NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006228304
PRECAUTIONS FOR INTELLIGENT BRAKE ASSIST
 The IBA system is a not collision avoidance system. It is the driver′s responsibility to stay alert, drive safely
and be in control of the vehicle at all times.
 As there is a performance limit, it may not prov ide a warning or brake in certain conditions.
 The system will not detect the following objects:
- Pedestrians, animals, or obstacles in the roadway
- Oncoming vehicles in the same lane
 The system will not detect under the following conditions:
- When the sensor gets dirty and it is impossibl e to detect the distance from the vehicle ahead.
- When driving into a strong light (i.e. sunlight)
 The sensor generally detects the signals returned from the reflectors on a vehicle ahead. Therefore, the sys-
tem may not function properly under the following conditions:
- When the reflectors of the vehicle ahead are positioned high or close each other (including a small vehicle
such as motorcycles).
- When the sensor gets dirty or and it is impossi ble to detect the distance from the vehicle ahead.
- When the reflectors on the vehicle ahead is missing, damaged or covered.
- When the reflector of the vehicle ahead is covered with dirt, snow and road spray.
- When visibility is low (such as rain, fog, snow, etc.).
- When snow or road spray from traveling vehicles are raised up.
- When dense exhaust or other smoke (black smoke) fr om vehicles reduces the sensor visibility.
- When excessively heavy baggage is loaded in the rear seat or the luggage room of vehicle.
- When abruptly accelerating or decelerating.
- On steep downhill or roads with sharp curves.
- When there is a highly reflective object near the vehicle ahead (i.e. very close to other vehicle, signboard,
etc.).
- While towing a trailer or other vehicle.
 Depending on certain road conditions (curved, beginning of a curve), vehicle conditions (steering position,
vehicle position), or preceding vehicle ′s conditions (position in lane, etc. ), the system may not function prop-
erly.
 The system may not function in offset conditions.
 The system may not function when the distanc e to the vehicle ahead is extremely close.
 The system detect highly reflective objects such as reflectors, signs, white markers, and other stationary objects on the road or
near the traveling lane, and when in extreme conditions, detection
of these objects may caus e the system to function.
 The system is designed to automatically check the sensor ′s func-
tionality. If the sensor is covered with ice, a transparent or translu-
cent plastic bag, etc., the system may not detect them. In these
instances the system may not be able to warn properly. Be sure to
check and clean the sensor regularly.
 Excessive noise will interfere with the warning chime sound, and the chime may not be heard.
 Never step in under the brake pedal to avoid an accident when IBA
system turns ON.
 Sudden appearance of the vehicle in front (i.e. it abrupt ly cuts in) may not be detected and the system may
not warn soon enough.
 The system will be cancelled automatically with a beep sound and the IBA OFF indicator lamp will illuminate
under the following conditions:
- When the sensor window is dirty
- When the system malfunctions
JSFIA0385ZZ
Revision: 2010 May2011 QX56

CCS-10
< SYSTEM DESCRIPTION >[ICC]
COMPONENT PARTS
Component Description
INFOID:0000000006224266
× : Applicable
13. Steering angle sensor
Refer to BRC-10, "
Component Parts
Location"
14. ADAS control unit
Refer to DAS-13, "
Component Parts
Location"
A. Back side of engine room (RH) B. Front bumper (center) C. Upper side of brake pedal
D. Under side of inst rument lower driver
panel
Component Function
Description
Vehicle-to-vehicle distance control mode
Conventional (fixed speed) cruise control mode Intelligent Brake Assist (IBA)
Brake Assist (with preview function)
ADAS control unit ×××× ADAS control unit calculates a target distance between vehicles
and a target speed, based on signals received from each sensor
and switch to transmit an engine torque command value to ECM
and a brake fluid pres sure control signal to ABS actuator and
electric unit (control unit) via CAN communication
 ADAS control unit transmits buzzer output signal to combination
meter via CAN communication
ICC sensor ×××× ICC sensor detects light reflected from a vehicle ahead by irra-
diating laser forward and calculates a distance from the vehicle
ahead and a relative speed, based on the detected signal
 ICC sensor transmits the presence/absence of vehicle ahead and the distance from the vehicle to ADAS control unit via ITS
communication
ECM ×××× ECM transmits the accelerator pedal position signal, ICC brake
switch signal, stop lamp switch signal, ICC steering switch sig-
nal, etc. to ADAS control unit via CAN communication
 ECM controls the electric throttle control actuator based on the engine torque demand received from the ADAS control unit via
CAN communication
ABS actuator and electric unit
(control unit) ×××× ABS actuator and electric unit (control unit) transmits the vehicle
speed signal (wheel speed), stop lamp signal and VDC/TCS/
ABS system operation condition to ADAS control unit via CAN
communication
 ABS actuator and electric unit (control unit) controls the brake, based on a brake fluid pressure control signal received from the
ADAS control unit via CAN communication
BCM ×BCM transmits the front wiper request signal to ADAS control unit
via CAN communication
TCM ××TCM transmits the signal related to A/T control to ADAS control
unit via CAN communication
Revision: 2010 May2011 QX56

CCS-14
< SYSTEM DESCRIPTION >[ICC]
SYSTEM
Output Signal Item
DESCRIPTION
Intelligent Cruise Control
The Intelligent Cruise Control (ICC) system maintains a se
lected distance from the vehicle in front of own vehi-
cle within the speed range of 0 to 144 km/h (0 to 90 MPH) up to the set speed.
The set speed can be selected by the driver between 32 to 144 km/h (20 to 90 MPH).
The vehicle travels at a set speed when the road ahead is clear.
The ICC system can be set to one of two cruise control modes:
CAUTION:
Never set the cruise speed exceed ing the posted speed limit.
Vehicle-to-vehicle Distance Control Mode
ICC sensorITS com-
munica-
tionICC sensor signal
Receives detection results, such as the presence or ab-
sence of a leading vehicle and distance from the vehicle
IBA OFF switch IBA OFF switch signal Receives an ON/OFF state of the IBA OFF switch Transmit unit Signal name Description
Reception unit Signal name Description
ECM CAN commu-
nicationICC operation signal
Transmits an ICC operation signal necessary for Intel-
ligent Cruise Control
TCM CAN commu-
nicationICC operation signal Transmits an ICC operation signal necessary for Intel-
ligent Cruise Control via ECM
ABS actuator
and electric
unit (control
unit) CAN commu-
nication
Brake fluid pressure control signal
Transmits a brake fluid pressure control signal to acti-
vates the brake
Combination
meter CAN commu-
nicationMeter display
signal Own vehicle indicator
signal
Transmits a signal to display a state of the system on
the information display
Vehicle ahead detec-
tion indicator signal
Set vehicle speed indi-
cator signal
Set distance indicator
signal
SET switch indicator
signal
MAIN switch indicator
signal
ICC warning lamp signal Transmits an ICC warning lamp signal to turn ON the
ICC system warning lamp
IBA OFF indicator lamp signal  Transmits a signal to turn ON the IBA OFF indicator
lamp
 Transmits an ON/OFF state of the intelligent brake
assist
Buzzer output signal Transmits a buzzer output signal to turn ON the buzz-
er of the following systems:
 Intelligent Cruise Control (ICC)
 Intelligent Brake Assist (IBA)
ICC sensor ITS commu-
nication
Vehicle speed signal Transmits a vehicle speed calculated by the ADAS
control unit
ICC brake hold
relay ICC brake hold relay drive signal
Activates the brake hold relay and turns ON the stop
lamp
Revision: 2010 May2011 QX56

CCS
SYSTEMCCS-15
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
For maintaining a selected distance between own vehicle and the vehicle in front of own vehicle up to t\
he pre-
set speed. Refer to CCS-15, "
VEHICLE-TO-VEHICLE DISTANCE CO NTROL MODE FUNCTION : System
Description".
Conventional (Fixed Speed) Cruise Control Mode
For cruising at a preset speed. Refer to CCS-18, "CONVENTIONAL (FIXED SPEED) CRUISE CONTROL
MODE FUNCTION : System Description".
NOTE:
In the Conventional (Fixed Speed) Cruise Control Mode, a warning chime will not sound to warn driver if own
vehicle are too close to the vehicle ahead.
WARNING:
Always drive carefully and attentively when using ei ther cruise control mode. To avoid serious injury
or death, do not rely on the system to prevent accide nts or to control the vehicle's speed in emer-
gency situations. Do not use cr uise control except in appropriat e rode and traffic conditions.
Distance Control Assist (DCA) System
DCA share the systems and component s with ICC system. Refer to DAS-68, "System Description".
Forward Collision Warning (FCW) System
FCW share the systems and component s with ICC system. Refer to DAS-218, "System Description".
Intelligent Brake Assist (IBA) System
IBA system share the systems and components with ICC system. Refer to BRC-152, "INTELLIGENT BRAKE
ASSIST : System Description".
Brake Assist (with preview function)
Brake Assist (with preview function) share t he systems and components with ICC system. Refer to BRC-145,
"BRAKE ASSIST (WITH PREVIEW FUNCTION) : System Description".
Fail-safe (ADAS Control Unit)INFOID:0000000006224268
If a malfunction occurs in each system, ADAS control unit cancels eac h control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Fail-safe (ICC Sensor)INFOID:0000000006224269
If a malfunction occurs in the ICC sensor, ADAS cont rol unit cancels control, sounds a beep, and turns ON the
ICC system warning lamp in the combination meter.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE FUNCTION
VEHICLE-TO-VEHICLE DISTANCE CONTRO L MODE FUNCTION : System Descrip-
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warning lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warning lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warning lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Lane Departure Prevention (LDP) Low-pitched
toneLane departure warning lamp Cancel
Blind Spot Warning (BSW) — BSW warning lamp Cancel
Revision: 2010 May2011 QX56

CCS
OPERATIONCCS-21
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
OPERATION
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE FUNCTION
VEHICLE-TO-VEHICLE DISTANCE CONT ROL MODE FUNCTION : Switch Name
and Function
INFOID:0000000006224272
VEHICLE-TO-VEHICLE DISTANCE CONT ROL MODE FUNCTION : Menu Displayed
by Pressing Each Switch
INFOID:0000000006224273
ICC SYSTEM DISPLAY (ON THE INFORMATION DISPLAY)
JSOIA0290ZZ
No. Switch name Description
1 CANCEL switch Deactivates the system without erasing the set speed
2 RESUME/ACCELERATE switch Resumes set speed or increases speed incrementally
 Push and hold the switch to increase the set speed by 5 km/h (5 MPH)
 Push then quickly release the switch to
increase the set speed by 1 km/h (1 MPH)
3 SET/COAST switch Sets desired cruise speed or reduces speed incrementally
 Push and hold the switch to decrease the set speed by 5 km/h (5 MPH)
 Push then quickly release the switch to decrease the set speed by 1 km/h (1 MPH)
NOTE:
The minimum set speed is 32 km/h (20 MPH)
4 MAIN switch Master switch to activate the system (Press for less than 1.5 seconds)
5 DISTANCE switch Changes the following distance from: Long, Middle, Short
JSOIA0291ZZ
No. Switch name Description 1 ICC system warning lamp Indicates that a malfunction occurs in the ICC system
2 MAIN switch indicator Indicates that th e MAIN switch is ON (ICC system ON)
3 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead
4 Set distance indicator Indicates the selected distance between vehicles set with the DISTANCE switch
Revision: 2010 May2011 QX56

CCS-24
< SYSTEM DESCRIPTION >[ICC]
OPERATION
WARNING LAMP AND AUTOMATIC CANCELLATION DISPLAY
NOTE:
Condition Display on ICC system display
When own vehicle comes closer to the vehicle ahead and it is judged that the distance be-
tween the vehicles is not sufficient
JSOIA0301ZZ
Condition Description Display on ICC system display
Warning
display  When the VDC is turned OFF
 When the VDC or ABS (in-
cluding the TCS) operates
 When a wheel slips
 When the 4WD shift switch is not AUTO
 When the SNOW mode switch is turned ON
 When driving into a strong light (i.e., sunlight) A chime sounds and the control is automatically
canceled.
NOTE:
When the conditions listed above are no longer
present, turn the system OFF using the MAIN
switch.
Turn the ICC system back on to use the system.
When the sensor window is
dirty, making it impossible to de-
tect a vehicle ahead. A chime sounds and the control is automatically
canceled.
NOTE:
Park the vehicle in a safe place, turn the engine
OFF.
Clean the sensor window with a soft cloth and
then perform the settings again.
When the ICC system is mal-
functioning A chime sounds and the control is automatically
canceled.
NOTE:
Turn the engine OFF and restart engine. If there
is no malfunction, it is possible to set the system.
Automatic
cancella-
tion display  When brake pedal is de-
pressed
 When CANCEL switch is pressed
 When a vehicle ahead is not
detected below the speed of
24 km/h (15 MPH)
 When the system judges the
vehicle is at standstill
 When the selector lever is not in “D” position or manual
mode
 When the front wipers are op- erating at HI
(If the vehicle is equipped
with a rain sensing auto-wip-
er, the system may cancel
when the wipers are set to
AUTO)
 When the parking brake are
applied A chime sounds and the control is automatically
canceled.
NOTE:
 The system will be in a standby, after the control
is automatically canceled.
 A chime sounds when the control is automati-
cally canceled, except when brake pedal is de-
pressed or when CANCEL switch is pressed.
JSOIA0302ZZ
JSOIA0303ZZ
JSOIA0304ZZ
JSOIA0292ZZ
Revision: 2010 May2011 QX56

CCS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
CCS-33
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
Display Items for The Cause of Automatic Cancellation 2
SELF DIAGNOSTIC RESULT
Refer to DAS-38, "DTC Index".
DATA MONITOR
INCHING LOST ×A vehicle ahead is not detected during the following driving when
the vehicle speed is approximately 24 km/h (15 MPH) or less
CAN COMM ERROR ×××ADAS control unit received an abnormal signal with CAN commu-
nication
ABS/TCS/VDC CIRC ×××An abnormal condition occurs in VDC/TCS/ABS system
ECD CIRCUIT ×××An abnormal condition occurs in ECD system
ASCD VHCL SPD DTAC ×Vehicle speed is detached from set vehicle speed
ASCD DOUBLE COMD ×Cancel switch and operation switch are detected simultaneously
APA HI TEMP ×The accelerator pedal actuator integrated motor temperature is
high
ICC SENSOR CAN
COMM ERR ××Communication error between ADAS control unit and the ICC sen-
sor
4WD LOCK MODE ×××Shifting of the 4WD shift switch to 4H or 4L
ABS WARNING LAMP ××ABS warning lamp ON
NO RECORD ××× —
Cause of cancellation Description
OPE VDC/TCS/ABS 1 The activation of VDC, TCS, or ABS during LDP system control
Vehicle dynamics Vehicle behavior exceeds specified value
Steering speed Steering speed was more than the specified value in evasive direction
End by yaw angle Yaw angle was the end of LDP control
Departure yaw large Detected more than the specified value of yaw angle in departure direction
ICC WARNING Target approach warning of ICC system, IBA system or FCW system was activated
CURVATURE Road curve was more than the specified value
Steering angle large Steering angle was more than the specified value
Brake is operated Brake pedal was operated
IGN LOW VOLT Decrease in ADAS control unit IGN voltage
Lateral offset Distance of vehicle and lane was detached in lateral direction more than the specified value
Lane marker lost Lane camera unit lost the trace of lane marker
Lane marker unclear Detected lane marker was unclear
Yaw acceleration Detected yawing speed was more than the specified value
Deceleration large Deceleration in a longitudinal direction was more than the specified value
Accel is operated Accelerator pedal was depressed
Departure steering Steering wheel was steered more than the specified value in departure direction
Evasive steering Steering wheel was steered more than the specified value in the evasive direction
R range Selector lever was operated to R range
Parking brake drift Rear wheels lock was detected
Not operating condition Did not meet the operating condition (vehicle speed, turn signal operation, etc)
SNOW MODE SW SNOW mo de switch was pressed
VDC OFF SW VDC OFF switch was pressed
OPE VDC/ABS 2 The activation of VDC or ABS duri ng a standby time of LDP system control
4WD LOCK MODE Shifting of the 4WD shift switch to 4H or 4L
NO RECORD —
Revision: 2010 May2011 QX56

CCS-34
< SYSTEM DESCRIPTION >[ICC]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
Monitored item
[Unit]
ALL SIG(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
MAIN SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
SET/COAST SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CANCEL SW
[On/Off] ××
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
RESUME/ACC SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DISTANCE SW
[On/Off] × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CRUISE OPE
[On/Off] ××
Indicates whether controlling or not (ON means “controlling”)
BRAKE SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC brake switch signal (ECM transmits
ICC brake switch signal through CAN communication)
STOP LAMP SW
[On/Off] ×× × × Indicates [On/Off] status as judged from stop lamp switch signal (ECM transmits
stop lamp switch signal through CAN communication)
IDLE SW
[On/Off] ×
Indicates [On/Off] status of idle switch read from ADAS control unit through CAN
communication (ECM transmits On/Off status through CAN communication)
SET DISTANCE
[Short/Mid/Long] ××
Indicates set distance memorized in ADAS control unit
CRUISE LAMP
[On/Off] ××
Indicates [On/Off] status of MAIN switch indicator output
OWN VHCL
[On/Off] ×
Indicates [On/Off] status of own vehicle indicator output
VHCL AHEAD
[On/Off] ×
Indicates [On/Off] status of vehicle ahead detection indicator output
ICC WARNING
[On/Off] ×
Indicates [On/Off] status of ICC system warning lamp output
VHCL SPEED SE
[km/h] or [mph] ×× × × Indicates vehicle speed calculated from ADAS control unit through CAN commu-
nication [ABS actuator and electric unit (c
ontrol unit) transmits vehicle speed sig-
nal (wheel speed) through CAN communication]
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ADAS control unit
BUZZER O/P
[On/Off] ×
Indicates [On/Off] status of ICC warning chime output
THRTL SENSOR
[deg] ××
NOTE:
The item is displayed, but it is not monitored
ENGINE RPM
[rpm] × Indicates engine speed read from ADAS control unit through CAN communication
(ECM transmits engine speed signal through CAN communication)
WIPER SW
[OFF/LOW/HIGH] × Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request sig-
nal through CAN communication)
YAW R AT E
[deg/s] ×
NOTE:
The item is displayed, but it is not monitored
BA WARNING
[On/Off] ×
Indicates [On/Off] status of IBA OFF indicator lamp output
STP LMP DRIVE
[On/Off] ××
Indicates [On/Off] status of ICC brake hold relay drive output
D RANGE SW
[On/Off] × Indicates [On/Off] status of “D” or “M” positions read from ADAS control unit
through CAN communication; ON when position “D” or “M” (TCM transmits shift
position signal through CAN communication).
Revision: 2010 May2011 QX56

CCS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
CCS-35
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
NP RANGE SW
[On/Off] × Indicates shift position signal read from ADAS control unit through CAN commu-
nication (TCM transmits shift position signal through CAN communication)
PKB SW
[On/Off] × Parking brake switch status [On/Off] judged from the parking brake switch signal
that ADAS control unit readout via CAN communication is displayed (Combination
meter transmits the parking brake switch signal via CAN communication)
PWR SUP MONI
[V] ××
Indicates IGN voltage input by ADAS control unit
VHCL SPD AT
[km/h] or [mph] × Indicates vehicle speed calculated from A/T vehicle speed sensor read from
ADAS control unit through CAN communication (TCM transmits A/T vehicle speed
sensor signal through CAN communication)
THRTL OPENING
[%] ×× Indicates throttle position read from ADAS control unit through CAN communica-
tion (ECM transmits accelerator pedal position signal through CAN communica-
tion).
GEAR
[1, 2, 3, 4, 5, 6, 7] × Indicates A/T gear position read from ADAS control unit through CAN communi-
cation (TCM transmits current gear position signal through CAN communication)
MODE SIG
[OFF, ICC, ASCD] × Indicates the active mode from ICC or ASCD [conventional (fixed speed) cruise
control mode]
SET DISP IND
[On/Off] ×
Indicates [On/Off] status of SET switch indicator output
DISTANCE
[m] ×
Indicates the distance from the vehicle ahead
RELATIVE SPD
[m/s] ×
Indicates the relative speed of the vehicle ahead
DYNA ASIST SW
[On/Off] ×× ×
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DCA ON IND
[On/Off] ×
The status [ON/OFF] of DCA system switch indicator output is displayed
DCA VHL AHED
[On/Off] × The status [ON/OFF] of vehicle ahead detection indicator output in DCA system
is displayed
IBA SW
[On/Off] ××
Indicates [On/Off] status of IBA OFF switch
FCW SYSTEM ON
[On/Off] ××
Indicates [On/Off] status of FCW system
APA TEMP
[ ° C] × Accelerator pedal actuator integrated motor temperature that the ADAS control
unit readout via ITS communication is displayed (Accelerator pedal actuator trans-
mits the integrated motor temperature via ITS communication)
APA PWR
[V] × Accelerator pedal actuator power supply voltage that the ADAS control unit read-
out via ITS communication is displayed (Accelerator pedal actuator transmits the
power supply voltage via ITS communication)
LDW SYSTEM ON
[On/Off] ×
Indicates [On/Off] status of LDW system
LDW ON LAMP
[On/Off] ×
Indicates [On/Off] status of waning systems ON indicator output
LDP ON IND
[On/Off] ×
Indicates [On/Off] status of LDP ON indicator lamp (Green) output
LANE DPRT W/L
[On/Off] ×
Indicates [On/Off] status of lane departure warning lamp (Yellow) output
LDW BUZER OUT-
PUT
[On/Off] ×
Indicates [On/Off] status of warning buzzer output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56

CCS
ADAS CONTROL UNITCCS-43
< ECU DIAGNOSIS INFORMATION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
ECU DIAGNOSIS INFORMATION
ADAS CONTROL UNIT
Reference ValueINFOID:0000000006227985
VALUES ON THE DIAGNOSIS TOOL
Monitor item Condition Value/Status
MAIN SW Ignition switch ON When MAIN switch is pressed On
When MAIN switch is not pressed Off
SET/COAST SW Ignition switch ON When SET/COAST switch is pressed On
When SET/COAST switch is not pressed Off
CANCEL SW Ignition switch ON When CANCEL switch is pressed On
When CANCEL switch is not pressed Off
RESUME/ACC SW Ignition switch ON When RESUME/ACCELERATE
switch is pressed On
When RESUME/ACCELERATE switch is not pressed Off
DISTANCE SW Ignition switch ON When DISTANCE swit
ch is pressed On
When DISTANCE switch is not pressed Off
CRUISE OPE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC system is controlling On
When ICC system is not controlling Off
BRAKE SW Ignition switch ON When brake pedal is depressed Off
When brake pedal is not depressed On
STOP LAMP SW Ignition switch ON When brake pedal is depressed On
When brake pedal is not depressed Off
IDLE SW Engine running Idling On
Except idling (depress accelerator pedal) Off
SET DISTANCE  Start the engine and turn the
ICC system ON
 Press the DISTANCE switch to change the vehi-
cle-to-vehicle distance set-
ting When set to “long” Long
When set to “middle” Mid
When set to “short” Short
CRUISE LAMP Start the engine and press
MAIN switch ICC system ON
(MAIN switch indicator ON)
On
ICC system OFF
(MAIN switch indicator OFF) Off
OWN VHCL Start the engine and press
MAIN switch ICC system ON
(Own vehicle indicator ON)
On
ICC system OFF
(Own vehicle indicator OFF) Off
VHCL AHEAD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected (vehicle ahead de-
tection indicator ON)
On
When a vehicle ahead is not detected (vehicle ahead
detection indicator OFF) Off
ICC WARNING Start the engine and press
MAIN switch When ICC system is malfunctioning
(ICC system warning lamp ON)
On
When ICC system is normal
(ICC system warning lamp OFF) Off
Revision: 2010 May2011 QX56
