B2614 ACC RELAY CIRCUITPCS-57
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
Is the inspection result normal?
YES >> Replace BCM. Refer to
BCS-81, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK ACCESSORY RELAY GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between accessory relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair accessory relay ground circuit.
4.CHECK ACCESSORY RELAY POWER SUPPLY CIRCUIT-2
1. Turn ignition switch ACC.
2. Check voltage between accessory relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check continuity open or short between accessory relay and battery.
5.CHECK ACCESSORY RELAY
Refer to PCS-57, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace accessory relay.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006220205
1.CHECK ACCESSORY RELAY
1. Turn ignition switch OFF.
2. Remove accessory relay.
Accessory relay
GroundContinuity
Te r m i n a l
1 Not existed
Accessory relay
GroundContinuity
Te r m i n a l
2 Existed
(+)
(–)Voltage (V)
(Approx.)
Accessory relay
Te r m i n a l5 Ground Battery voltage
Revision: 2010 May2011 QX56

PCS-60
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2615 BLOWER RELAY CIRCUIT
YES >> GO TO 6.
NO >> Repair or replace harness.
3.CHECK BLOWER RELAY GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between blower relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair blower relay ground circuit.
4.CHECK BLOWER RELAY POWER SUPPLY CIRCUIT-2
1. Turn ignition switch ON or ACC.
2. Check voltage between blower relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check continuity open or short between blower relay and battery.
5.CHECK BLOWER RELAY
Refer to PCS-60, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace blower relay.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006220208
1.CHECK BLOWER RELAY
1. Turn ignition switch OFF.
2. Remove blower relay.
3. Check the continuity between blower relay terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace blower relay
Blower relay
GroundContinuity
Te r m i n a l
2 Existed
(+)
(–)Voltage (V)
(Approx.)
Blower relay
Te r m i n a l 5 Ground Battery voltage
Terminals Condition Continuity
3 and 5 12 V direct current supply between terminals 1 and 2 Existed
No current supply Not existed
PBIB0098E
Revision: 2010 May2011 QX56

PCS-62
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2616 IGNITION RELAY CIRCUIT
YES >> Replace BCM. Refer to
BCS-81, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK IGNITION RELAY-1 GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between igniti on relay-1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair ignition relay-1 ground circuit.
4.CHECK IGNITION RELAY-1 POWER SUPPLY CIRCUIT-2
1. Turn ignition switch ON.
2. Check voltage between ignition relay-1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check continuity open or short between ignition relay-1 and battery.
5.CHECK IGNITION RELAY-1
Refer to PCS-62, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace ignition relay-1.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006220211
1.CHECK IGNITION RELAY-1
1. Turn ignition switch OFF.
2. Remove ignition relay-1.
3. Check the continuity between ignition relay-1 terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace Ignition relay-1.
Ignition relay-1
GroundContinuity
Te r m i n a l
1 Existed
(+)
(–)Voltage (V)
(Approx.)
Ignition relay-1
Te r m i n a l 5 Ground Battery voltage
Terminals Condition Continuity
3 and 5 12 V direct current supply between terminals 1 and 2 Existed
No current supply Not existed
PBIB0098E
Revision: 2010 May2011 QX56

PCS-72
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
PUSH-BUTTON IGNITION SWITCH
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT 2
1. Disconnect BCM connector.
2. Check continuity between IPDM E/R harness connec tor and push-button ignition switch harness connec-
tor.
3. Check continuity between IP DM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace harness.
5.CHECK PUSH-BUTTON IGNITION SWITCH GROUND CIRCUIT
Check continuity between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK PUSH-BUTTON IGNITION SWITCH
Refer to PCS-72, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace push-button ignition switch.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006220224
1.CHECK PUSH-BUTTON IGNITION SWITCH
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check continuity between push- button ignition switch terminals.
(+)
(–)Voltage (V)
(Approx.)
IPDM E/R
Connector Terminal E17 66 Ground Battery voltage
IPDM E/R Push-button ignition switch Continuity
Connector Terminal Connector Terminal
E17 66 M101 4 Existed
IPDM E/R GroundContinuity
Connector Terminal
E17 66 Not existed
Push-button ignition switch GroundContinuity
Connector Terminal
M101 1 Existed
Revision: 2010 May2011 QX56

PCS-74
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
PUSH-BUTTON IGNITION SW
ITCH POSITION INDICATOR
PUSH-BUTTON IGNITION SWITCH POSITION INDICATOR
DescriptionINFOID:0000000006220225
Push-button ignition switch changes the power supply position.
BCM maintains the power supply position status.
BCM changes the power supply position with the operation of the push-button ignition switch.
Component Function CheckINFOID:0000000006220226
1.CHECK FUNCTION
Check push-button ignition switch (“LOCK INDICATO R”, “ACC INDICATOR” and “IGNITION ON IND”) in
Active Test of BCM with CONSULT-III.
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Refer to PCS-74, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006220227
1.CHECK PUSH-BUTTON IGNITION SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection normal?
YES >> GO TO 2.
NO-1 >> Check 10 A fuse [No.10, located in fuse block (J/B)].
NO-2 >> Check harness for open or short betw een push-button ignition switch and fuse.
2.CHECK BCM INPUT
1. Connect push-button ignition switch connector.
2. Disconnect BCM connector.
3. Check voltage between BCM connector and ground.
Is the inspection normal?
YES >> Replace BCM. Refer to BCS-81, "Removal and Installation".
NO >> GO TO 3.
3.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT
1. Disconnect push-button ignition switch connector.
Te s t i t e m D e s c r i p t i o n
LOCK INDICATOR
ACC INDICATOR
IGNITION ON IND ON
Position indicator Illuminates
OFF Does not illuminate
(+) (–)Voltage (V)
(Approx.)
Push-button ignition switch
Connector Terminal M101 8 Ground Battery voltage
(+) (–)Voltage (V)
(Approx.)
BCM
Connector Terminal
M101 73
Ground Battery voltage
91
109
Revision: 2010 May2011 QX56
