INFINITI QX56 2011 Factory Workshop Manual

ADP-32
< ECU DIAGNOSIS INFORMATION >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
Reference ValueINFOID:0000000006248320
TERMINAL LAYOUT
PHYSICAL VALUES
JMJIA3671ZZ
Te r m i n a l N o .(wire color) Description
ConditionVoltage (V)
(Approx.)
+ - Signal name Input/
Output
1
(Y) Ground Tilt switch up signal Input Tilt switch Operate
(up)
0
Other than the
above 5
2
(GR/B) Ground
Changeover switch RH
signal Input
Changeover
switch position RH 0
Neutral or LH 5
3
(Y/G) Ground Mirror switch up
signal Input Mirror switch Operated
(up)
0
Other than the
above 5
4
(GR/R) Ground Mirror switch left
signal Input Mirror switch Operated
(left)
0
Other than the
above 5
5
(R/B) Ground Door mirror sensor (pas-
senger side) up/down
signal
Input Door mirror RH position
Change between 3.4 (close to
peak) 0.6 (close to valley)
6
(L/Y) Ground Door mirror sensor (driv-
er side) up/down signal
Input Door mirror LH position Change between 3.4 (close to
peak) 0.6 (close to valley)
7
(P) Ground Telescopic switch for-
ward signal
InputTelescopic
switch Operate
(forward)
0
Other than the
above 5
8
(LG/R) Ground UART communication
(TX/RX)
Output Ignition switch ON
JMJIA1391ZZ
Revision: 2010 May2011 QX56

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-33
< ECU DIAGNOSIS INFORMATION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
10
(L/O) Ground Door mirror motor (pas-
senger side) up output
signal
Output Door mirror RH Operate
(up)
12
Other than the
above 0
11
(Y/B) Ground Door mirror motor (pas-
senger side) left output
signal Output Door mirror RH Operate
(left)
12
Other than the
above 0
12
(SB) Ground Door mirror motor (driver
side) down/right output
signal Output Door mirror (LH) Operate
(down/right)
12
Other than the
above 0
13
(LG) Ground Tilt switch down signal Input Tilt switch Operate
(down)
0
Other than the
above 5
14
(BR) Ground
Changeover switch LH
signal Input
Changeover
switch position LH 0
Neutral or RH 5
15
(O/L) Ground Mirror switch down sig-
nal Input Mirror switchOperate
(down)
0
Other than the
above 5
16
(V/W) Ground Mirror switch righ
t signal Input Mirror switch Operate
(right)
0
Other than the
above 5
17
(L/R) Ground Door mirror sensor (pas-
senger side) left/right
signal
Input Door mirro
r RH position Change between 3.4 (close to
left edge) 0.6 (close to right
edge)
18
(G/W) Ground
Door mirror sensor (driv-
er side) left/right signal Input Door mirro
r LH position Change between 0.6 (close to
left edge) 3.4 (close to right
edge)
19
(G)
Ground Telescopic switch back-
ward signal
InputTelescopic
switch Operate
(backward)
0
Other than the
above 5
20
(Y) Ground Sensor ground — — 0
21
(W/L) Ground
Door mirror motor sen-
sor power supply Input — 5
22
(V) Ground Door mirror motor (pas-
senger side) down/right
output signal Output Door mirror (RH) Operate
(down/right)
12
Other than the
above 0
23
(L/W) Ground Door mirror motor (driver
side) up output signal
Output Door mirror (LH) Operate
(up)
12
Other than the
above 0
Te r m i n a l N o .
(wire color) Description
ConditionVoltage (V)
(Approx.)
+ - Signal name Input/
Output
Revision: 2010 May2011 QX56

ADP-34
< ECU DIAGNOSIS INFORMATION >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
24
(BR/Y) Ground Door mirror motor (driver
side) left output signal
Output Door mirror (LH) Operate
(left)
12
Other than the
above 0
25
(W/R) Ground Battery power supply Input — Battery voltage
26
(L) Ground Telescopic motor back-
ward output signal
OutputSteering tele-
scopic Operate
(backward)
12
Other than the
above 0
27
(P) Ground Tilt & telescopic sensor
power supply
Output — 12
28
(G) Ground Tilt motor down output
signal
Output Steering tilt Operate
(down)
12
Other than the
above 0
29
(W/B) Ground Tilt motor up output sig-
nal
OutputSteering tilt
Operate
(up)
12
Other than the
above 0
Telescopic motor for-
ward output signal Steering tele-
scopicOperate
(forward)
12
Other than the
above 0
30
(B) Ground Ground — — 0
Te r m i n a l N o .
(wire color) Description
ConditionVoltage (V)
(Approx.)
+ - Signal name Input/
Output
Revision: 2010 May2011 QX56

BCM (BODY CONTROL MODULE)ADP-35
< ECU DIAGNOSIS INFORMATION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
BCM (BODY CONTROL MODULE)
List of ECU ReferenceINFOID:0000000006248321
ECU Reference
BCM BCS-33, "
Reference Value"
BCS-54, "Fail-safe"
BCS-56, "DTCInspectionPriorityChart"
BCS-57, "DTCIndex"
Revision: 2010 May2011 QX56

ADP-36
< WIRING DIAGRAM >
AUTOMATIC DRIVE POSITIONER SYSTEM
WIRING DIAGRAM
AUTOMATIC DRIVE POSITIONER SYSTEM
Wiring DiagramINFOID:0000000006248322
JCJWM1530GB
Revision: 2010 May2011 QX56

AUTOMATIC DRIVE POSITIONER SYSTEMADP-37
< WIRING DIAGRAM >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
JCJWM1531GB
Revision: 2010 May2011 QX56

ADP-38
< WIRING DIAGRAM >
AUTOMATIC DRIVE POSITIONER SYSTEM
JCJWM1532GB
Revision: 2010 May2011 QX56

AUTOMATIC DRIVE POSITIONER SYSTEMADP-39
< WIRING DIAGRAM >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
JCJWM1533GB
Revision: 2010 May2011 QX56

ADP-40
< WIRING DIAGRAM >
AUTOMATIC DRIVE POSITIONER SYSTEM
JCJWM1534GB
Revision: 2010 May2011 QX56

AUTOMATIC DRIVE POSITIONER SYSTEMADP-41
< WIRING DIAGRAM >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
JCJWM1535GB
Revision: 2010 May2011 QX56
