INFINITI QX56 2011 Factory Service Manual
Manufacturer: INFINITI, Model Year: 2011, Model line: QX56, Model: INFINITI QX56 2011Pages: 5598, PDF Size: 94.53 MB
Page 3341 of 5598

INL-74
< REMOVAL AND INSTALLATION >
STEP LAMP
STEP LAMP
Exploded ViewINFOID:0000000006288655
Removal and InstallationINFOID:0000000006288656
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long ti me because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
REMOVAL
1. Insert any appropriate tool into the gap between the step lamp and door finisher.
2. Disconnect the step lamp harness connector, and then remove the step lamp.
INSTALLATION
Install in the reverse order of removal.
ReplacementINFOID:0000000006288657
STEP LAMP BULB
1. Remove the step lamp.
2. Remove the lens.
3. Remove the bulb.
1. Step lamp housing 2. Bulb 3. Lens
: Pawl
: Metal clip
JMLIA0541ZZ
Revision: 2010 May2011 QX56
Page 3342 of 5598

MOOD LAMPINL-75
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
MOOD LAMP
FRONT DOOR ARMREST
FRONT DOOR ARMREST : Exploded ViewINFOID:0000000006288658
FRONT DOOR ARMREST : ReplacementINFOID:0000000006288659
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
MOOD LAMP
1. Remove front door finisher. Refer to INT-14, "Removal and Installation".
2. Remove the mood lamp from front door finisher.
REAR DOOR ARMREST
REAR DOOR ARMREST : Exploded ViewINFOID:0000000006288660
1. Mood lamp
JMLIA1054ZZ
1. Mood lamp
JMLIA1055ZZ
Revision: 2010 May2011 QX56
Page 3343 of 5598

INL-76
< REMOVAL AND INSTALLATION >
MOOD LAMP
REAR DOOR ARMREST : Replacement
INFOID:0000000006288661
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long ti me because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
MOOD LAMP
1. Remove rear door finisher. Refer to INT-14, "Removal and Installation".
2. Remove the mood lamp from rear door finisher.
Revision: 2010 May2011 QX56
Page 3344 of 5598

PERSONAL LAMPINL-77
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
PERSONAL LAMP
Exploded ViewINFOID:0000000006288662
Removal and InstallationINFOID:0000000006288663
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
Replace the personal lamp case as a set (LH a nd RH). After removing the headlining assembly,
remove the personal lamp case.
REMOVAL
1. Remove headlining assembly. Refer to INT-29, "Removal and Installation".
1. Personal lamp case 2. Bulb 3. Lens
4. Personal lamp finisher
: Pawl
JMLIA1053ZZ
Revision: 2010 May2011 QX56
Page 3345 of 5598

INL-78
< REMOVAL AND INSTALLATION >
PERSONAL LAMP
2. Press the pawls (B) on both sides as shown in the figure using asmall flat-bladed screwdriver (A), and then pull out personal
lamp case (2) from personal lamp finisher (1).
INSTALLATION
Install in the reverse order of removal.
ReplacementINFOID:0000000006288664
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
Never touch the glass of bu lb directly by hand. Keep grease an d other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
Never leave bulb out of lamp reflector for a long ti me because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
PERSONAL LAMP BULB
1. Insert any appropriate tool into the gap between the lens, and then remove the lens.
2. Remove the bulb.
JMLIA1058ZZ
Revision: 2010 May2011 QX56
Page 3346 of 5598

PUDDLE LAMPINL-79
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
PUDDLE LAMP
Exploded ViewINFOID:0000000006288665
Removal and InstallationINFOID:0000000006288666
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch puddle lamp directly by hand. Keep grease and other oily substaces away from it.
Never touch puddle lamp by hand while it is lit or right after it is off.
It is prohibited to disassemble puddle lamp.
Always replace puddle lamp as an assembly, when replacing.
REMOVAL
1. Remove door mirror assembly. Refer to MIR-32, "DOOR MIRROR ASSEMBLY : Removal and Installa-
tion".
2. Disconnect puddle lamp harness connector te rminal from door mirror harness connector.
3. Disengage base cover fixing pawls using a small flat-bladed screwdriver (A), and then remove base cover.
CAUTION:
Apply protective tape (B) around the base to protect thesurface from damage.
Apply protective tape to small flat-bladed screwdriver.
1. Door mirror assembly 2. Puddle lamp 3. Base cover
: Pawl
JMLIA1148ZZ
: Pawl
JMLIA0922ZZ
Revision: 2010 May2011 QX56
Page 3347 of 5598

INL-80
< REMOVAL AND INSTALLATION >
PUDDLE LAMP
4. Disengage puddle lamp fixing pawls, and then remove puddlelamp (1) from base cover (2).
INSTALLATION
Install in the reverse order of removal.
: Pawl
JMLIA1283ZZ
Revision: 2010 May2011 QX56
Page 3348 of 5598

LUGGAGE ROOM LAMPINL-81
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
LUGGAGE ROOM LAMP
Exploded ViewINFOID:0000000006288667
Removal and InstallationINFOID:0000000006288668
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
REMOVAL
1. Insert any appropriate tool into the gap betw een lens and roof garnish, and then remove lens.
2. Disengage luggage room lamp housing fixing metal clips, and then disconnect luggage room lamp har- ness connector.
3. Remove luggage room lamp housing.
INSTALLATION
Install in the reverse order of removal.
ReplacementINFOID:0000000006288669
CAUTION:
Disconnect the battery cable from negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it.
Never touch bulb by hand while it is lit or right after it is off.
Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bu lb, be sure to replace it with a new one.
LUGGAGE ROOM LAMP BULB
1. Insert any appropriate tool into the gap between lens and roof garnish, and then remove the lens.
2. Remove bulb.
1. Lens 2. Bulb 3. Luggage room lamp housing
4. Roof garnish
: Pawl
: Vehicle front
JMLIA1056ZZ
Revision: 2010 May2011 QX56
Page 3349 of 5598

INL-82
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:0000000006288670
Item Type Wattage (W)
Push-button ignition switch illumination LED —
Map lamp Wedge 8
Console lamp
(integrated into the map lamp assembly) LED —
Puddle lamp LED —
Vanity mirror lamp — 2
Glove box lamp Wedge 1.4
Foot lamp (driver and passenger) Wedge 1.4
Rear foot lamp LED —
Mood lamp (front and rear door armrest) LED —
Ste p lam p We dg e 8
Personal lamp Wedge 8
Luggage room lamp — 8
Revision: 2010 May2011 QX56
Page 3350 of 5598

INT-1
BODY INTERIOR
C
DE
F
G H
I
K L
M
SECTION INT
A
B
INT
N
O P
CONTENTS
INTERIOR
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
3
Precaution for Procedure without Cowl Top Cover ......4
Precaution for Work ..................................................4
PREPARATION ............................................5
PREPARATION .............................................. .....5
Special Service Tools .......................................... ......5
Commercial Service Tools ........................................5
CLIP LIST ............................................................6
Clip List ............................................................... ......6
SYMPTOM DIAGNOSIS ...............................7
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ........................ ........................................
7
Work Flow ........................................................... ......7
Inspection Procedure ................................................9
Diagnostic Worksheet .............................................11
REMOVAL AND INSTALLATION ...............13
FRONT DOOR FINISHER .............................. ....13
Exploded View .................................................... ....13
Removal and Installation .........................................14
REAR DOOR FINISHER ....................................16
Exploded View .................................................... ....16
Removal and Installation .........................................16
BODY SIDE TRIM ..............................................18
Exploded View .................................................... ....18
DASH SIDE FINISHER .......................................... ....18
DASH SIDE FINISHER : Removal and Installation
....
18
FRONT PILLAR GARNISH .................................... ....19
FRONT PILLAR GARNISH : Removal and Instal-
lation ........................................................................
19
BODY SIDE WELT ................................................. ....20
BODY SIDE WELT : Removal and Installation ........20
KICKING PLATE INNER ....................................... ....20
KICKING PLATE INNER : Removal and Installa-
tion ...........................................................................
20
KICKING PLATE OUTER ...................................... ....21
KICKING PLATE OUTER : Removal and Installa-
tion ...........................................................................
21
CENTER PILLAR LOWER GARNISH ................... ....22
CENTER PILLAR LOWER GARNISH : Removal
and Installation ........................................................
22
CENTER PILLAR UPPER GARNISH ........................22
CENTER PILLAR UPPER GARNISH : Removal
and Installation .................................................... ....
22
FLOOR TRIM ....................................................24
Exploded View .........................................................24
FRONT FLOOR CARPET ...................................... ....25
FRONT FLOOR CARPET : Removal and Installa-
tion ....................................................................... ....
25
REAR FLOOR CARPET ........................................ ....27
REAR FLOOR CARPET : Removal and Installa-
tion ...........................................................................
27
HEADLINING ....................................................28
Exploded View .........................................................28
Removal and Installation .........................................29
LUGGAGE FLOOR TRIM .................................33
Exploded View .........................................................33
Revision: 2010 May2011 QX56
