DAS
BSW INDICATORDAS-525
< REMOVAL AND INSTALLATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
BSW INDICATOR
Removal and InstallationINFOID:0000000006223982
REMOVAL AND INSTALLATION
Removal
1. Remove the INFINITI QX56 2011 Factory Repair Manual
DAS
BSW INDICATORDAS-525
< REMOVAL AND INSTALLATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
BSW INDICATOR
Removal and InstallationINFOID:0000000006223982
REMOVAL AND INSTALLATION
Removal
1. Remove the](/img/42/57033/w960_57033-1489.png)
DAS
BSW INDICATORDAS-525
< REMOVAL AND INSTALLATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
BSW INDICATOR
Removal and InstallationINFOID:0000000006223982
REMOVAL AND INSTALLATION
Removal
1. Remove the door mirror corner cover. Refer to INT-13, "Exploded View".
2. Remove the BSW indicator.
Installation
Install in the reverse order of removal.
Revision: 2010 May2011 QX56
Page 1493 of 5598

DEF-1
DRIVER CONTROLS
C
DE
F
G H
I
J
K
M
SECTION DEF
A
B
DEF
N
O P
CONTENTS
DEFOGGER
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
3
SYSTEM DESCRIPTION ..............................5
COMPONENT PARTS ................................... .....5
Component Parts Location .................................. ......5
Component Description .............................................5
SYSTEM ..............................................................6
System Diagram .................................................. ......6
System Description ...................................................6
DIAGNOSIS SYSTEM (BCM) .............................7
COMMON ITEM ..................................................... ......7
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .......................................................
7
REAR WINDOW DEFOGGER ............................... ......8
REAR WINDOW DEFOGGER : CONSULT-III
Function (BCM - REAR DEFOGGER) ......................
8
DIAGNOSIS SYSTEM (IPDM E/R) .....................10
Diagnosis Description ......................................... ....10
CONSULT-III Function (IPDM E/R) .........................12
ECU DIAGNOSIS INFORMATION ..............15
BCM, IPDM E/R .............................................. ....15
List of ECU Reference ........................................ ....15
WIRING DIAGRAM ......................................16
REAR WINDOW DEFOGGER SYSTEM ........ ....16
Wiring Diagram ................................................... ....16
BASIC INSPECTION ...................................24
DIAGNOSIS AND REPAIR WORK FLOW .......24
Work Flow ............................................................ ....24
DTC/CIRCUIT DIAGNOSIS .........................25
REAR WINDOW DEFOGGER SWITCH ...........25
Component Function Check ................................ ....25
Diagnosis Procedure ...............................................25
REAR WINDOW DEFOGGER RELAY .............26
Description ...............................................................26
Component Function Check ....................................26
Diagnosis Procedure ...............................................26
REAR WINDOW DEFOGGER ..........................27
Description ...............................................................27
Component Function Check ....................................27
Diagnosis Procedure ...............................................27
DOOR MIRROR DEFOGGER ...........................29
Description ...............................................................29
Component Function Check ....................................29
Diagnosis Procedure ...............................................29
DRIVER SIDE DOOR MIRROR DEFOGGER ...30
Description ...............................................................30
Component Function Check ....................................30
Diagnosis Procedure ...............................................30
PASSENGER SIDE DOOR MIRROR DEFOG-
GER ...................................................................
31
Description ...............................................................31
Component Function Check ....................................31
Diagnosis Procedure ...............................................31
WIPER DEICER RELAY ...................................32
Component Function Check ....................................32
Diagnosis Procedure ...............................................32
Component Inspection .............................................33
WIPER DEICER ................................................34
Revision: 2010 May2011 QX56
Page 1494 of 5598

DEF-2
Component Function Check ...................................34
Diagnosis Procedure ..............................................34
SYMPTOM DIAGNOSIS .............................36
REAR WINDOW DEFOGGER DOES NOT
OPERATE ....................................................... ...
36
Diagnosis Procedure ........................................... ...36
REAR WINDOW DEFOGGER AND DOOR
MIRROR DEFOGGER DO NOT OPERATE. .....
37
Diagnosis Procedure ........................................... ...37
REAR WINDOW DEFOGGER DOES NOT
OPERATE BUT BOTH DOOR MIRROR DE-
FOGGERS OPERATE. ......................................
38
Diagnosis Procedure ........................................... ...38
DOOR MIRROR DEFOGGER DOES NOT OP-
ERATE ...............................................................
39
BOTH SIDES .......................................................... ...39
BOTH SIDES : Description .....................................39
BOTH SIDES : Diagnosis Procedure ................... ...39
DRIVER SIDE ......................................................... ...39
DRIVER SIDE : Description ....................................39
DRIVER SIDE : Diagnosis Procedure .....................39
PASSENGER SIDE ...................................................39
PASSENGER SIDE : Descripti on ...........................39
PASSENGER SIDE : Diagnos is Procedure ............39
WIPER DEICER DOSE NOT OPERATE ........ ...41
Diagnosis Procedure ............................................ ...41
ON IS NOT DISPLAYED WHEN PRESSING
REAR WINDOW DEFOGGER SWITCH BUT
IT IS OPERATED ...............................................
42
Diagnosis Procedure ............................................ ...42
REMOVAL AND INSTALLATION ..............43
FILAMENT ...................................................... ...43
Inspection and Repair .......................................... ...43
Revision: 2010 May2011 QX56
Page 1497 of 5598

COMPONENT PARTSDEF-5
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006299423
Component DescriptionINFOID:0000000006299424
1. BCM Refer to BCS-4, "
BODY CONTROL
SYSTEM : Component Parts Loca-
tion"
2. Door mirror defogger (driver side) 3. Rear window defogger connector
4. Rear window defogger connector 5. Multifunction switch (rear window defogger switch)
Refer to AV- 9 , "
Component Parts Lo-
cation"
6. IPDM E/R
Refer to PCS-4, "
Component Parts
Location"
7. AV control unit 8. Wiper deicer
JMLIA0978ZZ
BCM Transmits rear window defogger switch operation to IPDM E/R via CAN commu-
nication
Performs the timer control of rear window defogger
IPDM E/R Controls rear window defogger relay when rear window defogger switch signal is re-
ceived via CAN communication, and then operates rear window defogger
Multifunction switch The rear window defogger switch is installed
Turns the indicator lamp ON when detecting the operation of rear window defog-
ger
Rear window defogger switch The rear window defogger is operated by turning the rear window defogger switch
ON.
The indicator lamp in the rear window defogger switch illuminates when the rear window defogger is operating.
Rear window defogger relay Operates the rear window defogger with the control signal from IPDM E/R
Rear window defogger Heats the heating wire with the power supply from the rear window defogger relay
to prevent the rear window from fogging up.
Door mirror defogger Heats the heating wire with the power supply from the rear window defogger relay
to prevent the door mirror from fogging up.
Wiper deicer Heats the heating wire with the power supply from the wiper deicer relay to thaw the
frozen wiper blade and glass.
Wiper deicer relay Supplies power to the wiper deicer with rear window defogger relay control.
Revision: 2010 May2011 QX56
Page 1498 of 5598

DEF-6
< SYSTEM DESCRIPTION >
SYSTEM
SYSTEM
System DiagramINFOID:0000000006299425
System DescriptionINFOID:0000000006299426
System Description
Multifunction switch (rear window defogger switch) transmits rear window defogger switch signal to AV con-
trol unit via AV communication when rear window defogger switch is turned ON, while ignition switch is ON.
AV control unit transmits rear window defogger switch signal to BCM via CAN communication.
BCM transmits rear defogger window switch signal to IPDM E/R for approximately 15 minutes via CAN com-
munication when rear window defogger switch signal is received.
IPDM E/R turns rear window defogger relay ON when rear window defogger switch signal is received.
Power supply is supplied to rear window defogger and door mirror defoggers when rear window defogger
relay is ON.
Wiper deicer relay turns ON when rear window defogger relay is ON.
Power is supply to wiper deicer when wiper deicer relay is ON.
AV control unit transmits rear window defogger contro l signal to multifunction switch (rear window defogger
switch) via AV communication.
IPDM E/R transmits rear window defogger control signal to AV control unit via CAN communication.
Timer function
BCM turns rear window defogger relay ON for appr oximately 15 minutes when rear window defogger switch
is turned ON to operate rear window defogger, door mirror defoggers and wiper deicer.
Timer is canceled when rear window defogger switch is pressed again during timer operation. BCM turns
rear window defogger relay OFF. The same operation also occurs when the ignition switch is turned OFF
during timer operation.
JMLIA0981GB
Revision: 2010 May2011 QX56
Page 1521 of 5598

DOOR MIRROR DEFOGGERDEF-29
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
DOOR MIRROR DEFOGGER
DescriptionINFOID:0000000006299442
Heats the heating wire with the power supply from t he rear window defogger relay to prevent the door mirror
from fogging up.
Component Function CheckINFOID:0000000006299443
1.CHECK DOOR MIRROR DEFOGGER
1. Perform IPDM E/R Active Test (“REAR DEFOGGER”) using CONSULT-III.
2. Touch “ON”.
3. Check that both side door mirror glasses are getting warmer.
Is the inspection result normal?
YES >> Door mirror defogger is OK.
NO >> Refer to DEF-29, "
Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000006299444
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10A fuse [No.80, loca ted in fuse block (J/B)].
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK DOOR MIRROR DEFOGGER CIRCUIT
1. Disconnect IPDM E/R connector and door mirror (both sides) connector.
2. Check continuity between IPDM E/R harness connec tor and door mirror (driver side) harness connector.
3. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
IPDM E/R Door mirro r (driver side)
Continuity
Connector Terminal Connector Terminal
E11 14 D3 7 Existed
IPDM E/R GroundContinuity
Connector Terminal
E11 14 Not existed
Revision: 2010 May2011 QX56
Page 1522 of 5598

DEF-30
< DTC/CIRCUIT DIAGNOSIS >
DRIVER SIDE DOOR MIRROR DEFOGGER
DRIVER SIDE DOOR MIRROR DEFOGGER
DescriptionINFOID:0000000006299445
Heats the heating wire with the power supply from the rear window defogger relay to prevent the door mirror
from fogging up.
Component Function CheckINFOID:0000000006299446
1.CHECK DRIVER SIDE DOOR MIRROR DEFOGGER
1. Perform IPDM E/R Active Test (“REAR DEFOGGER”) using CONSULT-III.
2. Touch “ON”.
3. Check that the driver side door mirror glass is getting warmer.
Is the inspection result normal?
YES >> Driver side door mirror defogger is OK.
NO >> Refer to DEF-30, "
Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000006299447
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door mirror (driver side) connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between door mirror (driver side) harness connector and ground.
Is the inspection result normal?
YES >> Replace door mirror glass (driver side).
NO >> Repair or replace harness.
(+)
(–) Condition Voltage (V)
(Approx.)
Door mirror (driver side)
Connector Terminal
D3 7 Ground Rear window defogger
switchON Battery voltage
OFF 0
Door mirror (driver side)
GroundContinuity
Connector Terminal
D3 19 Existed
Revision: 2010 May2011 QX56
Page 1523 of 5598

PASSENGER SIDE DOOR MIRROR DEFOGGERDEF-31
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
PASSENGER SIDE DOOR MIRROR DEFOGGER
DescriptionINFOID:0000000006299448
Heats the heating wire with the power supply from t he rear window defogger relay to prevent the door mirror
from fogging up.
Component Function CheckINFOID:0000000006299449
1.CHECK PASSENGER SIDE DOOR MIRROR DEFOGGER
1. Perform IPDM E/R Active Test (“REAR DEFOGGER”) using CONSULT-III.
2. Touch “ON”.
3. Check that the passenger side door mirror glass is getting warmer.
Is the inspection result normal?
YES >> Passenger side door mirror defogger is OK.
NO >> Refer to DEF-31, "
Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000006299450
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door mirror (passenger side) connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror (passenger side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between door mirror (passenger side) harness connector and ground.
Is the inspection result normal?
YES >> Replace door mirror glass (passenger side).
NO >> Repair or replace harness.
(+)
(–) Condition Voltage (V)
(Approx.)
Door mirror (passenger side)
Connector Terminal
D23 7 Ground Rear window defogger
switchON Battery voltage
OFF 0
Door mirror (passenger side)
GroundContinuity
Connector Terminal
D23 19 Existed
Revision: 2010 May2011 QX56
Page 1529 of 5598

REAR WINDOW DEFOGGER AND DOOR MIRROR DEFOGGER DO NOT OPER-
ATE.
DEF-37
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
REAR WINDOW DEFOGGER AND DO OR MIRROR DEFOGGER DO NOT
OPERATE.
Diagnosis ProcedureINFOID:0000000006299457
1.CHECK REAR WINDOW DEFOGGER SWITCH
Check rear window defogger switch.
Refer to DEF-25, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK REAR WINDOW DEFOGGER RELAY
Check rear window defogger relay.
Refer to DEF-26, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK REAR WINDOW DEFOGGER
Check rear window defogger.
Refer to DEF-27, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
Revision: 2010 May2011 QX56
Page 1530 of 5598

DEF-38
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH DOOR MIRROR
DEFOGGERS OPERATE.
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH DOOR
MIRROR DEFOGGERS OPERATE.
Diagnosis ProcedureINFOID:0000000006299458
1.CHECK REAR WINDOW DEFOGGER
Check rear window defogger.
Refer to DEF-27, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
Revision: 2010 May2011 QX56
