ACS-2Revision: 2006 January2006 M35/M45 PLY CIR 2 ............................................................... 41
DTC 3 VHCL SPEED SE CIRC .............................. 42
DTC 4 ABS/TCS/VDC CIRC .................................. 42
DTC 5 BRAKE SW/STOP L SW ............................. 43
DTC 6 OPERATION SW CIRC ............................... 47
DTC 12 LASER BEAM OFFCNTR ......................... 48
DTC 13 STOP LAMP RLY FIX ............................... 49
DTC 14 ECM CIRCUIT ........................................... 55
DTC 15 GEAR POSITION ...................................... 56
DTC 16 RADAR STAIN .......................................... 57
DTC 18 LASER AIMING INCMP ............................ 57
DTC 21 UNIT HIGH TEMP ..................................... 57
DTC 24 NP RANGE ............................................... 58
DTC 25 SHIFT RANGE IND ................................... 58
DTC 26 ECD MODE MALF .................................... 59
DTC 27 ECD PWR SUPLY CIR .............................. 59
DTC 100 CAN COMM CIRCUIT ............................. 60
DTC 110 CONTROL UNIT (CAN) ........................... 60
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 61
Symptom Chart ....................................................... 61
Symptom 1: MAIN Switch Does Not Turn ON*
1 ,
MAIN Switch Does Not Turn OFF*
2 ........................ 62Symptom 2: ICC System Cannot Be Set (MAIN
Switch Turns ON/OFF) ............................................ 63
Symptom 3: ICC System Cannot Be Operated by
CANCEL Switch, RESUME/ACCELERATE Switch
or DISTANCE Switch .............................................. 64
Symptom 4: ICC System Is Not Cancelled When
the A/T Selector Lever Is In Other Than “D” and “M” ... 64
Symptom 5: Chime Does Not Sound ...................... 65
Symptom 6: Driving Force Is Hunting ..................... 66
Symptom 7: ICC System Frequently Cannot Detect
the Vehicle Ahead/ Detection Zone Is Short ........... 66
Symptom 8: The System Does Not Detect the Vehi-
cle Ahead at All ....................................................... 67
ELECTRICAL COMPONENT INSPECTION ............. 68
ICC Steering Switch ................................................ 68
ICC Brake Hold Relay ............................................. 68
ICC Brake Switch and Stop Lamp Switch ............... 68
REMOVAL AND INSTALLATION .............................. 69
ICC Sensor Integrated Unit ..................................... 69
REMOVAL ............................................................ 69
INSTALLATION .................................................... 69
ICC Steering Switch ................................................ 69
Page 12 of 5621
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
ACS-3
[ASCD]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
[ASCD]AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
DescriptionNKS004CB
Regarding the information for ASCD system, refer to EC-36, "AUTOMATIC SPEED CONTROL DEVICE
(ASCD)" (VQ35DE), EC-746, "AUTOMATIC SPEED CONTROL DEVICE (ASCD)" (VK45DE).
Page 13 of 5621
ACS-4
[ICC]
PRECAUTIONS
Revision: 2006 January2006 M35/M45
[ICC]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS004CC
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NING :
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceNKS004CD
Do not look straight into the laser beam discharger when adjusting laser beam aiming.
Turn the MAIN switch OFF in conditions similar to driving, such as free rollers or a chassis dynamometer.
Do not use the ICC sensor integrated unit removing from vehicle. Never disassemble and remodel.
Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.
Page 14 of 5621
PREPARATION
ACS-5
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
PREPARATIONPFP:00002
Special Service ToolsNKS004CE
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent - Moore No.)
To o l n a m eDescription
KV99110100
(J-45718)
ICC target boardUses for laser beam aiming adjustment
PKIA0358J
Page 15 of 5621
ACS-6
[ICC]
DESCRIPTION
Revision: 2006 January2006 M35/M45
DESCRIPTIONPFP:00000
OutlineNKS004CF
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function).
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Vehicle-to-vehicle distance control mode, the driver can maintain the same speed as other vehicles without
the constant need to adjust the set speed as the driver would with a normal cruise control system.
The system is intended to enhance the operation of the vehicle when following the vehicle traveling in the
same lane and direction.
If the ICC sensor integrated unit detects a slower moving vehicle ahead, the system will reduce speed so that
the vehicle ahead can be followed at the selected distance.
The system automatically controls the throttle and applies the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 390 ft (120 m) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise control mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the Brake Assist is activated and generates a
greater braking force than that of a conventional brake booster even with light pedal force.
When the Preview Function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver
depresses the brake pedal and improves brake response by reducing its free play.
Refer to Owner's Manual for BRAKE ASSIST (WITH PREVIEW FUNCTION) operating instructions.
System DiagramNKS004CG
PKIB8345E
Page 16 of 5621
DESCRIPTION
ACS-7
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
Components DescriptionNKS004CH
CAN CommunicationNKS004CI
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-34, "CAN Communication Unit" .
ComponentVehicle-to-
vehicle
distance
control modeConventional
(fixed speed)
cruise
control modeBrake assist
(with pre-
view func-
tion)Description
ICC sensor integrated unit
Controls vehicle distance by operating electric throttle
control actuator based on that sensor signals and
CAN communication data.
Controls vehicle distance by transmitting deceleration
degree commandment value signal to ABS actuator
and electric unit (control unit) when deceleration with
brake is needed.
Irradiates laser beam, and receives reflected laser
beam to measure distance from preceding vehicle.
ECM
Transmits accelerator pedal position signal, ICC brake
switch signal, stop lamp switch signal and ICC steering
switch signal to ICC sensor integrated unit through CAN
communication.
ABS actuator and electric
unit (control unit)
Transmits vehicle speed signal (wheel speed) and
stop lamp switch signal to ICC sensor integrated unit
through CAN communication.
Receives Deceleration degree commandment value
signal from ICC sensor integrated unit, and controls
brake fluid pressure with the ABS motor.
BCM
Transmits front wiper request signal to ICC sensor inte-
grated unit through CAN communication.
TCM
Transmits gear position signal and output shaft revolu-
tion signal to ICC sensor integrated unit through CAN
communication.
Unified meter and A/C amp.
Receives meter display signal, ICC warning lamp signal
and buzzer output signal from ICC sensor integrated
unit through CAN communication.
ICC brake switch
Transmits operating signal to ECM when depressing
brake pedal. ICC sensor integrated unit cancels cruise
system at driver's brake operation.
Stop lamp switch
Transmits operating signal to ECM and ABS actuator
and electric unit (control unit) when depressing brake
pedal. ICC sensor integrated unit cancels cruise system
at driver's brake operation.
Page 17 of 5621
ACS-8
[ICC]
DESCRIPTION
Revision: 2006 January2006 M35/M45
Switch OperationNKS004CJ
The system is operated by MAIN switch and four control switches, all mounted on the steering wheel.
IN VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
IN CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
PKIB8346E
No. Switch name Description
1 RESUME/ACCELERATE switch Resumes set speed or increases speed incrementally.
2 SET/COAST switch Sets desired cruise speed, reduces speed incrementally.
3 CANCEL switch Deactivates system without erasing set speed.
4 DISTANCE switch Changes the following distance from: Long, Middle, Short.
5 MAIN switch Master switch to activate the system (press for less than 1.5 seconds)
No. Switch name Description
1 RESUME/ACCELERATE switch Resumes set speed or increases speed incrementally.
2 SET/COAST switch Sets desired cruise speed, reduces speed incrementally.
3 CANCEL switch Deactivates system without erasing set speed.
4 DISTANCE switch Ineffective in this mode
5 MAIN switch Master switch to activate the system (press for more than 1.5 seconds)
Page 18 of 5621
DESCRIPTION
ACS-9
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
ICC System DisplayNKS004CK
The status of ICC system is displayed by dot matrix LCD, MAIN switch indicator lamp and ICC system warning
lamp on the combination meter.
IN VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
IN CONVENTIONAL (FIXED SPEED) CRUISE CONTROL
MODE
PKIB8347E
No. Display items Description
1 Set vehicle speed indicator Indicates the set vehicle speed.
2 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead.
3 Set distance indicatorIndicates the selected distance between vehicles set with the DISTANCE
switch.
4 Own vehicle indicator Indicates the base vehicle.
5 MAIN switch indicator lamp (Green) Indicates that the MAIN switch is ON.
6Intelligent cruise control system warning
lamp (Orange)The light comes on if there is a malfunction in the ICC system.
PKIB4982J
No. Display items Description
1 Set switch indicatorIndicates that the set conventional (fixed speed) cruise control mode is con-
trolled.
2 MAIN switch indicator lamp (Green) Indicates that the MAIN switch is ON.
3Intelligent cruise control system warning
lamp (Orange)The light comes on if there is a malfunction in the ICC system.
Page 19 of 5621
ACS-10
[ICC]
ACTION TEST
Revision: 2006 January2006 M35/M45
ACTION TESTPFP:00000
ICC System Running TestNKS004CL
NOTE:
ICC system can set VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE and CONVENTIONAL (FIXED
SPEED) CRUISE CONTROL MODE when selector lever is in “D” and “M” position.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
NOTE:
When there is no vehicle ahead, drive at the set speed steadily.
When there is a vehicle ahead, control to maintain distance from the vehicle ahead, watching its speed.
Set Checking
1. Press the MAIN switch for less than 1.5 seconds.
2. Drive the vehicle between 25 MPH (40 km/h for CANADA models) and 90 MPH (144 km/h for CANADA
models).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
The set vehicle speed is displayed on the dot matrix LCD in the combination meter.
Check For Increase Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed increases by 1 MPH (1 km/h for CANADA models) as RESUME/ACCELERATE
switch is pushed up.
NOTE:
The maximum set speed of the vehicle-to-vehicle distance control mode is 90 MPH (144 km/h for CANADA
models).
Check For Decrease Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed decreases by 1 MPH (1 km/h for CANADA models) as SET/COAST switch is
pushed down.
NOTE:
Vehicle-to-vehicle distance control mode is automatically cancelled when the driving speed lowers to 20
MPH (32 km/h for CANADA models) due to the deceleration of the vehicle ahead.
The minimum set speed of the vehicle-to-vehicle distance control mode is 25 MPH (40 km/h for CANADA
models).
Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Condi-
tion) In The Following Cases:
1. When the brake pedal is depressed after the system is turned ON.
2. When the selector lever is shifted to the “N” (Neutral) position.
3. When the MAIN switch is turned OFF.
4. When CANCEL switch is operated.
Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode Before
Cancellation
1. Cancel the system by depressing the brake pedal. Then, check if the speed before cancellation is
restored when pushing up RESUME/ACCELERATE switch with 25 MPH (40 km/h for CANADA models)
or above.
2. Cancel the system by shifting the selector lever to “N”. Then, check if the speed set before the cancella-
tion is restored when RESUME/ACCELERATE switch is pushed up.
3. Check if the speed previously set is restored when RESUME/ACCELERATE switch is operated with driv-
ing 25 MPH (40 km/h for CANADA models), after canceling vehicle-to-vehicle distance control mode by
operating the CANCEL switch.
Page 20 of 5621
ACTION TEST
ACS-11
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per-
formed correctly.
2. Vehicle-to-vehicle distance control mode is displayed in combi-
nation meter and “CRUISE” is illuminated when MAIN switch is
pressed “ON” for less than 1.5 seconds and ready for operation.
The illumination goes off when MAIN switch is turned to OFF.
3. “CRUISE” illumination and dot matrix LCD go off when the igni-
tion switch is turned to OFF while MAIN switch is ON (“CRUISE”
illumination is ON and vehicle-to-vehicle distance control mode
is ready for operation).
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERATE, SET/COAST, CANCEL switches are operated smoothly.
2. Check if switches come up as hand is released from the switches.
Check For Distance Switch
1. Start engine.
2. Press the MAIN switch for less than 1.5 seconds.
3. Press the DISTANCE switch.
4. Check if the set distance indicator changes display in order of:
(Long)
(Middle)(Short).
NOTE:
The set distance indicator shows (Long) immediately after the engine starts.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Set Checking
1. Press the MAIN switch for more than 1.5 seconds.
2. Drive the vehicle between 25 MPH (40 km/h for CANADA models) and 90 MPH (144 km/h for CANADA
models).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
The set vehicle speed is not displayed on the dot matrix LCD in the combination meter.
PKIB8348E
PKIB8349E
