INFINITI QX56 2009 Factory Service Manual

INT-8
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005864613
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000005864610
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: December 20092009 QX56

PRECAUTIONSINT-9
< PRECAUTION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Service NoticeINFOID:0000000003775406
• When removing or installing various parts, place a cloth or padding on the vehicle body to prevent scratches.
• Handle trim, molding, instruments, grille, etc. carefully during removing or installing. Be careful not to soil or
damage them.
• Apply sealing compound where necessary when installing parts.
• When applying sealing compound, be careful that the sealing compound does not protrude from parts.
• When replacing any metal parts (for example body outer panel, members, etc.), be sure to take rust preven-
tion measures.
Revision: December 20092009 QX56

INT-10
< PREPARATION >
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000003775407
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolINFOID:0000000003775408
Tool number
(Kent-Moore No.)
Tool name Description
—
(J-39570)
Chassis ear Locating the noise
—
(J-43980)
NISSAN Squeak and Rattle kit Repairing the cause of noise
—
(J-46534)
Trim Tool Set Removing trim components
SBT839
SBT840
AWJIA0483ZZ
Tool name
(Kent-Moore No.)
Description
Engine ear
(J-39565) Locating the noise
SIIA0995E
Revision: December 20092009 QX56

DOOR FINISHERINT-11
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
ON-VEHICLE REPAIR
DOOR FINISHER
Removal and InstallationINFOID:0000000005864614
FRONT DOOR
Removal
1. Remove the power window switch assembly. • Disconnect the harness connectors.
2. Remove the cap from the inside door handle escutcheon and remove screw.
3. Remove the pull handle cover. • Remove the screws behind pull handle cover.
4. Remove the seat memory switch. • Disconnect the harness connector.
5. Remove the step lamp.
1. Armrest 2. Front door finisher (LH shown) 3. Pull handle cover
4. Cap 5. Inside door handle escutcheon 6. Door lock knob
7. Step lamp 8. Seat memory switch 9. Inside door handle assembly
10. Power window switch assembly
AWJIA0450ZZ
Revision: December 20092009 QX56

INT-12
< ON-VEHICLE REPAIR >
DOOR FINISHER
• Disconnect the harness connector.
6. Remove the door finisher and disconnect the lock cable and handle cable from the inside door handle assembly. Refer to INT-11, "
Removal and Installation".
7. Remove the inside door handle assembly.
8. Remove door lock knob.
9. Remove the armrest screws (A), then remove the armrest (1).
Installation
Installation is in the reverse order of removal.
REAR DOOR
AWJIA0452ZZ
AWJIA0451ZZ
Revision: December 20092009 QX56

DOOR FINISHERINT-13
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
Removal
1. Remove the power window switch assembly.
• Disconnect the harness connector.
2. Remove the pull handle cover. • Remove the screws behind the pull handle cover.
3. Remove the cap from the inside door handle escutcheon and the remove screw.
4. Remove the inside door handle escutcheon. • Remove the screw behind inside door handle escutcheon.
5. Remove step lamp. • Disconnect the step lamp harness connector.
6. Remove the door finisher and disconnect lock c able and handle cable from inside door handle assembly.
Refer to INT-11, "
Removal and Installation".
7. Remove the inside door handle assembly.
8. Remove door lock knob.
9. Remove the rear door tweeter.
10. Remove the armrest screws (A), then remove the armrest (1).
Installation
Installation is in the reverse order of removal.
1. Armrest 2. Power window switch assembly 3. Rear door finisher LH
4. Pull handle cover 5. Cap6. Inside door handle escutcheon
7. Door lock knob 8. Step lamp9. Inside door handle assembly
10. Rear door tweeter
AWJIA0452ZZ
Revision: December 20092009 QX56

INT-14
< ON-VEHICLE REPAIR >
BODY SIDE TRIM
BODY SIDE TRIM
Removal and InstallationINFOID:0000000003775410
CAUTION:
• Wrap the tip of flat-bladed screwdriver with a cloth when removing metal clips from finishers.
• When removing or installing body side welts, do not allow butyl seal to come in contact with pillar
finisher.
LOWER DASH SIDE FINISHER
Removal
1. Remove the push pin from the lower dash side finisher.
2. Remove the front kicking plate from the center pillar lower finisher. Refer to INT-16, "
Removal and Instal-
lation".
3. Remove the lower dash side finisher and the front kicking plate together.
4. Remove the lower dash side finisher from the front kicking plate.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR LOWER FINISHER
1. Center pillar upper finisher LH 2. Center pillar assist grip 3. Rear door welt
4. Rear door bumper 5. Rear door parting seal 6. Clip CG104
7. Rear mudguard finisher 8. Rear kicking plate 9. Center pillar lower finisher LH
10. Metal clip 11. Front mudguard finisher 12. Metal clip
13. Clip CG103 14. Front kicking plate 15. Front door parting seal
16. Front door welt 17. Metal clip 18. Front door bumper
19. Lower dash side finisher LH 20. Front pillar finisher LH 21. Metal clip
22. Front pillar assist grip ⇐Vehicle front
WIIA0967E
Revision: December 20092009 QX56

BODY SIDE TRIMINT-15
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
Removal
1. Remove the front and rear door welts.
2. Remove the seat belt anchor. Refer to
SB-14, "
Removal and Installation".
• On RH side, disconnect the seat belt tension sensor.
3. Remove the front and rear kicking plates. Refer to INT-14, "
Removal and Installation".
4. Remove the center pillar lower finisher.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR UPPER FINISHER
Removal
1. Remove the center pillar lower finisher. Refer to INT-19, "Removal and Installation".
2. Remove the assist grip.
3. Remove the center pillar upper finisher.
Installation
Installation is in the reverse order of removal.
FRONT PILLAR FINISHER
Removal
1. Remove the assist grip.
2. Remove the front pillar finisher.
Installation
Installation is in the reverse order of removal.
KICKING PLATES
Removal
Release the clips and remove the front and/or rear kicking plates.
Installation
Installation is in the reverse order of removal.
MUDGUARD FINISHERS
Removal
Release the clips and remove the front and/or rear mudguard finishers.
Installation
Installation is in the reverse order of removal.
DOOR PARTING SEALS
Removal
1. Open front and/or rear doors fully.
2. Release clips and remove parting seals.
Installation
Installation is in the reverse order of removal.
Revision: December 20092009 QX56

INT-16
< ON-VEHICLE REPAIR >
FLOOR TRIM
FLOOR TRIM
Removal and InstallationINFOID:0000000003775411
REMOVAL
1. Remove the front seats. Refer to SE-50, "Removal and Installation".
• Remove the subwoofer. Refer to AV-176, "
Removal and Installation".
• Remove the navigation display control unit. Refer to AV-170, "
Removal and Installation".
2. Remove the second row seats. Refer to SE-55, "
Removal and Installation" and SE-51, "Exploded View", if
equipped.
3. Remove the third row rear seats. Refer to SE-56, "
Exploded View".
4. Remove the lower seat belt anchors. Refer to SB-14, "
Removal and Installation".
5. Remove the lower body side trim. Refer to INT-14
.
6. Remove the luggage lower side finishers (left / right). Refer to INT-19
.
7. Remove the kicking plates. Refer to INT-14
.
8. Remove the center console. Refer to IP-20, "
Removal and Installation".
9. Remove the rear console, if equipped. Refer to IP-21, "
Removal and Installation".
10. Remove the rear lower finisher. Refer to INT-19
.
11. Remove the carpet.
12. Remove the floor mat hooks from the front carpet.
INSTALLATION
Installation is in the reverse order of removal.
1. Carpet 2. Floor mat hooks
AWJIA0408ZZ
Revision: December 20092009 QX56

HEADLININGINT-17
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
HEADLINING
Removal and InstallationINFOID:0000000003775412
1. Headlining 2. Assist grip bracket3. Assist grip
4. Sunvisor assembly LH 5. Cap LH 6. Sunvisor holder
7. Front roof console 8. Sunglass bin9. Sunroof welt
AWJIA0341GB
Revision: December 20092009 QX56
