INFINITI QX56 2011 Factory Service Manual

PWO-32
< SYMPTOM DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INDICATOR DOES NOT TURN ON
AC 120 V OUTLET MAIN SWITCH
INDICATOR DOES NOT TURN ON
Diagnosis ProcedureINFOID:0000000006257110
1.CHECK FAIL-SAFE ACTIVATION
Check if the symptom is caused by a fail-safe operation. Refer to PWO-17, "
Fail-safe".
Is fail-safe operating?
YES >> Repair the part causing fail-safe operation.
NO >> GO TO 2.
2.CHECK INVERTER UNIT POWER SUPPLY CIRCUIT
Check inverter unit power supply circuit. Refer to PWO-23, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK AC 120 V OUTLET MAIN SWITCH POWER SUPPLY CIRCUIT
Check AC 120 V outlet main switch power supply circuit. Refer to PWO-24, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK AC 120 V OUTLET MAIN SWITCH INPUT SIGNAL CIRCUIT
Check AC 120 V outlet main switch input signal circuit. Refer to PWO-25, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
Check AC 120 V outlet main switch indicator circuit. Refer to PWO-29, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: 2010 May2011 QX56

PWO
NORMAL OPERATING CONDITIONPWO-33
< SYMPTOM DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006257122
Because of modified sine wave output, the AC 120 V out
let may not operate normally for electric appliance of
which electric power consumption is 150 W or less.
 Electric appliances requiring a large amount of electr ic power consumption at startup (e.g. CRT-based TV,
power tool)
 Measuring instruments for data requiring accuracy (e.g. medical equipment, measuring instrument)
 Microprocessor-controlled appliances (e.g. microprocessor-controlled blanket)
Noise may be caused in radio or TV, depending on an electric appliance.
Revision: 2010 May2011 QX56

PWO-34
< REMOVAL AND INSTALLATION >[AC 120 V OUTLET]
INVERTER UNIT
REMOVAL AND INSTALLATION
INVERTER UNIT
Removal and InstallationINFOID:0000000006257131
REMOVAL
1. Remove console body assembly. Refer to
IP-23, "Exploded View".
2. Disconnect inverter unit connector.
3. Remove mounting bolt.
4. Remove inverter unit.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

PWO
AC 120V OUTLET MAIN SWPWO-35
< REMOVAL AND INSTALLATION > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120V OUTLET MAIN SW
Removal and InstallationINFOID:0000000006257132
REMOVAL
1. Remove console body assembly. Refer to
IP-23, "Exploded View".
2. Disengage pawl. Then remove AC 120 V outlet main switch from center console assembly.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

PWO-36
< REMOVAL AND INSTALLATION >[AC 120 V OUTLET]
AC 120 V OUTLET
AC 120 V OUTLET
Removal and InstallationINFOID:0000000006257133
REMOVAL
1. Remove console rear finisher. Refer to
IP-23, "Exploded View".
2. Push the pawl from the back of the console rear finisher to remove the AC 120 V outlet.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

PWO
SERVICE DATA AND SPECIFICATIONS (SDS)
PWO-37
< SERVICE DATA AND SPECIFICATIONS (SDS) [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
AC 120 V Power OutletINFOID:0000000006257135
Rated voltage AC 120 V
Maximum electric capacity 150 W or less (Total)
Maximum current 1.25 A or less (Total)
Revision: 2010 May2011 QX56

RAX-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION RAX
A
B
RAX
N
O P
CONTENTS
REAR AXLE
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precautions for Drive Shaft ................................. ......2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tools .......................................... ......3
Commercial Service Tools ........................................3
SYMPTOM DIAGNOSIS ...............................4
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ .....
4
NVH Troubleshooting Chart ................................ ......4
PERIODIC MAINTENANCE ..........................5
REAR WHEEL HUB AND HOUSING ............ .....5
Inspection ............................................................ ......5
REAR DRIVE SHAFT ..........................................6
Inspection ............................................................ ......6
REMOVAL AND INSTALLATION ................7
REAR WHEEL HUB AND HOUSING ................7
Exploded View ..................................................... .....7
Removal and Installation ..........................................7
Inspection .................................................................9
REAR DRIVE SHAFT ........................................11
Exploded View .........................................................11
Removal and Installation .........................................11
WHEEL SIDE ......................................................... ....12
WHEEL SIDE : Disassembly and Assembly ...........12
FINAL DRIVE SIDE ................................................ ....15
FINAL DRIVE SIDE : Disassembly and Assembly ....15
Inspection ................................................................16
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .............................................
18
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
18
Wheel Hub and Bearing Assembly ...................... ....18
Drive Shaft ...............................................................18
Revision: 2010 May2011 QX56

RAX-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precautions for Drive ShaftINFOID:0000000006225459
• Observe the following precautions when disassembling and assembling drive shaft.
- Never disassemble joint sub-assembly because it is non-overhaul parts.
- Perform work in a location which is as dust-free as possible.
- Clean the parts, before disassembling and assembling.
- Prevent the entry of foreign objects during disassembly of the service location.
- Reassemble disassembled parts carefully in the correct order. If work is interrupted, a clean cover must be placed over parts.
- Use paper waste. Do not use fabric shop clot hs because of the danger of lint adhering to parts.
- Clean disassembled parts (except for rubber parts) with kerosene which shall be removed by blowing with
air or wiping with paper waste.
Revision: 2010 May2011 QX56

PREPARATIONRAX-3
< PREPARATION >
CEF
G H
I
J
K L
M A
B
RAX
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000006225460
The actual shapes of Kent-Moore t ools may differ from those of special service tools illustrated here.
Commercial Service ToolsINFOID:0000000006225461
Tool number
(Kent-Moore No.)
Tool name Description
KV40107300
( − )
Boot band crimping tool Installing boot band
ZZA1229D
Tool name
Description
Power tool Loosening bolts and nuts
Drive shaft puller Remove drive shaft joint sub assembly
Ball joint remover Removing hub bolt
PBIC0190E
JPDIG0152ZZ
NT146
Revision: 2010 May2011 QX56

RAX-4
< SYMPTOM DIAGNOSIS >
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000006225462
Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference
—
RAX-16—
RAX-7—
NVH in DLN section.
NVH in DLN section.
NVH in RAX and RSU sections.
Refer to REAR AXLE in this chart.
NVH in WT section.
NVH in WT section.
Refer to DRIVE SHAFT in this chart.
NVH in BR section.
NVH in ST section.
Possible cause and SUSPECTED PARTS
Excessive joint angle
Joint sliding resistance
Imbalance
Improper installation, looseness
Parts interference
PROPELLER SHAFT
DIFFERENTIAL
REAR AXLE AND REAR SUSPENSION
REAR AXLE
TIRE
ROAD WHEEL
DRIVE SHAFT
BRAKE
STEERING
Symptom DRIVE
SHAFT
Noise
×× ×××××× ××
Shake ×× ×××××××
REAR AXLE Noise
××××× ×××××
Shake ××× × ×××××
Vibration ×××××××
Shimmy ×× × ×× ××
Judder × × ×× ××
Poor quality ride or handling ×× × ××
Revision: 2010 May2011 QX56
