< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A01 POWER SUPPLY CIRCUIT 1,
C1A02 POWER SUPPLY CIRCUIT 2
C1A01 POWER SUPPLY CIRCUIT 1, C1A02 POWER SUPPLY CIRCUIT 2
DTC LogicINFOID:0000000006223531
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A01” or “C1A02” is detected as t he current malfunction in “Self Diagnostic Result” of “ICC/
ADAS”.
Is
“C1A01” or “C1A02” detected as the current malfunction?
YES >> Refer to DAS-130, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223532
1.CHECK ADAS CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit of ADAS control unit. Refer to DAS-195, "
ADAS CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> Repair or replace the malfunctioning parts.
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A01 (1) POWER SUPPLY
CIR The battery voltage sent to ADAS control unit re-
mains less than 7.9 V for 5 seconds
 Connector, harness, fuse
 ADAS control unit
C1A02
(2) POWER SUPPLY
CIR 2 The battery voltage sent to ADAS control unit re-
mains more than 19.3 V for 5 seconds
Revision: 2010 May2011 QX56

DAS
C1A03 VEHICLE SPEED SENSORDAS-131
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000006228063
DTC DETECTION LOGIC
NOTE:
If DTC “C1A03” is detected along with DTC “U1000” or “C1A04”, first diagnose the DTC “U1000” or “C1A04”.
 Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic" for DTC “U1000”.
 Refer to DAS-133, "
DTC Logic" for DTC “C1A04”.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Drive the vehicle at 30 km/h (19 MPH) or more. CAUTION:
Always drive safely.
4. Stop the vehicle.
5. Perform “All DTC Readi ng” with CONSULT-III.
6. Check if the “C1A03” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A03” detected as the current malfunction?
YES >> Refer to DAS-131, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228064
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A04” or “U1000” is detected other than “C1A03” in “Self Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-100, "
DTC Index".
NO >> GO TO 2.
2.CHECK DATA MONITOR
1. Start the engine.
2. Drive the vehicle.
3. Check that the value of “VHCL SPD AT” is almost the same as the value of “VHCL SPEED SE” in “DATA
MONITOR” of “ICC/ADAS”.
CAUTION:
Be careful of the vehicle speed.
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> GO TO 3.
3.CHECK TCM SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading”.
2. Check if any DTC is detected in “Sel f Diagnostic Result” of “TRANSMISSION”.
DTC
(On board
display) Trouble diagnosis
name DTC detecting condition Possible causes
C1A03 (3) VHCL SPEED SE
CIRC If the vehicle speed signal (wheel speed) from
ABS actuator and electric unit (control unit) and
the A/T vehicle speed sensor signal (output
shaft revolution signal) from TCM, received by
the ADAS control unit via CAN communication,
are inconsistent  Wheel speed sensor
 ABS actuator and electric unit (control
unit)
 Vehicle speed sensor A/T (output speed sensor)
TCM
 ADAS control unit
Revision: 2010 May2011 QX56

DAS
C1A04 ABS/TCS/VDC SYSTEM
DAS-133
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000006228065
DTC DETECTION LOGIC
NOTE:
If DTC “C1A04” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228066
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Readi ng” with CONSULT-III.
2. Check if the “U1000” is detect ed other than “C1A04” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A04 (4) ABS/TCS/VDC CIRC
If a malfunction occurs in the VDC/TCS/ABS
system ABS actuator and electric unit (control
unit)
Revision: 2010 May2011 QX56

DAS-134
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A05 BRAKE SW/STOP LAMP SW
C1A05 BRAKE SW/STOP LAMP SW
DTC LogicINFOID:0000000006228067
DTC DETECTION LOGIC
NOTE:
If DTC “C1A05” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228068
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the “U1000” is detected other than “C1A 05” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
Check that “STOP LAMP SW” and “BRAKE SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
Is the inspection result normal?
YES >> GO TO 3.
NO-1 >> When “BRAKE SW” operation is malfunctioning: GO TO 4.
NO-2 >> When “STOP LAMP SW” operation is malfunctioning: GO TO 9.
3.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate norma lly in “DATA MONITOR” of “ABS”.
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 9.
4.CHECK ICC BRAKE SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check ICC brake switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Adjust ICC brake switch installation. Refer to BR-7, "
Inspection and Adjustment".
5.ICC BRAKE SWITCH INSPECTION
1. Disconnect ICC brake switch connector.
2. Check ICC brake switch. Refer to DAS-137, "
Component Inspection (ICC Brake Switch)".
Is the inspection result normal?
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A05 (5) BRAKE SW/STOP L
SW A mismatch between a stop lamp switch signal
and a ICC brake switch signal received from
ECM and a stop lamp signal received from the
ABS actuator and electric unit (control unit) con-
tinues for 10 seconds or more with vehicle
speeds at approximately 40 km/h or more  Stop lamp switch circuit
 ICC brake switch circuit
 Stop lamp switch
 ICC brake switch
 Incorrect stop lamp switch installa-
tion
 Incorrect ICC brake switch installa- tion
ECM
 ABS actuator and electric unit (con-
trol unit)
Revision: 2010 May2011 QX56

DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-137
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
14.PERFORM SELF-DIAGNOSIS OF ECM
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ENGINE”. Refer to EC-98, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> GO TO 15.
15.PERFORM SELF-DIAGNOSIS OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”. Refer to BRC-51, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
Component Inspection (ICC Brake Switch)INFOID:0000000006228069
1.CHECK ICC BRAKE SWITCH
Check for continuity between I CC brake switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ICC brake switch.
Component Inspection (Stop Lamp Switch)INFOID:0000000006228070
1.CHECK STOP LAMP SWITCH
Check for continuity between stop lamp switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch.
Terminal Condition Continuity
12 When brake pedal is depressed
Not exist-
ed
When brake pedal is released Existed
Terminal Condition Continuity
12 When brake pedal is depressed Existed
When brake pedal is released
Not exist-
ed
34 When brake pedal is depressed Existed
When brake pedal is released
Not exist-
ed
Revision: 2010 May2011 QX56

DAS-138
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A06 OPERATION SW
C1A06 OPERATION SW
DTC LogicINFOID:0000000006228071
DTC DETECTION LOGIC
NOTE:
If DTC “C1A06” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Wait for approximately 10 minutes after turning the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A06” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A06” detected as the current malfunction?
YES >> Refer to DAS-138, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228072
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “C1A06” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC STEERING SWITCH
1. Turn the ignition switch OFF.
2. Disconnect the ICC steering switch connector.
3. Check the ICC steering switch. Refer to DAS-139, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the steering wheel.
3.CHECK HARNESS BETWEEN SPIRAL CABLE AND ECM
1. Disconnect the ECM connector.
2. Check for continuity between the spiral cable harness connector and ECM harness connector.
3. Check for continuity between spiral cable harness connector and ground.
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A06 (6) OPERATION SW
CIRC  Any switch of the ICC steering switch is de-
tected as “ON” continuously for 60 seconds
 An ON/OFF state judgment of the ICC differs
between ECM and ADAS control unit, and the
state continues for 2 seconds or more  ICC steering switch circuit
 ICC steering switch
ECM
Spiral cable ECM
Continuity
Connector Terminal Connector Terminal
M33 25
E80 128
Existed
32 130
Revision: 2010 May2011 QX56

DAS
C1A13 STOP LAMP RELAYDAS-141
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A13 STOP LAMP RELAY
DTC LogicINFOID:0000000006228076
DTC DETECTION LOGIC
NOTE:
If DTC “C1A13” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE (1)
1. Start the engine.
2. Perform the active test item “STOP LAMP” with CONSULT-III.
3. Perform “All DTC Reading”.
4. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE (2)
1. Drive at the vehicle speed of 40 km/h (25 MPH) or more for approximately 60 seconds or more without the
brake pedal depressed.
CAUTION:
Always drive safely.
NOTE:
If it is outside the above condition, repeat step 1.
2. Perform “All DTC Reading”.
3. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228077
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A13” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A13 (13) STOP LAMP RLY FIX  Stop lamp inactive state continues for 0.3
seconds or more despite the outputting of
an ICC sensor ICC brake hold relay drive
signal
 The stop lamp remains ON for 60 seconds or more under the following conditions:
- Driving at 40 km/h or more
- No stop lamp drive signal output from ICC
sensor
- No brake operation  Stop lamp switch circuit
 ICC brake switch circuit
 ICC brake hold relay circuit
 Stop lamp switch
 ICC brake switch
 ICC brake hold relay
 Incorrect stop lamp switch installation
 Incorrect ICC brake switch installation
ECM
 ABS actuator and elec
tric unit (control
unit)
Revision: 2010 May2011 QX56

DAS-144
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A13 STOP LAMP RELAY
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ADAS control unit. Refer to
DAS-63, "
Removal and Installation".
13.CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Check the voltage between ICC brake hold relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Repair or replace ICC brake hold relay power supply circuit.
14.CHECK HARNESS BETWEEN ICC BR AKE HOLD RELAY AND ECM
1. Disconnect ECM, rear combination lamp, and high- mounted stop lamp connectors and remove ICC brake
hold relay.
2. Check for continuity between ICC brake hold relay harness connector and ECM harness connector.
3. Check for continuity between ICC brake hold relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 15.
NO >> Repair the harnesses or connectors.
15.CHECK ICC BRAKE HOLD RELAY
1. Remove ICC brake hold relay.
2. Check ICC brake hold relay. Refer to DAS-146, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 16.
NO >> Replace ICC brake hold relay.
16.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate norma lly in “DATA MONITOR” of “ABS”.
Te r m i n a l
Condition
Vo l ta g e
(Approx.)
(+) (–)
ADAS control unit
GroundActive Test
item
“STOP LAMP”
Connector Terminal
B61 5 Off
Battery
voltage
On 0 V
Te r m i n a l
Vo l ta g e
(Approx.)
(+) (–)
ICC brake hold relay
Ground
Connector Terminal
E64 3 Battery
voltage
ICC brake hold relay ECM Continuity
Connector Terminal Connector Terminal
E64 5 E80 158 Existed
ICC brake hold relay GroundContinuity
Connector Terminal
E64 5 Not existed
Revision: 2010 May2011 QX56

DAS-146
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A13 STOP LAMP RELAY
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ENGINE”. Refer to
EC-98, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> GO TO 22.
22.PERFORM SELF-DIAGNOSIS OF ABS ACTUAT OR AND ELECTRIC UNIT (CONTROL UNIT)
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ABS”. Refer to BRC-51, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> Replace ADAS control unit. Refer to DAS-63, "
Removal and Installation".
Component InspectionINFOID:0000000006228078
1.CHECK ICC BRAKE HOLD RELAY
Apply battery voltage to ICC brake hold relay terminals 1 and 2, and
then check for continuity under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ICC brake hold relay.
Terminal Condition Continuity
35 When the battery voltage is applied Existed
When the battery voltage is not ap-
plied
Not exist-
ed
JSOIA0075GB
Revision: 2010 May2011 QX56

DAS
C1A14 ECMDAS-147
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A14 ECM
DTC LogicINFOID:0000000006228079
DTC DETECTION LOGIC
NOTE:
If DTC “C1A14” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Operate the ICC system and drive. CAUTION:
Always drive safely.
3. Stop the vehicle.
4. Perform “All DTC Readi ng” with CONSULT-III.
5. Check if the “C1A14” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A14” detected as the current malfunction?
YES >> Refer to DAS-147, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228080
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A14” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.PERFORM SELF-DIAGNOSIS OF ECM
Check if any DTC is detected in “S elf Diagnostic Result” of “ENGINE”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
EC-98, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A14 (14) ECM CIRCUIT If ECM is malfunctioning  Accelerator pedal position sensor
ECM
 ADAS control unit
Revision: 2010 May2011 QX56
