CONTROLLERPFP:27500
Removal and Installation of Multifunction SwitchNJS000H4
REMOVAL
Refer to AV- 2 9 2 , "Multifunction Switch" .
INSTALLATION
Installation is basically the reverse order of removal.

AUTO AMP
ATC-125
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 January2006 M35/M45
AUTO AMPPFP:27760
Removal and Installation of Unified Meter and A/C Auto Amp.NJS000H5
REMOVAL
1. Remove audio unit. Refer to AV- 1 3 0 , "Audio Unit" (Without mobile entertainment system) or AV- 2 8 5 ,
"Audio Unit" (With mobile entertainment system).
2. Remove mounting screws, and then remove unified meter and
A/C amp.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4108E

ATC-126
AMBIENT SENSOR
Revision: 2006 January2006 M35/M45
AMBIENT SENSORPFP:27722
Removal and InstallationNJS000H6
REMOVAL
1. Remove front grille. Refer to EI-16, "FRONT GRILLE" .
2. Disconnect ambient sensor connector, and then remove ambi-
ent sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4087E

IN-VEHICLE SENSOR
ATC-127
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 January2006 M35/M45
IN-VEHICLE SENSORPFP:27720
Removal and InstallationNJS000H7
REMOVAL
1. Remove instrument driver lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting screw, and then remove in-vehicle sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4109E

ATC-128
SUNLOAD SENSOR
Revision: 2006 January2006 M35/M45
SUNLOAD SENSORPFP:27721
Removal and InstallationNJS000H8
REMOVAL
1. Remove front defroster grille (left). Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect sunload sensor connector, and then remove sunload
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4110E

INTAKE SENSOR
ATC-129
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 January2006 M35/M45
INTAKE SENSORPFP:27723
Removal and InstallationNJS000H9
REMOVAL
1. Remove low-pressure pipe 1 and high-pressure pipe 2. Refer to ATC-162, "Removal and Installation of
Low-Pressure Pipe 1 and High-Pressure Pipe 2" .
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of A/C piping with new ones, and then apply compressor oil to it when installing
it.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sen-
sor can be located in the same position.
Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.
Insert piping securely until a click is heard.
After piping connection is completed, pull male-side piping by hand to make sure that connection
does not come loose.
When recharging refrigerant, check for leaks.
RJIA4103E

ATC-130
BLOWER UNIT
Revision: 2006 January2006 M35/M45
BLOWER UNITPFP:27200
Removal and InstallationNJS000HA
REMOVAL
1. Remove instrument passenger lower cover and glove box cover. Refer to IP-10, "INSTRUMENT PANEL
ASSEMBLY" .
2. Remove BCM. Refer to BCS-17, "
Removal and Installation of BCM" .
3. Remove mounting nuts, and then remove ECM with bracket
attached.
4. Disconnect intake door motor connector and blower fan motor
connector.
5. Remove mounting bolt and screw from blower unit.
CAUTION:
Move blower unit rightward, and remove locating pin (1
part) and joint. Then remove blower unit downward.
6. Remove blower unit.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure locating pin (1 part) and joint are securely inserted.
R J I A 4 111 E
RJIA4112E

BLOWER UNIT
ATC-131
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 January2006 M35/M45
Disassembly and AssemblyNJS000HB
1. Intake box (left) 2. In-cabin microfilter 3. Filter cover
4. Intake box (right) 5. Intake door lever 2 6. Intake door motor
7. Intake door link 8. Intake door lever 1 9. Intake lower case
10. Blower motor assembly 11. Motor cover 12. Intake upper case
13. Intake door 1 14. Intake door 2
RJIA4113E

ATC-132
BLOWER MOTOR
Revision: 2006 January2006 M35/M45
BLOWER MOTORPFP:27226
Removal and InstallationNJS000HC
REMOVAL
1. Remove instrument passenger lower cover. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect blower motor connector.
3. Remove mounting screws, and then remove blower motor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4114E

INTAKE DOOR MOTOR
ATC-133
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 January2006 M35/M45
INTAKE DOOR MOTORPFP:27730
Removal and InstallationNJS000HD
REMOVAL
1. Remove ECM with bracket attached. Refer to ATC-130, "BLOWER UNIT" .
2. Remove mounting screws, and then remove intake door motor
from blower unit.
3. Disconnect intake door motor connector.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA4115E
