ADP-12
< SYSTEM DESCRIPTION >
SYSTEM
NOTE:
The lumbar support system are controlled independently with no link to the automatic drive positioner system.
Refer to SE-16, "
LUMBAR SUPPORT SYSTEM : System Description".
Sleep control
Driver seat control unit equips sleep control for reducing power consumption.
The system switches to sleep control when al l of the following conditions are satisfied.
Ignition switch is OFF (steering lock status).
All devices of auto driving pos ition system are not operating.
45 seconds timer of driver s eat control unit is not operating.
Set switch and memory switch (1 and 2) are OFF.
Wake-up control
Sleep control releases when detecting status change in either of the following item.
CAN communication
Power seat switch
Set switch and seat memory switch (1 and 2)
Tilt & telescopic switch
MANUAL FUNCTION
Function Description
Manual function The driving position (seat, steering column and door mirror position) can be adjusted
by using the power seat switch, tilt & telescopic switch or door mirror remote control
switch.
Memory function The seat, steering column and door mirror move to the stored driving position by
pressing seat memory switch (1 or 2).
Entry/Exit assist function Exit On exit, the seat moves backward and the steering column moves upward.
Entry
On entry, the seat and steering column returns from exiting position to the previous
driving position.
Intelligent Key interlock function Perform memory operation, exiting operation and entry operation by Intelligent Key
unlock operation or driver side door request switch unlock operation.
Revision: 2010 May2011 QX56
Page 22 of 5598

SYSTEMADP-13
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
MANUAL FUNCTION : System DiagramINFOID:0000000006248305
MANUAL FUNCTION : System DescriptionINFOID:0000000006248306
The driving position (seat, steering column and door mi rror position) can be adjusted manually with power seat
switch, tilt & telescopic switch and door mirror remote control switch.
OPERATION PROCEDURE
1. Turn ignition switch ON.
2. Operate power seat switch, tilt & telescopic switch or door mirror remote control switch.
3. The driver seat, steering column or door mirror operates according to the operation of each switch.
NOTE:
Seat operates only up to two places at the same time.
JMJIA3774GB
Revision: 2010 May2011 QX56
Page 23 of 5598

ADP-14
< SYSTEM DESCRIPTION >
SYSTEM
DETAIL FLOW
Seat
NOTE:
The power seat can be operated manually regardless of the ignition switch position.
Tilt & Telescopic
Door Mirror
NOTE:
The door mirrors can be operated manually when ignition switch is in either ACC or ON position.
MEMORY FUNCTION
Order Input Output Control unit condition
1 Power seat switch
(sliding, lifting, reclin-
ing)
—The power seat switch signal is inputted to the driver seat control
unit when the power seat switch is operated.
2— Motors
(sliding, lifting, reclin-
ing)The driver seat control unit outputs signals to each motor accord-
ing to the power seat switch input signal.
Order Input Output Control unit condition
1 Tilt & telescopic switch — The tilt & telescopic switch signal is inputted to the automatic
drive positioner control unit when the tilt & telescopic switch is op-
erated.
2— Motors
(Tilt, telescopic)The automatic drive positioner control unit actuates each motor
according to the operation of the tilt & telescopic switch.
Order Input Output Control unit condition
1 Door mirror remote
control switch — The door mirror remote control switch signal is inputted to the au-
tomatic drive positioner control unit when the door mirror remote
control switch is operated.
2— Motors
(Door mirror motor)The automatic drive positioner control unit actuates each motor
according to the operation of the door mirror remote control switch.
Revision: 2010 May2011 QX56
Page 24 of 5598

SYSTEMADP-15
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
MEMORY FUNCTION : System DiagramINFOID:0000000006248307
MEMORY FUNCTION : System DescriptionINFOID:0000000006248308
The driver seat control unit can store the optimum driving positions (seat, steering column and door mirror
position) for 2 people. If the front seat position is changed, one-touch (pressing desired memory switch) oper-
ation allows changing to the other driving position.
NOTE:
Further information for the memory storage procedure. Refer to ADP-53, "
MEMORY STORING : Description".
OPERATION PROCEDURE
1. Turn ignition switch ON.
2. Shift position P position.
JMJIA3775GB
Revision: 2010 May2011 QX56
Page 25 of 5598

ADP-16
< SYSTEM DESCRIPTION >
SYSTEM
3. Push desired memory switch.
4. Driver seat, steering and door mirror will move to the memorized position.
OPERATION CONDITION
Satisfy all of the following items. The memory function is not performed if these items are not satisfied.
* : When timer function does not operate.
DETAIL FLOW
TIMER FUNCTION
The memory function can be performed for 45 seconds after opening the driver door even if the ignition
switch position is in OFF position.
Satisfy all of the following items. The timer functi on is not performed if these items are not satisfied.
Item Request status
Ignition position ON
*
Switch inputs
Power seat switch
Tilt & telescopic switch
Door mirror control switch
Set switch
Memory switchOFF
(Not operated)
A/T shift selector P position
Memory function Registered
Vehicle speed 0 Km/h (0 MPH)
CONSULT-III Not connected
Order Input Output Control unit condition
1 Memory switch — The memory switch signal is inputted to the driver seat control unit
when memory switch 1 or 2 is operated.
2— Motors
(Seat, Steering,
door mirror)Driver seat control unit operates each motor of seat when it recogniz-
es the memory switch pressed for 0.5 second or more and requests
each motor operation to automatic drive positioner control unit via
UART communication. The automatic drive positioner control unit op-
erates each motor.
Memory switch Indica-
tor Driver seat control unit requests the flashing of memory indicator
while either of the motors is operating. The driver seat control unit il-
luminates the memory indicator.
3 Sensors
(Seat, steering col-
umn, door mirror) —Driver seat control unit judges the operating seat position with each
seat sensor input. The positions of the steering column and outside
mirror are monitored with each sensor signal. Driver seat control unit
stops the operation of each motor when each part reaches the record-
ed address.
4— Memory switch Indica-
torDriver seat control unit requests the illumination of memory indicator
after all motors stop. The driver seat control unit illuminates the mem-
ory indicator for 5 seconds.
Item Request status
Ignition position OFF
Set switch/memory switch OFF
Memory function Registered
A/T shift selector P position
Steering lock unit status LOCK
Driver side door switch OFF
CUNSULT-III Not connected
Revision: 2010 May2011 QX56
Page 26 of 5598

SYSTEMADP-17
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
EXIT ASSIST FUNCTION
EXIT ASSIST FUNCTION : System DiagramINFOID:0000000006248309
EXIT ASSIST FUNCTION : System DescriptionINFOID:0000000006248310
When exiting, the condition is satisfied, the seat is moved backward 40 mm (1.57 in) from normal sitting
position and the steering is moved to the most upper position.
The seat slide amount and the steering oper ation at entry/exit operation can be changed.
NOTE:
This function is set to ON before delivery (initial setting).
Further information for the system setting procedure. Refer to ADP-54, "
SYSTEM SETTING : Description".
OPERATION PROCEDURE
1. Shift position P position.
2. Open the driver door with ignition switch in OFF position.
3. Driver seat and steering column will move to the exiting position.
OPERATION CONDITION
Satisfy all of the following items. The exit assist function is not performed if these items are not satisfied.
JMJIA3776GB
Item Request status
Ignition position OFF
System setting [Entry/exit assist function (seat/steering)] ON
Initialization Done
Switch inputs
Power seat switch
Tilt & telescopic switch
Door mirror remote control switch
Set switch
Memory switch OFF
(Not operated)
A/T shift selector P position
Handle position LHD
Revision: 2010 May2011 QX56
Page 27 of 5598

ADP-18
< SYSTEM DESCRIPTION >
SYSTEM
DETAIL FLOW
ENTRY ASSIST FUNCTION
ENTRY ASSIST FUNCTION : System DiagramINFOID:0000000006248311
ENTRY ASSIST FUNCTION : System DescriptionINFOID:0000000006248312
The seat is in the exiting position when following condition is satisfied, the seat returns from exiting position to
the previous driving position.
NOTE:
This function is set to ON before delivery (initial setting).
Further information for the system setting procedure. Refer to ADP-54, "
SYSTEM SETTING : Description".
OPERATION PROCEDURE
1. Turn ignition switch ACC.
Transmission A/T
CUNSULT-III Not connected
Item Request status
Order Input Output Control unit condition
1 Door switch
(Driver side)
—Driver seat control unit receives door switch signal (driver side/
open) from BCM via CAN communication.
2— Motors
(Sliding, tilt)Driver seat control unit operates the seat sliding motor, which recog-
nizes that the driver side door is opened with ignition switch OFF.
Driver seat control unit then requests the operations of tilt motor to
auto drive positioner control unit via UART communication. The au-
tomatic drive positioner control unit operates each motor for a con-
stant amount.
3 Sensor
(Sliding, tilt) —Each sensor monitors the operating positions of seat and steering,
and then stops the operation of each motor when each part reaches
the recorded address.
JMJIA3777GB
Revision: 2010 May2011 QX56
Page 28 of 5598

SYSTEMADP-19
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
2. Driver seat and steering column will return from the exiting position to entry position.
OPERATION CONDITION
Satisfy all of the following items. The entry assist f unction is not performed if these items are not satisfied.
DETAIL FLOW
INTELLIGENT KEY INTERLOCK FUNCTION
Item Request status
Seat, steering column The vehicle is not moved after performing the
exit assist function.
Switch inputs
Power seat switch
Tilt & telescopic switch
Door mirror control switch
Set switch
Memory switch OFF
(Not operated)
Vehicle speed 0 Km/h (0 MPH)
Sta rte r OFF
Transmission A/T
CONSULT-III Not connected
Order Input Output Control unit condition
1 Ignition switch — Driver seat control unit receives the signals of [ignition switch signal]
from BCM via CAN communication.
2— Motors
(Sliding, tilt)Driver side control unit operates the sliding motor when the operating
conditions are satisfied and requests the operations of tilt motor to
automatic drive positioner control unit via UART communication. The
automatic drive positioner operates each motor.
3 Sensors
(Sliding, tilt) —Each sensor monitors the operating positions of seat and steering,
and then stops the operation of each motor when each part reaches
the recorded address.
Revision: 2010 May2011 QX56
Page 29 of 5598

ADP-20
< SYSTEM DESCRIPTION >
SYSTEM
INTELLIGENT KEY INTERLOCK FUNCTION : System Diagram
INFOID:0000000006248313
INTELLIGENT KEY INTERLOCK F UNCTION : System DescriptionINFOID:0000000006248314
By associating Intelligent Key and automatic drive po sitioner system, the unlock operation of Intelligent Key
or driver side door request switch performs me mory function and entry/exit assist function.
Registration of Intelligent Key interlock function can regist er a different key ID to the driver seat control unit,
one by one, for memory switch 1 and 2. A total of 2 key IDs can be registered.
When ignition switch is OFF (steering lock unit status ), and door unlock operation is performed using Intelli-
gent Key or driver side door request swit ch, driver seat automatically adjusts to a driving position other than
seat sliding. Seat sliding and steering column tilt perform return operation and are set to standby status.
In standby status, when ignition switch is operated from OFF to ACC, return operation sets seat sliding and
steering column tilt to a registered position.
NOTE:
When another key ID is newly registered to a key switch to which a key ID is already registered, the previ-
ously registered key ID is overwritten and becomes unusable.
When starter signal turns ON during return operation, the operation is interrupted, starter signal turns from
ON to OFF, and operation restarts.
OPERATION PROCEDURE
1. Unlock driver door by Intelligent Key or driver side door request switch.
2. Operation other than memory functi on of seat sliding is performed. Seat sliding and steering column tilt
perform exit assist operation.
3. Turn ignition switch ACC.
4. Driver seat and steering column will return from the exiting position to entry position.
NOTE:
Further information for Intelligent Key interlock function. Refer to ADP-54, "
INTELLIGENT KEY INTERLOCK
STORING : Description".
OPERATION CONDITION
Satisfy all of the following items. The Intelligent Key interlock function is not performed if these items are not
satisfied.
JMJIA3778GB
Revision: 2010 May2011 QX56
Page 30 of 5598

SYSTEMADP-21
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
DETAIL FLOW
Fail SafeINFOID:0000000006248315
The fail-safe mode may be activated if the following symptoms are observed.
Item Request status
Ignition position OFF
Intelligent key interlock function Registered
Steering lock unit status LOCK
Switch inputs
Power seat switch
Tilt & telescopic switch
Door mirror control switch
Set switch
Memory switch OFF
(Not operated)
A/T shift selector P position
Order Input Output Control unit condition
1 Door unlock signal
(CAN)
Key ID signal (CAN) —Driver seat control unit receives unlock signal and key ID signal from
BCM, when driver seat control unit is unlocked by Intelligent Key or
driver side door request switch.
2— — Driver seat control unit performs the seat slide and steering tilt move
directly to the exit assist function. Other loads move to the exit assist
function after performing memory function.
3 — — Driver seat control unit performs the entry assist function.
Operating in
fail-safe mode Malfunction Item
Related
DTC Diagnosis
Only manual functions operate normally. CAN communication U1000
ADP-56
CONTROL UNIT U1010ADP-57
EEPROM B2130ADP-66
Only manual functions, except door mirror, operate normally. UART communication B2128 ADP-64
Only manual functions, except seat sliding, operate normally. Seat sliding output B2112ADP-58
Only manual functions, except seat reclining, operate normally. Seat reclining output B2113ADP-60
Only manual functions, except steering tilt, operate normally. Steering column tilt output B2116ADP-62
Revision: 2010 May2011 QX56
