INFINITI FX35 2008 Service Manual

AT-308
< SERVICE INFORMATION >
ASSEMBLY
9. Install return spring to servo assembly.
10. Install servo assembly in transmission case.
11. Using pair of snap ring pliers, install snap ring to transmissioncase.
12. Install D-rings in reverse brake piston. CAUTION:
 Do not reuse D-rings.
 Apply ATF to D-rings.
13. Install reverse brake piston in transmission case.
SCIA5717E
SCIA5679E
SCIA2333E
SCIA5340E
SCIA2325E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ASSEMBLYAT-309
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
14. Install needle bearing to drum support edge surface. CAUTION:
 Take care with the direction of needle bearing. Refer toAT-264, "
Location of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings".
 Apply petroleum jelly to needle bearing.
15. Install seal rings to drum support. CAUTION:
 Do not reuse seal rings.
 Apply petroleum jelly to seal rings.
16. Install spring retainer and return spring in transmission case.
17. Set the SST on spring retainer and install snap ring (fixing spring retainer) in transmission case while compressing return spring.
CAUTION:
Securely assemble them using a flat-bladed screwdriver so
that snap ring tension is slightly weak.
SCIA2796E
SCIA3333E
SCIA2324E
SCIA5877E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-310
< SERVICE INFORMATION >
ASSEMBLY
18. Install reverse brake drive plates, driven plates and dish plates in transmission case.
CAUTION:
Take care with order of plates.
 VQ35DE models
 VK45DE models
- Snap ring (1)
- Retaining plate (2)
- Drive plate (3)
- Driven plate (4)
- Dish plate (5)
- Drive plate/Driven plate: 6/6
SCIA5250E
SCIA6949E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ASSEMBLYAT-311
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
19. Assemble N-spring.
20. Install reverse brake retaining plate in transmission case.
21. Install snap ring in transmission case.
22. Measure clearance between retaining plate and snap ring. If not within specified clearance, select proper retaining plate. Refer to
“Parts Information” for retaining plate.
23. Install needle bearing to transmission case. CAUTION:
 Take care with the direction of needle bearing. Refer to
AT-264, "
Location of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings".
 Apply petroleum jelly to needle bearing.
SCIA5249E
SCIA2439E
Specified clearance “A”
Standard : 0.7 - 1.1 mm (0.028 - 0.043 in)
SCIA3129E
SCIA5031E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-312
< SERVICE INFORMATION >
ASSEMBLY
24. Install revolution sensor to transmission case, and then tightenrevolution sensor mounting bolt to the specified torque. Refer to
AT-249, "
Component".
CAUTION:
 Do not subject it to impact by dropping or hitting it.
 Do not disassemble.
 Do not allow metal filings, etc. to get on the sensor's front
edge magnetic area.
 Do not place in an area affected by magnetism.
25. As shown in the figure, use the drift to drive rear oil seal into the rear extension (2WD models) or adapter case (AWD models)
until it is flush.
CAUTION:
 Do not reuse rear oil seal.
 Apply ATF to rear oil seal.
26. Install return spring to parking pawl. VQ35DE models
SCIA2320E
SCIA5477E
SCIA2445E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ASSEMBLYAT-313
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
 VK45DE models
- Return spring (1)
- Parking pawl (2)
27. Install parking pawl (with return spring) and pawl shaft to rear extension (2WD models) or adapter case (AWD models).
28. Install parking actuator support to rear extension (2WD models) or adapter case (AWD models).
29. Install needle bearing to rear extension (2WD models) or adapter case (AWD models).
CAUTION:
 Take care with the direction of needle bearing. Refer toAT-264, "
Location of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings".
 Apply petroleum jelly to needle bearing.
30. Install seal rings to output shaft. CAUTION:
 Do not reuse seal rings.
 Apply petroleum jelly to seal rings.
SCIA6180J
SCIA3424E
SCIA3423E
SCIA5221E
SCIA5209E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-314
< SERVICE INFORMATION >
ASSEMBLY
31. Install parking gear to output shaft.
32. Install output shaft in transmission case.CAUTION:
Be careful not to mistake front for rear because both sides
looks similar. (Thinner end is front side.)
33. Install bearing race to output shaft.
34. Install rear extension assembly (2WD models) or adapter case assembly (AWD models) according to the following procedures.
a. 2WD models
i. Apply recommended sealant (Genuine Anaerobic Liquid Gasket or equivalent. Refer to GI-44, "
Recommended Chemical Product
and Sealant".) to rear extension assembly as shown in the fig-
ure.
CAUTION:
Completely remove all moisture, oil and old sealant, etc.
from the transmission case and rear extension assembly
mounting surfaces.
SCIA5247E
SCIA5030E
SCIA5245E
SCIA8228E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ASSEMBLYAT-315
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
ii. Install rear extension assembly to transmission case. CAUTION:
Insert the tip of parking rod between the parking pawl and
the parking actuator suppor t when assembling the rear
extension assembly.
iii. Tighten rear extension assembly mounting bolts to specified torque. Refer to AT-249, "
Component".
CAUTION:
Do not reuse self-sealing bolts.
b. AWD m od e l s
i. Install gasket onto transmission case. CAUTION:
 Do not reuse gasket.
 Completely remove all moistu re, oil and old gasket, etc.
from the transmission case and adapter case assembly
mounting surfaces.
ii. Install adapter case assembly to transmission case. CAUTION:
Insert the tip of parking rod between the parking pawl and
the parking actuator suppor t when assembling the rear
extension assembly.
SCIA5029E
SCIA6941E
SCIA5231E
SCIA5186E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-316
< SERVICE INFORMATION >
ASSEMBLY
iii. Tighten adapter case assembly mounting bolts (1) to specifiedtorque. [With bracket (2).] Refer to AT-249, "
Component".
: Bolt (10)
CAUTION:
Do not reuse self-sealing bolts (3).
Refer to GI section to mark sure icons (symbol marks) in the fig-
ure. Refer to GI-8, "
Component".
35. Install needle bearing in drum support. CAUTION:
 Take care with the direction of needle bearing. Refer to
AT-264, "
Location of Adjusting Sh ims, Needle Bearings,
Thrust Washers and Snap Rings".
 Apply petroleum jelly to needle bearing.
36. Install direct clutch assembly in reverse brake. CAUTION:
Make sure that drum support edge surface and direct clutch
inner boss edge surface come to almost same place.
37. Install high and low reverse clutch assembly in direct clutch.
SCIA7210E
SCIA5198E
SCIA5019E
SCIA2306E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ASSEMBLYAT-317
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
38. Using a flat-bladed screwdriver, align drive plate.
39. Install high and low reverse clutch hub, mid sun gear assembly and rear sun gear assembly as a unit.
CAUTION:
Check that portion “A” of high and low reverse clutch drum
protrudes approximately 2 mm (0 .08 in) beyond portion “B”
of rear sun gear.
40. Install needle bearing in rear carrier assembly. CAUTION:
 Take care with the direction of needle bearing. Refer toAT-264, "
Location of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings".
 Apply petroleum jelly to needle bearing.
SCIA3169E
SCIA5018E
SCIA3130E
SCIA2803E
