INFINITI FX35 2008 Service Manual

AT-278
< SERVICE INFORMATION >
DISASSEMBLY
47. Remove parking gear from output shaft.
48. Remove seal rings from output shaft.
49. Remove needle bearing from transmission case.
50. Remove revolution sensor from transmission case.CAUTION:
 Do not subject it to impact by dropping or hitting it.
 Do not disassemble.
 Do not allow metal filings, etc. to get on the sensor's front
edge magnetic area.
 Do not place in an area affected by magnetism.
51. Remove reverse brake snap ring (fixing plate) using 2 flat- bladed screwdrivers.
NOTE:
Press out snap ring from the transmission case oil pan side gap
using a flat-bladed screwdriver, and remove it using another
screwdriver.
52. Remove reverse brake retaining plate from transmission case. Check facing for burns, cracks or damage. If necessary,
replace the plate.
SCIA5247E
SCIA5209E
SCIA5031E
SCIA2320E
SCIA5032E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DISASSEMBLYAT-279
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
53. Remove N-spring from transmission case.
54. Remove reverse brake drive plates, driven plates and dish plate from transmission case.
Check facing for burns, cracks or damage. If necessary,
replace the plate.
55. Remove snap ring (fixing spring retainer) using a flat-bladed screwdriver.
56. Remove spring retainer and return spring from transmission case.
57. Remove seal rings from drum support.
SCIA5214E
SCIA2322E
SCIA2323E
SCIA2324E
SCIA3333E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-280
< SERVICE INFORMATION >
DISASSEMBLY
58. Remove needle bearing from drum support edge surface.
59. Remove reverse brake piston from transmission case with com-pressed air. Refer to AT-261, "
Oil Channel".
CAUTION:
Care should be taken not to ab ruptly blow air. It makes pis-
tons incline, as the result, it becomes hard to disassemble
the pistons.
60. Remove D-rings from reverse brake piston.
61. Use a pin punch [4 mm (0.16 in) dia. commercial service tool] to knock out retaining pin.
SCIA2796E
SCIA5047E
SCIA5340E
SCIA2328E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DISASSEMBLYAT-281
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
62. Remove manual shaft retaining pin with pair of nippers.
63. Remove manual plate (with parking rod) from manual shaft.
64. Remove parking rod from manual plate.
65. Remove manual shaft from transmission case.
66. Remove manual shaft oil seals using a flat-bladed screwdriver. CAUTION:
Be careful not to scratch transmission case.
SCIA2329E
SCIA5715E
SCIA5220E
SCIA5716E
SCIA2331E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-282
< SERVICE INFORMATION >
DISASSEMBLY
67. Remove detent spring and spacer from transmission case.
68. Using pair of snap ring pliers, remove snap ring from transmis-sion case.
69. Remove servo assembly (with return spring) from transmission case.
70. Remove return spring from servo assembly.
71. Remove O-rings from servo assembly.
SCIA5248E
SCIA2333E
SCIA5679E
SCIA5717E
SCIA5719E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DISASSEMBLYAT-283
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
72. Remove needle bearing from rear extension (2WD models) or adapter case (AWD models).
73. Remove parking actuator s upport from rear extension (2WD
models) or adapter case (AWD models).
74. Remove parking pawl (with return spring) and pawl shaft from rear extension (2WD models) or adapter case (AWD models).
75. Remove return spring from parking pawl. VQ35DE models
SCIA5221E
SCIA3423E
SCIA3424E
SCIA2445E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-284
< SERVICE INFORMATION >
DISASSEMBLY
VK45DE models
- Return spring (1)
- Parking pawl (2)
76. Remove rear oil seal from rear extension (2WD models) or adapter case (AWD models).
CAUTION:
Be careful not to scratch rear extension (2WD models) or
adapter case (AWD models).
SCIA6180J
SCIA5481E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

REPAIR FOR COMPONENT PARTSAT-285
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
REPAIR FOR COMPONENT PARTS
Oil PumpINFOID:0000000001327404
COMPONENTS
DISASSEMBLY
1. Remove oil pump housing from oil pump cover.
2. Remove oil pump housing oil seal using a flat-bladed screw- driver.
CAUTION:
Be careful not to scratch oil pump housing.
1. O-ring 2. Oil pump cover 3. O-ring
4. Oil pump housing 5. Oil pump housing oil seal
SCIA5227E
SCIA5228E
SCIA2840E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-286
< SERVICE INFORMATION >
REPAIR FOR COMPONENT PARTS
3. Remove O-ring from oil pump housing.
4. Remove O-ring from oil pump cover.
ASSEMBLY
1. Install O-ring to oil pump cover.CAUTION:
 Do not reuse O-ring.
 Apply ATF to O-ring.
2. Install O-ring to oil pump housing. CAUTION:
 Do not reuse O-ring.
 Apply ATF to O-ring.
SCIA2841E
SCIA5230E
SCIA5230E
SCIA2841E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

REPAIR FOR COMPONENT PARTSAT-287
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
3. Using the drift, install oil pump housing oil seal to the oil pump housing until it is flush.
CAUTION:
 Do not reuse oil pump housing oil seal.
 Apply ATF to oil pump housing oil seal.
4. Install oil pump housing to oil pump cover.
5. Tighten bolts to the specified torque in numerical order shown in the figure after temporarily ti ghtening them. Refer to "COMPO-
NENTS".
Front Sun Gear, 3r d One-Way ClutchINFOID:0000000001327405
COMPONENTS
DISASSEMBLY
SCIA5313E
SCIA6388E
1. Front sun gear 2. 3rd one-way clutch 3. Snap ring
SCIA3114E
