Component DescriptionINFOID:0000000006223499
Component Description
ADAS control unit  ADAS control unit calculates a target distance between vehicles and a target speed,
based on signals received from each sensor and switch to transmit a brake fluid pres-
sure control signal to ABS actu ator and electric unit (control unit) via CAN communica-
tion
 ADAS control unit transmits the buzzer output signal to the combination meter via CAN communication
 ADAS control unit transmits an accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS communication
ICC sensor  ICC sensor detects light reflected from a vehicle ahead by irradiating laser forward and
calculates a distance from the vehicle ahead and a relative speed, based on the detect-
ed signal
 ICC sensor transmits the presence/absence of vehicle ahead and the distance from the vehicle to ADAS control unit via ITS communication
ECM ECM transmits the accelerator pedal position signal, ICC brake switch signal, stop lamp
switch signal, ICC steering switch signal, etc. to ADAS control unit via CAN communica-
tion
ABS actuator and electric unit (control
unit)  ABS actuator and electric unit (control unit
) transmits the vehicle speed signal (wheel
speed), stop lamp signal and VDC/TCS/ABS system operat ion condition to ADAS con-
trol unit via CAN communication
 ABS actuator and electric unit (control unit ) controls the brake, based on a brake fluid
pressure control signal received from ADAS control unit via CAN communication
TCM TCM transmits the signal related to A/T control to ADAS control unit via CAN communi-
cation
Combination meter Performs the following operations using the signals received from the ADAS control unit
via the CAN communication
 Displays the DCA system operation status using the meter display signal
 Illuminates the ICC system warning lamp using the ICC warning lamp signal
 Operates the buzzer (ICC warning chime) using the buzzer output signal
Dynamic driver assistance switch
(On the ICC steering switch) ECM receives an ICC steering switch (dynamic driver assistance switch) signal and trans-
mits the signal to ADAS control unit via CAN communication
ICC brake hold relay ICC brake hold relay activates the stop lamp by ICC brake hold relay drive signal (stop
lamp drive signal) outputted by the ADAS control unit
ICC brake switch  ICC brake switch is turned OFF and stop lamp switch is turned ON, when depressing the brake pedal
 ICC brake switch signal is input to ECM. These signals are transmitted from ECM to ADAS control unit via CAN communication
 Stop lamp switch signal is input to ECM and ABS actuator and electric unit (control unit). These signals are transmitted from ECM and ABS actuator and electric unit (control
unit) to ADAS control unit via CAN communication
Stop lamp switch
Transfer control unit
Transfer control unit transmits a mode selection state of 4WD shift switch to the ADAS
control unit via CAN communication
AV control unit AV control unit transmits the system selection signal to the ADAS control unit via CAN
communication
Steering angle sensor Measures the rotation amount, rotation speed, and rotation direction of steering wheel,
and then transmits them to ADAS control unit via CAN communication
Accelerator pedal actuator Accelerator pedal actuator receives an accelerator pedal feedback force control signal
from the ADAS control unit via ITS communication and pushes back the accelerator pedal
Revision: 2010 May2011 QX56

DAS
SYSTEMDAS-69
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Output Signal Item
Transmit unit Signal name Description
ECM CAN com-
munica-
tionClosed throttle position signal Receives idle position state (ON/OFF)
Accelerator pedal position signal Receives accelerator pedal position (angle)
ICC steering switch
signal
Dynamic driver as-
sistance switch sig-
nal Receives the operational state of the ICC steering
switch
Engine speed signal Receives engine speed
Stop lamp switch signal Receives an operational state of the brake pedal
Snow mode signal Receives an operational state of the snow mode
TCM CAN com-
munica-
tionInput speed signal Receives the number of revolutions of input shaft
Current gear position signal Receives a current gear position
Shift position signal Receives a selector lever position
Output shaft revolution signal Receives the number of revolutions of output shaft
ABS actuator
and electric unit
(control unit) CAN com-
munica-
tionABS malfunction signal Receives
a malfunction state of ABS
ABS operation signal Receives an operational state of ABS
ABS warning lamp signal Receives an ON/OFF state of ABS warning lamp
TCS malfunction signal Receives a malfunction state of TCS
TCS operation signal Receives an operational state of TCS
VDC OFF switch signal Receives an ON/OFF state of VDC
VDC malfunction signal Receives a malfunction state of VDC
VDC operation signal Receives an operational state of VDC
Vehicle speed signal (ABS) Receives wheel speeds of four wheels
Stop lamp switch signal Receives an operational state of the brake pedal
Yaw rate signal Receives yaw rate acting on the vehicle
Steering angle
sensor CAN com-
munica-
tionSteering angle sensor malfunction signal Receives a malfunction state of steering angle sensor
Steering angle sensor signal
Receives the number of revolutions, turning direction of
the steering wheel
Steering angle speed signal Receives the turning angle speed of the steering wheel
AV control unit CAN com-
munica-
tionSystem selection signal
Receives a selection state of each item in “Driver As-
sist” selected with the navigation system
Transfer control
unit CAN com-
munica-
tion
Current 4WD mode signal Receives a mode selection state of the 4WD shift mode
ICC sensor ITS com-
munica-
tion
ICC sensor signal
Receives detection results, such as the presence or ab-
sence of a vehicle ahead and distance from the vehicle
Accelerator
pedal actuator ITS com-
munica-
tionAccelerator pedal actuator operation status
signal
Receives an operational state of accelerator pedal ac-
tuator
Reception unit Signal name Description
ABS actuator
and electric
unit (control
unit) CAN commu-
nication
Brake fluid pressure control signal Transmits a brake fluid pressure control signal to acti-
vates the brake
Revision: 2010 May2011 QX56

DAS-70
< SYSTEM DESCRIPTION >[DCA]
SYSTEM
FUNCTION DESCRIPTION
When a vehicle is detected ahead The vehicle ahead detection indicator comes ON.
When vehicle approaches a vehicle ahead If the driver is not depressing the accelerator pedal, t
he system activates the brakes to decelerate smoothly
as necessary. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limita-
tions of the system.
 If the driver is depressing the accelerator pedal, the system moves the accelerator pedal upward to assist
the driver to release the accelerator pedal.
When brake operation by driver is required The system alerts the driver by a warning chime and blinking the vehicle ahead detection indicator. If the
driver is depressing the accelerator pedal after the wa rning, the system moves the accelerator pedal upward
to assist the driver to switch to the brake pedal.
CAUTION:
If the vehicle ahead comes to a stan dstill, the vehicle decelerates to a standstill within the limitations
of the system. The system will release brake control wi th a warning chime once it judges the vehicle is
at a standstill. To prevent the vehicle from moving , the driver must depress the brake pedal. [The sys-
tem will resume control automatically once the system reaches 5 km/h (3 MPH)].
NOTE:
 Depending on the position of the accelerator pedal, the system may not be able to assist the driver to
release the accelerator pedal appropriately.
 When the driver depresses the accelerator pedal even further while the system is moving the acce\
lerator pedal upward, the accelerator pedal control will be canceled.
 When the driver is depressing the accelerator pedal, the brake control by the system is not operated.
 When the driver is depressing the brake pedal, neither the brake control nor the alert by the system oper-
ates.
 When the ICC system is set, the DCA system will be canceled.
OPERATION DESCRIPTION
ICC sensor calculates a distance from a vehicle ahead and a relative speed to transmit the ICC sensor signal
to the ADAS control unit via ITS communication. Based on the received signal, the ADAS control unit trans-
mits a control signal to the accelerator pedal actuator via ITS communication and to the ABS actuator control
unit (control unit) via CAN communication.
Combination
meter CAN commu-
nicationMeter display
signal
Vehicle ahead detec-
tion indicator signal
Transmits a signal to display a state of the system on
the information display
DCA system switch in-
dicator signal
ICC warning lamp signal Transmits an ICC warning lamp signal to turn ON the
ICC system warning lamp
Buzzer output signal Transmits a buzzer output signal to activate the buzz-
er
ICC sensor ITS commu-
nicationVehicle speed signal
Transmits a vehicle speed calculated by the ADAS
control unit
Steering angle sensor signal Transmits a steering angle sensor signal received
from the steering angle sensor
Accelerator
pedal actuator ITS commu-
nicationAccelerator pedal position signal
Transmits an accelerator pedal angle calculated by
the ADAS control unit
Accelerator pedal feedback force control
signal Transmits a target actuation force value calculated by
the ADAS control unit
ICC brake hold
relay ICC brake hold relay drive signal
Activates the brake hold relay and turns ON the stop
lamp
Reception unit Signal name Description
Revision: 2010 May2011 QX56

DAS
OPERATIONDAS-73
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
OPERATION
Switch Name and FunctionINFOID:0000000006223503
Menu Displayed by Pressing Each SwitchINFOID:0000000006223504
SYSTEM DISPLAY
DISPLAY AND WARNING LAMP
System Control Condition Display
The DCA system switch indicator illuminates and the system is turned ON by pressing the dynamic driver
assistance switch at the system OFF.
JSOIA0365ZZ
No. Switch name Description
1 Dynamic driver assistance switch Turns the DCA system ON/OFF
(When the setting of the DCA system on the navigation screen is ON)
2 DCA system setting screen
(Navigation system settings screen) DCA system settings can be switched between ON and OFF
JSOIA0175ZZ
No. Switch name Description
1 ICC system warning lamp This indicates that an abnormal condition is present in DCA system
2 DCA system switch indicator Indicates that DCA system is ON
3 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead
NOTE:
The vehicle ahead detection indicator turns OFF when the no operation condition is sat-
isfied
Revision: 2010 May2011 QX56

DAS-74
< SYSTEM DESCRIPTION >[DCA]
OPERATION
Approach Warning Display
 If own vehicle comes closer to the vehicle ahead due to r
apid deceleration of that vehicle or if another vehi-
cle cuts in, the system warns the driver with the chime and DCA system display. Decelerate by depressing
the brake pedal to maintain a safe vehicle distance if:
- The chime sounds.
- The vehicle ahead detection indicator blinks.
 The warning chime may not sound in some cases when there is a short distance between vehicles. Some examples are:
- When the vehicles are traveling at the same s peed and the distance between vehicles is not changing
- When the vehicle ahead is traveling faster and the distance between vehicles is increasing
- When a vehicle cuts in near own vehicle
 The warning chime will not sound when own vehicle approaches vehicles that are parked or moving slowly.
Warning Lamp Display
Condition Display on combination meter
Operation status Vehicle ahead not detected
Vehicle ahead detected
JSOIA0207ZZ
JSOIA0208ZZ
Condition Display on combination meter
When the system judges that the brake operation by the driver is necessary
JSOIA0209ZZ
Revision: 2010 May2011 QX56

DAS
OPERATIONDAS-75
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
NOTE:
When the DCA system is automatic ally canceled, the cancellation condition can be displayed on “WORK
SUPPORT” of CONSULT-III (ICC/ADAS).
Condition Description Display on combination meter
Warning display When the dynamic driver assistance
switch is turned ON with settings of
DCA system and LDP system OFF
The DCA system is not activated. The DCA
system switch indicator blinks.
 When the VDC or ABS (including the TCS) operates
 When the VDC is turned OFF
 When the SNOW mode switch is turned ON
 When the 4WD shift switch is turned to not AUTO
 When driving into a strong light (i.e., sunlight) The DCA system is automatically can-
celed. The chime will sound and the DCA
system switch indicator will blink.
NOTE:
The system operates if the dynamic driver
assistance switch is turned OFF
⇒ON after
the condition improves.
When the sensor window is dirty, mak-
ing it impossible to detect a vehicle
ahead The DCA system is automatically can-
celed. The chime sounds and the ICC sys-
tem warning lamp will come on and the
“CLEAN SENSOR” indicator will appear.
NOTE:
Stop the vehicle in a safe location and turn
the ignition switch OFF. Clean the dirty
area with soft cloth. The system returns to
normal condition when turning the ignition
switch ON again.
When the DCA system is not operating
properly The chime sounds and the ICC system
warning lamp will come on.
NOTE:
Turn the ignition switch OFF, and then turn
the ignition switch ON again. If there is no
malfunction, the system returns to the nor-
mal condition.
JSOIA0210ZZ
JSOIA0326ZZ
JSOIA0212ZZ
Revision: 2010 May2011 QX56

DAS
HANDLING PRECAUTIONDAS-77
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
 The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate.
- A vehicle ahead may move outside of the detection zone due to its
position within the same lane of travel. Motorcycles may not be
detected in the same lane ahead if they are traveling offset from
the center line of the lane. A vehicle that is entering the lane ahead
may not be detected until the vehicle has completely moved into
the lane. If this occurs, the system may warn driver by blinking the
system indicator and sounding the chime. The driver may have to
manually control the proper distance away from vehicle traveling
ahead.
- When driving on some roads, such as winding, hilly, curved, nar- row roads, or roads which are under construction, the sensor may
detect vehicles in a different lane, or may temporarily not detect a
vehicle traveling ahead. This may cause the system to work inap-
propriately. The detection of vehicles may also be affected by vehi-
cle operation (steering maneuver or traveling position in the lane,
etc.) or vehicle condition. If this occurs, the system may warn
driver by blinking the system indicator and sounding the chime
unexpectedly. The driver will have to manually control the proper
distance away from the vehicle traveling ahead.
 The approach warning chime may sound and the system display may blink when the sensor detects some reflectors which are fitted
on vehicles in other lanes or on the side of the road. This may
cause the DCA system to operate inappropriately. The sensor may
detect these reflectors when the vehicle is driven on winding
roads, hilly roads or when entering or exiting a curve. The sensor
may also detect reflectors on narrow roads or in road construction
zones. In these cases driver will have to manually control the
proper distance ahead of own vehicle. Also, the sensor sensitivity
can be affected by vehicle operation (steering maneuver or driving
position in the lane) or traffic or vehicle condition (for example, if a
vehicle is being driven with some damage).
 The DCA system automatically dec elerates own vehicle to help
assist the driver to maintain a following distance from the vehicle
ahead. Manually brake when deceleration is required to maintain a safe distance upon sudden braking by
the vehicle ahead or when a vehicle suddenly appears in front of own vehicle. Always stay alert when using
the DCA system.
 When the vehicle ahead detection indicator lamp is not illum inated, system will not control or warn the driver.
 Never place a foot under the brake pedal. A foot may be caught when the system controls the brake.
 Depending on the position of the accelerator pedal, the system may not be able to assist the driver to
release the accelerator pedal appropriately.
 If the vehicle ahead comes to a standstill, the vehicle decel erates to a standstill within the limitations of the
system. The system will rel ease brake control with a warning chime once it judges the vehicle is at a stand-
still. To prevent the vehicle from moving, the driv er must depress the brake pedal. [The system will resume
control automatically once the system reaches 5 km/h (3 MPH)].
JPOIA0221ZZ
JPOIA0220ZZ
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-81
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Display Items for The Cause of Automatic Cancellation 2
SELF DIAGNOSTIC RESULT
Refer to DAS-38, "DTC Index".
DATA MONITOR
INCHING LOST ×A vehicle ahead is not detected during the following driving when
the vehicle speed is approximately 24 km/h (15 MPH) or less
CAN COMM ERROR ×××ADAS control unit received an abnormal signal with CAN commu-
nication
ABS/TCS/VDC CIRC ×××An abnormal condition occurs in VDC/TCS/ABS system
ECD CIRCUIT ×××An abnormal condition occurs in ECD system
ASCD VHCL SPD DTAC ×Vehicle speed is detached from set vehicle speed
ASCD DOUBLE COMD ×Cancel switch and operation switch are detected simultaneously
APA HI TEMP ×The accelerator pedal actuator integrated motor temperature is
high
ICC SENSOR CAN
COMM ERR ××Communication error between ADAS control unit and the ICC sen-
sor
4WD LOCK MODE ×××Shifting of the 4WD shift switch to 4H or 4L
ABS WARNING LAMP ××ABS warning lamp ON
NO RECORD ××× —
Cause of cancellation Description
OPE VDC/TCS/ABS 1 The activation of VDC, TCS, or ABS during LDP system control
Vehicle dynamics Vehicle behavior exceeds specified value
Steering speed Steering speed was more than the specified value in evasive direction
End by yaw angle Yaw angle was the end of LDP control
Departure yaw large Detected more than the specified value of yaw angle in departure direction
ICC WARNING Target approach warning of ICC system, IBA system or FCW system was activated
CURVATURE Road curve was more than the specified value
Steering angle large Steering angle was more than the specified value
Brake is operated Brake pedal was operated
IGN LOW VOLT Decrease in ADAS control unit IGN voltage
Lateral offset Distance of vehicle and lane was detached in lateral direction more than the specified value
Lane marker lost Lane camera unit lost the trace of lane marker
Lane marker unclear Detected lane marker was unclear
Yaw acceleration Detected yawing speed was more than the specified value
Deceleration large Deceleration in a longitudinal direction was more than the specified value
Accel is operated Accelerator pedal was depressed
Departure steering Steering wheel was steered more than the specified value in departure direction
Evasive steering Steering wheel was steered more than the specified value in the evasive direction
R range Selector lever was operated to R range
Parking brake drift Rear wheels lock was detected
Not operating condition Did not meet the operating condition (vehicle speed, turn signal operation, etc)
SNOW MODE SW SNOW mo de switch was pressed
VDC OFF SW VDC OFF switch was pressed
OPE VDC/ABS 2 The activation of VDC or ABS duri ng a standby time of LDP system control
4WD LOCK MODE Shifting of the 4WD shift switch to 4H or 4L
NO RECORD —
Revision: 2010 May2011 QX56

DAS-82
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
Monitored item
[Unit]
ALL SIG(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
MAIN SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
SET/COAST SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CANCEL SW
[On/Off] ××
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
RESUME/ACC SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DISTANCE SW
[On/Off] × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CRUISE OPE
[On/Off] ××
Indicates whether controlling or not (ON means “controlling”)
BRAKE SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC brake switch signal (ECM transmits
ICC brake switch signal through CAN communication)
STOP LAMP SW
[On/Off] ×× × × Indicates [On/Off] status as judged from stop lamp switch signal (ECM transmits
stop lamp switch signal through CAN communication)
IDLE SW
[On/Off] ×
Indicates [On/Off] status of idle switch read from ADAS control unit through CAN
communication (ECM transmits On/Off status through CAN communication)
SET DISTANCE
[Short/Mid/Long] ××
Indicates set distance memorized in ADAS control unit
CRUISE LAMP
[On/Off] ××
Indicates [On/Off] status of MAIN switch indicator output
OWN VHCL
[On/Off] ×
Indicates [On/Off] status of own vehicle indicator output
VHCL AHEAD
[On/Off] ×
Indicates [On/Off] status of vehicle ahead detection indicator output
ICC WARNING
[On/Off] ×
Indicates [On/Off] status of ICC system warning lamp output
VHCL SPEED SE
[km/h] or [mph] ×× × × Indicates vehicle speed calculated from ADAS control unit through CAN commu-
nication [ABS actuator and electric unit (c
ontrol unit) transmits vehicle speed sig-
nal (wheel speed) through CAN communication]
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ADAS control unit
BUZZER O/P
[On/Off] ×
Indicates [On/Off] status of ICC warning chime output
THRTL SENSOR
[deg] ××
NOTE:
The item is displayed, but it is not monitored
ENGINE RPM
[rpm] × Indicates engine speed read from ADAS control unit through CAN communication
(ECM transmits engine speed signal through CAN communication)
WIPER SW
[OFF/LOW/HIGH] × Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request sig-
nal through CAN communication)
YAW R AT E
[deg/s] ×
NOTE:
The item is displayed, but it is not monitored
BA WARNING
[On/Off] ×
Indicates [On/Off] status of IBA OFF indicator lamp output
STP LMP DRIVE
[On/Off] ××
Indicates [On/Off] status of ICC brake hold relay drive output
D RANGE SW
[On/Off] × Indicates [On/Off] status of “D” or “M” positions read from ADAS control unit
through CAN communication; ON when position “D” or “M” (TCM transmits shift
position signal through CAN communication).
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-83
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
NP RANGE SW
[On/Off] × Indicates shift position signal read from ADAS control unit through CAN commu-
nication (TCM transmits shift position signal through CAN communication)
PKB SW
[On/Off] × Parking brake switch status [On/Off] judged from the parking brake switch signal
that ADAS control unit readout via CAN communication is displayed (Combination
meter transmits the parking brake switch signal via CAN communication)
PWR SUP MONI
[V] ××
Indicates IGN voltage input by ADAS control unit
VHCL SPD AT
[km/h] or [mph] × Indicates vehicle speed calculated from A/T vehicle speed sensor read from
ADAS control unit through CAN communication (TCM transmits A/T vehicle speed
sensor signal through CAN communication)
THRTL OPENING
[%] ×× Indicates throttle position read from ADAS control unit through CAN communica-
tion (ECM transmits accelerator pedal position signal through CAN communica-
tion).
GEAR
[1, 2, 3, 4, 5, 6, 7] × Indicates A/T gear position read from ADAS control unit through CAN communi-
cation (TCM transmits current gear position signal through CAN communication)
MODE SIG
[OFF, ICC, ASCD] × Indicates the active mode from ICC or ASCD [conventional (fixed speed) cruise
control mode]
SET DISP IND
[On/Off] ×
Indicates [On/Off] status of SET switch indicator output
DISTANCE
[m] ×
Indicates the distance from the vehicle ahead
RELATIVE SPD
[m/s] ×
Indicates the relative speed of the vehicle ahead
DYNA ASIST SW
[On/Off] ×× ×
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DCA ON IND
[On/Off] ×
The status [ON/OFF] of DCA system switch indicator output is displayed
DCA VHL AHED
[On/Off] × The status [ON/OFF] of vehicle ahead detection indicator output in DCA system
is displayed
IBA SW
[On/Off] ××
Indicates [On/Off] status of IBA OFF switch
FCW SYSTEM ON
[On/Off] ××
Indicates [On/Off] status of FCW system
APA TEMP
[ ° C] × Accelerator pedal actuator integrated motor temperature that the ADAS control
unit readout via ITS communication is displayed (Accelerator pedal actuator trans-
mits the integrated motor temperature via ITS communication)
APA PWR
[V] × Accelerator pedal actuator power supply voltage that the ADAS control unit read-
out via ITS communication is displayed (Accelerator pedal actuator transmits the
power supply voltage via ITS communication)
LDW SYSTEM ON
[On/Off] ×
Indicates [On/Off] status of LDW system
LDW ON LAMP
[On/Off] ×
Indicates [On/Off] status of waning systems ON indicator output
LDP ON IND
[On/Off] ×
Indicates [On/Off] status of LDP ON indicator lamp (Green) output
LANE DPRT W/L
[On/Off] ×
Indicates [On/Off] status of lane departure warning lamp (Yellow) output
LDW BUZER OUT-
PUT
[On/Off] ×
Indicates [On/Off] status of warning buzzer output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56
