOTE:
The maximum set speed of the vehicle-to-vehicl e distance control mode is 144 km/h (90 MPH).
Check For Decrease Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed decreases by 1 km/h (1 MPH) as SET/COAST switch is pushed.
NOTE:
 Vehicle-to-vehicle distance control mode is automatica lly turned off when the driving speed lowers to 32 km/
h (20 MPH) due to the deceleration of the vehicle ahead.
 The minimum set speed of the vehicle-to-vehicle distance control mode is 40 km/h (25 MPH).
Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Condition) In The Following
Cases:
 When the brake pedal is depressed after the system is turned ON.
 When the selector lever is shifted to the “N” (Neutral) position.
 When the MAIN switch is turned OFF.
 When CANCEL switch is operated.
Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode Before Cancellation
1. Cancel the system by depressing the foot brake. Then, check that the speed before cancellation is
restored when pressing RESUME/ACCELERATE switch with 40 km/h (25 MPH) or above.
2. Cancel the system by shifting the selector lever to “N” position. Then, check if the speed set before the
cancellation is restored when RESU ME/ACCELERATE switch is pushed up.
3. Check if the speed previously set is restored w hen RESUME/ACCELERATE switch is operated with driv-
ing 40 km/h (25 MPH), after canceling vehicle-to-v ehicle distance control mode by operating the CANCEL
switch.
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per- formed correctly.
2. Vehicle-to-vehicle distance control mode is displayed in combi- nation meter illuminates when MAIN switch is pressed “ON” for
less than 1.5 seconds and ready for operation. The illumination
goes off when MAIN switch is turned to OFF.
3. “CRUISE” illumination and ICC system display go off when the ignition switch is turned to OFF while MAIN switch is ON
(“CRUISE” illumination is ON and vehicle-to-vehicle distance
control mode is ready for operation).
SKIB8559E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-12
< SERVICE INFORMATION >[ICC]
ACTION TEST
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERA
TE, SET/COAST, CANCEL switches are operated smoothly.
2. Check if buttons come up as hand is released from the buttons.
Check For Distance Switch
1. Start engine.
2. Press the MAIN switch for less than 1.5 seconds.
3. Press the DISTANCE switch.
4. Check if the set distance indicator changes display in order of: (Long) →(Middle) →(Short).
NOTE:
The set distance indicator shows (Long) immediately after the engine starts.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Set Checking
1. Press the MAIN switch for more than 1.5 seconds.
2. Drive the vehicle between 40 km/h (25 MPH) and 144 km/h (90 MPH).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
ICC system display in the combination meter shows nothing.
Check For Increase Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed increases by 1.6 km/h (1 MPH) as RESUME/ACCELERATE switch is pushed up.
NOTE:
 If the RESUME/ACCELERATE switch is kept pushing up during cruise control driving, the vehicle speed
increases until the switch is released.
 The maximum set speed is 144 km/h (90 MPH).
Check For Decrease Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed decreases by 1.6 km/h (1 MPH) as SET/COAST switch is pushed down.
NOTE:
 Conventional (fixed speed) cruise control mode is automatically turned off when the driving speed lowers to 32 km/h (20 MPH).
 The minimum set speed is 40 km/h (25 MPH).
Check For Cancellation Of Conventional (Fixed Speed) Cr uise Control Mode (Normal Driving Condition) In The Fol-
lowing Cases:
SKIB8746E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACTION TESTACS-13
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
Refer to "Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Condition) In
The Following Cases:".
Check For Restoring Speed That Is Set By Conventional (Fixed Speed) Cruise Control Mode Before ICC Cancella-
tion
Refer to "Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode Before Can-
cellation".
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per- formed correctly.
2. “CRUISE” lamp illuminates and ICC system indicator goes off when MAIN switch is pressed “ON” for more than 1.5 seconds,
and then ready for operation. The illumination goes off when
MAIN switch is turned to OFF.
3. “CRUISE” illumination go off when the ignition switch is turned to OFF while MAIN switch is ON.
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERATE, SET/COAST , CANCEL switches are operated smoothly.
2. Check if buttons come up as hand is released from the buttons.
SKIB8560E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
