INFINITI QX56 2011 Factory Service Manual

SRC-148
< DTC/CIRCUIT DIAGNOSIS >
B1177 LAP PRE-TENSIONER RH
B1177 LAP PRE-TENSIONER RH
DTC LogicINFOID:0000000006220092
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-148, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220093
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-148, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-148, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1182 PRE-TEN2 FRONT LH [OPEN] Lap pre-tensioner LH circuit is open  Harness or connectors
(Lap pre-tensioner circuit is open.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1178 LAP PRE-TENSIONER RHSRC-149
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1178 LAP PRE-TENSIONER RH
DTC LogicINFOID:0000000006220094
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-149, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220095
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1183 PRE-TEN2 FRONT LH [VB-SHORT] Lap pre-tensioner LH circuit is shorted
to some power supply circuit  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-150
< DTC/CIRCUIT DIAGNOSIS >
B1179 LAP PRE-TENSIONER RH
B1179 LAP PRE-TENSIONER RH
DTC LogicINFOID:0000000006220096
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-150, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220097
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1184 PRE-TEN2 FRONT LH [GND-SHORT] Lap pre-tensioner LH circuit is shorted to
ground  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1180 LAP PRE-TENSIONER RHSRC-151
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1180 LAP PRE-TENSIONER RH
DTC LogicINFOID:0000000006220098
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-151, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220099
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1185 PRE-TEN2 FRONT LH [SHORT] Lap pre-tensioner LH circuit are shorted
to each other  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-152
< DTC/CIRCUIT DIAGNOSIS >
B1182 LAP PRE-TENSIONER LH
B1182 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220100
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-148, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220101
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-148, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-148, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1182 PRE-TEN2 FRONT LH [OPEN] Lap pre-tensioner LH circuit is open  Harness or connectors
(Lap pre-tensioner circuit is open.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1183 LAP PRE-TENSIONER LHSRC-153
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1183 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220102
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-149, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220103
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1183 PRE-TEN2 FRONT LH [VB-SHORT] Lap pre-tensioner LH circuit is shorted
to some power supply circuit  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-154
< DTC/CIRCUIT DIAGNOSIS >
B1184 LAP PRE-TENSIONER LH
B1184 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220104
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-150, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220105
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1184 PRE-TEN2 FRONT LH [GND-SHORT] Lap pre-tensioner LH circuit is shorted to
ground  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1185 LAP PRE-TENSIONER LHSRC-155
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1185 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220106
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-151, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220107
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1185 PRE-TEN2 FRONT LH [SHORT] Lap pre-tensioner LH circuit are shorted
to each other  Harness or connectors
(Lap pre-tensioner circuit is shorted.)
 Malfunction in lap pre-tensioner LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-156
< DTC/CIRCUIT DIAGNOSIS >
B1186, B1187, B1188, B1189, B1190, B1191 DIAGNOSIS SENSOR UNIT
B1186, B1187, B1188, B1189, B1190, B1191 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006220108
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-156, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220109
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-156, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1186
B1187
B1188
B1189
B1190
B1191 CONTROL UNIT Air bag diagnosis sensor unit is malfunctioning Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1193 CURTAIN AIR BAG MODULE RHSRC-157
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1193 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220110
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-157, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220111
WARNING:
 Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-157, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module RH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-157, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1193 CURTAIN MODULE RH
[OPEN] Front curtain air bag module RH circuit is
open  Disconnection of wiring harness and open
 Malfunction in front curtain air bag module RH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56
