ADP-102
< DTC/CIRCUIT DIAGNOSIS >
MIRROR SENSOR
MIRROR SENSOR
DRIVER SIDE
DRIVER SIDE : Component Function CheckINFOID:0000000006248398
1.CHECK FUNCTION
1. Select “MIR/SEN LH U-D”, “MIR/SEN LH R-L” in “Data monitor” with CONSULT-III.
2. Check mirror sensor (driver side) signal under the following condition.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-102, "
DRIVER SIDE : DiagnosisProcedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000006248399
1.CHECK DOOR MIRROR (DRIVER SIDE) SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect door mirror (driver side) connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR MIRROR (DRIVER SIDE ) SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive posit ioner control unit harness connector and door mirror
(driver side) harness connector.
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit.
NO >> Repair or replace harness or connector.
Monitor item Condition Value
MIR/SEN LH U-D Door mirror (driver side)Change between
3.4 [V] (close to peak)
0.6 [V] (close to valley)
MIR/SEN LH R-L Change between
0.6 [V] (close to left edge)
3.4 [V] (close to right edge)
(+)
(-)Voltage (V)
(Approx.)
Door mirror (driver side)
Connector Terminals D3 23 Ground 5
Automatic drive positioner control unit Door mirror (driver side) Continuity
Connector Terminal Connector Terminal
M7521D323Existed
Automatic drive positioner control unit GroundContinuity
Connector Terminal
M75 21 Not existed
