Automatic Transmission – 4L60E – General Information Page 7C1–13
General Definition
Line Pressure The main fluid pressure in a hydraulic system created by the pump and pressure
regulator valve.
Manual Valve A spool valve that distributes fluid to various hydraulic circuits and is mechanically
linked to the gear selector lever.
Orifice A restricting device (usually a hole in the spacer plate) for controlling pressure build up
into another circuit.
Overdrive An operating condition in the gear set allowing output speed to be higher than input
speed and output torque to be lower than input torque.
Overrunning The function of a one-way mechanical clutch that allows the clutch to freewheel during certain operating conditions of the transmission.
Pedal Position The percentage angle of the accelerator pedal as displayed by Tech 2.
Pinion Gears Pinion gears (housed in a carrier) that are in constant mesh with a circumferential
internal gear and centralised sun gear.
Planetary Gear Set An assembly of gears that consists of an internal gear, planet pinion gears with a carrier, and a sun gear.
Pressure A measurable force that is exerted on an area and expressed as kilopascals (kPa).
Pulse Width Modulated (PW M) An electronic signal that continuously cycles the On and Off time of a device (such as
a solenoid) while varying the amount of On time.
Race (Inner or Outer) A highly polished steel surface that contacts bearings or sprag or roller elements.
Reduction (Gear Reduction) An operating condition in the gear set allowing output speed to be lower than input speed and output torque to be higher than input torque.
Residual Fluid Pressure Excess pressure contained within an area after the supply pressure has been terminated.
Roller Clutch A mechanical clutch (holding device) consisting of roller bearings assembled between inner and outer races.
Servo A spring loaded device consisting of a piston in a bore that is operated (stroked) by
hydraulic pressure to apply or release a band.
Spool Valve A round hydraulic control valve often containing a variety of land and valley diameters.
Sprag Clutch A mechanical clutch (holding device consisting of "figure eight" like elements
assembled between inner and outer races.
Staking The effect of deforming, peening over or riveting a shaft to provide a solid mounting.
Throttle Position The travel of the throttle plate that is expressed in percentages and measured by
Tech 2.
Torque A measurable twisting force expressed in terms of Newton metres (Nm).
Torque Converter A component of an automatic transmission, (attached to the engine flex plate) that
transfers torque from the engine to the transmission through a fluid coupling.
Torx Plus Bit A special tool used for the removal of the bell housing. Precision tip fit means that cam
out of the bolt head is virtually eliminated.
NOTE
Torx
Plus Bits are different from normal Torx
Bits
Transmission Control Module
(TCM) An electronic device that manages the vehicle's engine and automatic transmission
functions.
Variable Capacity Pump The device that provides fluid for operating the hydraulic circuits in the transmission. The amount of fluid supplied varies depending on vehicle operating conditions.
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3788 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–2
4 Diagnostics ...........................................................................................................................................27
4.1 Introduction ................................................................................................................... ....................................... 27
4.2 Basic Knowledge Required ....................................................................................................... .......................... 27
4.3 Diagnostic Precautions ....................................................................................................................................... 27
4.4 Preliminary Checks.............................................................................................................................................. 28
4.5 Diagnostic Trouble Code Tables ................................................................................................. ....................... 29
Multiple DTCs Fault Condition ............................................................................................................................ 29
4.6 Diagnostic Trouble Code Definitions ............................................................................................ ..................... 29
Type A – Emission Related DTCs ....................................................................................................................... 29
Type B – Emission Related DTCs ....................................................................................................................... 30
Conditions for Clearing Type A or Type B DTCs .................................................................................. ............ 30
Type C – Non-emission Related DTCs ............................................................................................................... 30
Conditions for Clearing Type C DTCs .............................................................................................................. 30
Current DTCs........................................................................................................................................................ 30
History DTCs ........................................................................................................................................................ 30
4.7 Diagnostic System Check ........................................................................................................ ........................... 30
Description ........................................................................................................................................................... 30
Test Description ................................................................................................................................................... 31
4.8 Diagnostic Trouble Code List ................................................................................................... .......................... 31
4.9 DTC P0218 – Transmission Fluid Overtemperature................................................................................. ......... 33
DTC Description ................................................................................................................................................... 33
Circuit Description ............................................................................................................................................... 33
Conditions for Running the DTC ................................................................................................. ....................... 33
Conditions for Setting the DTC........................................................................................................................... 33
Action Taken When the DTC Sets ................................................................................................. ..................... 33
Conditions for Clearing the DTC ........................................................................................................................ 34
Diagnostic Aids .................................................................................................................................................... 34
Test Description ................................................................................................................................................... 34
DTC P0218 Diagnostic Table..................................................................................................... .......................... 34
4.10 DTC P0562 – System Voltage Low ................................................................................................. .................... 35
DTC Description ................................................................................................................................................... 35
Circuit Description ............................................................................................................................................... 35
Conditions for Running the DTC ................................................................................................. ....................... 36
Conditions for Setting the DTC........................................................................................................................... 36
Action Taken When the DTC Sets ................................................................................................. ..................... 36
Conditions for Clearing the DTC ........................................................................................................................ 36
Diagnostic Aids .................................................................................................................................................... 36
Test Description ................................................................................................................................................... 36
DTC P0562 Diagnostic Table..................................................................................................... .......................... 36
4.11 DTC P0563 – System Voltage High................................................................................................ ..................... 38
DTC Description ................................................................................................................................................... 38
Circuit Description ............................................................................................................................................... 38
Conditions for Running the DTC ................................................................................................. ....................... 38
Conditions for Setting the DTC........................................................................................................................... 39
Action Taken When the DTC Sets ................................................................................................. ..................... 39
Conditions for Clearing the DTC ........................................................................................................................ 39
Diagnostic Aids .................................................................................................................................................... 39
Test Description ................................................................................................................................................... 39
DTC P0563 Diagnostic Table..................................................................................................... .......................... 39
4.12 DTC P0601 to P0604 or P1621 – TCM Malfunction .................................................................................. .......... 41
DTC Description ................................................................................................................................................... 41
Circuit Description ............................................................................................................................................... 41
Conditions for Running the DTC ................................................................................................. ....................... 41
Conditions for Setting the DTC........................................................................................................................... 41
Action Taken When the DTC Sets ................................................................................................. ..................... 42
Conditions for Clearing the DTC ........................................................................................................................ 42
Test Description ................................................................................................................................................... 42
DTC P0601 to P0604 or P1621 Diagnostic Table ................................................................................... ............ 42
4.13 DTC P0711 to P0713 – Transmission Fluid Temperature Sensor .................................................................... 4 3
DTC Description ................................................................................................................................................... 43
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3789 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–3
Circuit Description ............................................................................................................................................... 43
Conditions for Running the DTC ........................................................................................................................ 43
DTC P0711 ...................................................................................................................................................... 43
DTC P0712 ...................................................................................................................................................... 43
DTC P0713 ...................................................................................................................................................... 44
Conditions for Setting the DTC................................................................................................. .......................... 44
DTC P0711 ...................................................................................................................................................... 44
DTC P0712 ...................................................................................................................................................... 44
DTC P0713 ...................................................................................................................................................... 44
Action Taken When the DTC Sets ................................................................................................. ..................... 44
Conditions for Clearing the DTC ........................................................................................................................ 44
Diagnostic Aids .................................................................................................................................................... 45
Test Description ................................................................................................................................................... 45
DTC P0711 to P0713 Diagnostic Table ............................................................................................ ................... 45
4.14 DTC P0719 – Brake Switch Circuit High Input (Stuck On) ......................................................................... ....... 47
DTC Description ................................................................................................................................................... 47
Circuit Description ............................................................................................................................................... 47
Conditions for Running the DTC ................................................................................................. ....................... 47
Conditions for Setting the DTC........................................................................................................................... 47
Action Taken When the DTC Sets ................................................................................................. ..................... 47
Conditions for Clearing the DTC ........................................................................................................................ 47
Diagnostic Aids .................................................................................................................................................... 48
Test Description ................................................................................................................................................... 48
DTC P0719 Diagnostic Table..................................................................................................... .......................... 48
4.15 DTC P0722 – Vehicle Speed Sensor Circuit Low Voltage........................................................................... ...... 49
DTC Description ................................................................................................................................................... 49
Circuit Description ............................................................................................................................................... 49
Conditions for Running the DTC ................................................................................................. ....................... 49
Conditions for Setting the DTC........................................................................................................................... 49
Action Taken When the DTC Sets ................................................................................................. ..................... 50
Conditions for Clearing the DTC ........................................................................................................................ 50
Diagnostic Aids .................................................................................................................................................... 50
Test Description ................................................................................................................................................... 50
DTC P0722 Diagnostic Table..................................................................................................... .......................... 50
4.16 DTC P0723 – Vehicle Speed Sensor Circuit Intermittent .......................................................................... ........ 52
DTC Description ................................................................................................................................................... 52
Circuit Description ............................................................................................................................................... 52
Conditions for Running the DTC ................................................................................................. ....................... 52
Conditions for Setting the DTC........................................................................................................................... 53
Action Taken When the DTC Sets ................................................................................................. ..................... 53
Conditions for Clearing the DTC ........................................................................................................................ 53
Diagnostic Aids .................................................................................................................................................... 53
Test Description ................................................................................................................................................... 53
DTC P0723 Diagnostic Table..................................................................................................... .......................... 54
4.17 DTC P0724 – Brake Switch Circuit Low Input (Stuck Off) ................................................................................ 55
DTC Description ................................................................................................................................................... 55
Circuit Description ............................................................................................................................................... 55
Conditions for Running the DTC ................................................................................................. ....................... 56
Conditions for Setting the DTC........................................................................................................................... 56
Action Taken When the DTC Sets ................................................................................................. ..................... 56
Conditions for Clearing the DTC ........................................................................................................................ 56
Diagnostic Aids .................................................................................................................................................... 56
Test Description ................................................................................................................................................... 56
DTC P0724 Diagnostic Table..................................................................................................... .......................... 56
4.18 DTC P0741 – Torque Converter Clutch System – Stuck Off......................................................................... .... 57
DTC Description ................................................................................................................................................... 57
Circuit Description ............................................................................................................................................... 57
Conditions for Running the DTC ................................................................................................. ....................... 58
Conditions for Setting the DTC........................................................................................................................... 58
Action Taken When the DTC Sets ................................................................................................. ..................... 58
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3790 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–4
Conditions for Clearing the DTC ........................................................................................................................ 58
Diagnostic Aids .................................................................................................................................................... 58
Test Description ................................................................................................................................................... 58
DTC P0741 Diagnostic Table..................................................................................................... .......................... 59
4.19 DTC P0742 – Torque Converter Clutch System – Stuck On .......................................................................... ... 60
DTC Description ................................................................................................................................................... 60
Circuit Description ............................................................................................................................................... 60
Conditions for Running the DTC ................................................................................................. ....................... 60
Conditions for Setting the DTC........................................................................................................................... 61
Action Taken When the DTC Sets ................................................................................................. ..................... 61
Conditions for Clearing the DTC ........................................................................................................................ 61
Diagnostic Aids .................................................................................................................................................... 61
Test Description ................................................................................................................................................... 61
DTC P0742 Diagnostic Table..................................................................................................... .......................... 61
4.20 DTC P0751 – 1-2 Shift Solenoid Valve Performance – No First or Fourth Gear ............................................. 63
DTC Description ................................................................................................................................................... 63
Circuit Description ............................................................................................................................................... 63
Conditions for Running the DTC ................................................................................................. ....................... 63
Conditions for Setting the DTC........................................................................................................................... 63
Action Taken When the DTC Sets ................................................................................................. ..................... 63
Conditions for Clearing the DTC ........................................................................................................................ 63
Diagnostic Aids .................................................................................................................................................... 64
Test Description ................................................................................................................................................... 64
DTC P0751 Diagnostic Table..................................................................................................... .......................... 64
4.21 DTC P0752 – 1-2 Shift Solenoid Valve Performance – No Second or Third Gear........................................... 65
DTC Description ................................................................................................................................................... 65
Circuit Description ............................................................................................................................................... 65
Conditions for Running the DTC ................................................................................................. ....................... 65
Conditions for Setting the DTC........................................................................................................................... 65
Action Taken When the DTC Sets ................................................................................................. ..................... 66
Conditions for Clearing the DTC ........................................................................................................................ 66
Diagnostic Aids .................................................................................................................................................... 66
Test Description ................................................................................................................................................... 66
DTC P0752 Diagnostic Table..................................................................................................... .......................... 66
4.22 DTC P0756 – 2-3 Shift Solenoid Valve Performance – No First or Second Gear ............................................ 68
DTC Description ................................................................................................................................................... 68
Circuit Description ............................................................................................................................................... 68
Conditions for Running the DTC ................................................................................................. ....................... 68
Conditions for Setting the DTC........................................................................................................................... 68
Action Taken When the DTC Sets ................................................................................................. ..................... 68
Conditions for Clearing the DTC ........................................................................................................................ 68
Diagnostic Aids .................................................................................................................................................... 69
Test Description ................................................................................................................................................... 69
DTC P0756 Diagnostic Table..................................................................................................... .......................... 69
4.23 DTC P0757 – 2-3 Shift Solenoid Valve Performance – No Third or Fourth Gear ............................................ 70
DTC Description ................................................................................................................................................... 70
Circuit Description ............................................................................................................................................... 70
Conditions for Running the DTC ................................................................................................. ....................... 71
Conditions for Setting the DTC........................................................................................................................... 71
Action Taken When the DTC Sets ................................................................................................. ..................... 71
Conditions for Clearing the DTC ........................................................................................................................ 71
Diagnostic Aids .................................................................................................................................................... 71
Test Description ................................................................................................................................................... 71
DTC P0757 Diagnostic Table..................................................................................................... .......................... 72
4.24 DTC P0787 – 3-2 Shift Solenoid Control Circuit Low Voltage .......................................................................... 73
DTC Description ................................................................................................................................................... 73
Circuit Description ............................................................................................................................................... 73
Conditions for Running the DTC ................................................................................................. ....................... 73
Conditions for Setting the DTC........................................................................................................................... 73
Action Taken When the DTC Sets ................................................................................................. ..................... 73
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3791 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–5
Conditions for Clearing the DTC ........................................................................................................................ 73
Test Description ................................................................................................................................................... 74
DTC P0787 Diagnostic Table..................................................................................................... .......................... 74
4.25 DTC P0788 – 3-2 Shift Solenoid Control Circuit High Voltage .................................................................... ..... 77
DTC Description ................................................................................................................................................... 77
Circuit Description ............................................................................................................................................... 77
Conditions for Running the DTC ................................................................................................. ....................... 77
Conditions for Setting the DTC........................................................................................................................... 77
Action Taken When the DTC Sets ................................................................................................. ..................... 77
Conditions for Clearing the DTC ........................................................................................................................ 77
Test Description ................................................................................................................................................... 78
DTC P0788 Diagnostic Table..................................................................................................... .......................... 78
4.26 DTC P0894 – Transmission Component Slipping .................................................................................... ......... 79
DTC Description ................................................................................................................................................... 79
Circuit Description ............................................................................................................................................... 79
Conditions for Running the DTC ................................................................................................. ....................... 80
Conditions for Setting the DTC........................................................................................................................... 80
Action Taken When the DTC Sets ................................................................................................. ..................... 81
Conditions for Clearing the DTC ........................................................................................................................ 81
Diagnostic Aids .................................................................................................................................................... 81
Test Description ................................................................................................................................................... 81
DTC P0894 Diagnostic Table..................................................................................................... .......................... 81
4.27 DTC P0961 – Line Pressure Control Solenoid System Performance .............................................................. 86
DTC Description ................................................................................................................................................... 86
Circuit Description ............................................................................................................................................... 86
Conditions for Running the DTC ................................................................................................. ....................... 86
Conditions for Setting the DTC........................................................................................................................... 86
Action Taken When the DTC Sets ................................................................................................. ..................... 86
Conditions for Clearing the DTC ........................................................................................................................ 87
Diagnostic Aids .................................................................................................................................................... 87
Test Description ................................................................................................................................................... 87
DTC P0961 Diagnostic Table..................................................................................................... .......................... 87
4.28 DTC P0973 – 1-2 Shift Solenoid Control Circuit Low Voltage .......................................................................... 89
DTC Description ................................................................................................................................................... 89
Circuit Description ............................................................................................................................................... 89
Conditions for Running the DTC ................................................................................................. ....................... 90
Conditions for Setting the DTC........................................................................................................................... 90
Action Taken When the DTC Sets ................................................................................................. ..................... 90
Conditions for Clearing the DTC ........................................................................................................................ 90
Test Description ................................................................................................................................................... 90
DTC P0973 Diagnostic Table..................................................................................................... .......................... 91
4.29 DTC P0974 – 1-2 Shift Solenoid Control Circuit High Voltage .................................................................... ..... 93
DTC Description ................................................................................................................................................... 93
Circuit Description ............................................................................................................................................... 93
Conditions for Running the DTC ................................................................................................. ....................... 94
Conditions for Setting the DTC........................................................................................................................... 94
Action Taken When the DTC Sets ................................................................................................. ..................... 94
Conditions for Clearing the DTC ........................................................................................................................ 94
Test Description ................................................................................................................................................... 94
DTC P0974 Diagnostic Table..................................................................................................... .......................... 94
4.30 DTC P0976 – 2-3 Shift Solenoid Control Circuit Low Voltage .......................................................................... 96
DTC Description ................................................................................................................................................... 96
Circuit Description ............................................................................................................................................... 96
Conditions for Running the DTC ................................................................................................. ....................... 96
Conditions for Setting the DTC........................................................................................................................... 97
Action Taken When the DTC Sets ................................................................................................. ..................... 97
Conditions for Clearing the DTC ........................................................................................................................ 97
Test Description ................................................................................................................................................... 97
DTC P0976 Diagnostic Table..................................................................................................... .......................... 97
4.31 DTC P0977 – 2-3 Shift Solenoid Control Circuit High Voltage .................................................................... ... 100
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3792 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–6
DTC Description ................................................................................................................................................. 100
Circuit Description ............................................................................................................................................. 100
Conditions for Running the DTC ................................................................................................. ..................... 101
Conditions for Setting the DTC......................................................................................................................... 101
Action Taken When the DTC Sets ................................................................................................. ................... 101
Conditions for Clearing the DTC ...................................................................................................................... 101
Test Description ................................................................................................................................................. 101
DTC P0977 Diagnostic Table..................................................................................................... ........................ 101
4.32 DTC P1810, P1815 and P1816 – Transmission Fluid Pressure Position Switch........................................... 103
DTC Description ................................................................................................................................................. 103
Circuit Description ............................................................................................................................................. 103
Conditions for Running the DTC ................................................................................................. ..................... 104
DTC P1810 .................................................................................................................................................... 104
DTC P1815 .................................................................................................................................................... 104
DTC P1816 .................................................................................................................................................... 104
Conditions for Setting the DTC................................................................................................. ........................ 104
DTC P1810 .................................................................................................................................................... 104
DTC P1815 .................................................................................................................................................... 104
DTC P1816 .................................................................................................................................................... 104
Action Taken When the DTC Sets ................................................................................................. ................... 104
Conditions for Clearing the DTC ...................................................................................................................... 105
Diagnostic Aids .................................................................................................................................................. 105
Test Description ................................................................................................................................................. 105
DTC P1810, P1815 and P1816 Diagnostic Table.................................................................................... .......... 105
4.33 DTC P2763 – Torque Converter Clutch Pressure Control Solenoid Control Circuit High Voltage ............. 108
DTC Description ................................................................................................................................................. 108
Circuit Description ............................................................................................................................................. 108
Conditions for Running the DTC ................................................................................................. ..................... 108
Conditions for Setting the DTC......................................................................................................................... 108
Action Taken When the DTC Sets ................................................................................................. ................... 108
Conditions for Clearing the DTC ...................................................................................................................... 108
Test Description ................................................................................................................................................. 109
DTC P2763 Diagnostic Table..................................................................................................... ........................ 109
4.34 DTC P2764 – Torque Converter Clutch Pressure Control Solenoid Control Circuit Low Voltage .............. 111
DTC Description ................................................................................................................................................. 111
Circuit Description ............................................................................................................................................. 111
Conditions for Running the DTC ................................................................................................. ..................... 111
Conditions for Setting the DTC......................................................................................................................... 111
Action Taken When the DTC Sets ................................................................................................. ................... 111
Conditions for Clearing the DTC ...................................................................................................................... 111
Test Description ................................................................................................................................................. 112
DTC P2764 Diagnostic Table..................................................................................................... ........................ 112
4.35 DTC P2769 – Torque Converter Clutch Enable Solenoid Control Circuit Low Voltage ............................... 115
DTC Description ................................................................................................................................................. 115
Circuit Description ............................................................................................................................................. 115
Conditions for Running the DTC ................................................................................................. ..................... 115
Conditions for Setting the DTC......................................................................................................................... 115
Action Taken When the DTC Sets ................................................................................................. ................... 115
Conditions for Clearing the DTC ...................................................................................................................... 116
Diagnostic Aids .................................................................................................................................................. 116
Test Description ................................................................................................................................................. 116
DTC P2769 Diagnostic Table..................................................................................................... ........................ 116
4.36 DTC P2770 – Torque Converter Clutch Enable Solenoid Control Circuit High Voltage............................... 119
DTC Description ................................................................................................................................................. 119
Circuit Description ............................................................................................................................................. 119
Conditions for Running the DTC ................................................................................................. ..................... 119
Conditions for Setting the DTC......................................................................................................................... 119
Action Taken When the DTC Sets ................................................................................................. ................... 120
Conditions for Clearing the DTC ...................................................................................................................... 120
Test Description ................................................................................................................................................. 120
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3793 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–7
DTC P2770 Diagnostic Table............................................................................................................................. 120
4.37 DTC U0073 and U0100 – CAN-Bus No Communication With ECM (Engine Control Module)...................... 121
DTC Description ................................................................................................................................................. 121
Circuit Description ............................................................................................................................................. 121
Conditions for Running the DTC ................................................................................................. ..................... 121
Conditions for Setting the DTC......................................................................................................................... 121
DTC U0073 .................................................................................................................................................... 121
DTC U0100 .................................................................................................................................................... 121
Action Taken When the DTC Sets ................................................................................................. ................... 122
Conditions for Clearing the DTC ...................................................................................................................... 122
Test Description ................................................................................................................................................. 122
DTC P0864 and U0101 Diagnostic Table........................................................................................... ............... 122
5 Electrical Specifications ....................................................................................................................124
5.1 Transmission Fluid Temperature (TFT) Sensor Specifications ..................................................................... 124
5.2 Range Reference................................................................................................................................................ 124
5.3 Transmission Fluid Pressure Manual Valve Position Switch Logic .............................................................. 125
5.4 Transmission Range Switch Logic................................................................................................................... 125
5.5 Component Resistance ..................................................................................................................................... 126
5.6 Shift Solenoid Valve State and Gear Ratio ...................................................................................................... 126
5.7 Line Pressure ..................................................................................................................................................... 126
6 Special Tools ......................................................................................................................................127
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3800 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–14
3 Tech 2 Information
3.1 Tech 2 Diagnostics
Tech 2, with the appropriate software, cables and adapters,
when connected to the serial data link connector (DLC) can
read seat and exterior rear-view mirror serial data. The DLC
is attached to the instrument panel trim retainer beneath the
steering wheel.
1 DLC
2 DLC Adapter
3 DLC Cable
4 Tech 2
For additional general information on connecting and
operating Tech 2, refer to 0C Tech 2.
Figure 1A7 – 3
Test Modes
Tech 2 has six test modes for diagnosing the transmission. To get to these various test modes, on Tech 2 select:
Diagnostics / Model Year / Model / Vehicle Type / Transmission / Automatic Transmission
and follow Tech 2’s prompts. This will then display the following menu operations.
Diagnostic Trouble Codes
If Diagnostic Trouble Codes is selected, a selection list is displayed which contains:
• Read DTC Information – Once selected, both current and history diagnostic trouble codes (DTCs) stored in the
transmission control module will be displayed.
• Clear Engine & Transmission DTC(s) – Once selected, DTCs stored in the transmission control module (TCM)
and engine control module (ECM) memory may be cleared.
• Freeze Frame / Failure Records – Shows Freeze Frame / Failure Records information. Freeze Frame / Failure
Records are types of snapshots stored in the memory of the TCM and contain data parameters from the TCM at
the time the DTC set.
NOTE
For a complete list of TCM DTCs, refer to
4.8 Diagnostic Trouble Code List. For
further information on Tech 2 and it functions,
refer to 0C Tech 2.
Data Display
If Data Display is selected, a selection list is displayed which contains:
• Transmission Data – Once is selected, a list of transmission components and the TCM inputs are displayed along
with their status.
• TCC Data – Once selected, displays specific parameter information about the torque converter clutch controlling
devices and their circuits.
• 1-2 Shift Data – Once selected, displays specific parameter information about the 1-2 shift solenoid valve (shift
solenoid A) and its circuits.
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3801 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–15
• 2-3 Shift Data – Once this mode is selected, displays specific parameter information about the 2-3 shift solenoid
valve (shift solenoid B) and its circuits.
• 3-4 Shift Data – Once selected, displays information on 3-4 shift timing.
• 3-2 Downshift Data – Once selected, displays information on 3-2 downshift timing.
• Pressure Control Solenoid Data – Once selected, displays specific parameter information about the PC solenoid
and its circuits.
• Transmission Adapts – Once selected, it has further sub menus:
• 1-2 Adapt Data – In this mode Tech 2 continuously monitors and displays 1-2 TAP cell data parameters.
• 2-3 Adapt Data –In this mode Tech 2 continuously monitors and displays 2-3 TAP cell data parameters.
• 3-4 Adapt Data –In this mode Tech 2 continuously monitors and displays 3-4 TAP cell data parameters.
• Steady State Adapt Data – In this mode Tech 2 continuously monitors and displays Steady State TAP data
parameters.
• System Identification: In this mode, Tech 2 will display the transmission identification screen. The following items
will be displayed; Identifier, Partnumber, Hardware Partnumber, Alpha Code, Software Version Number, Software
Partnumber, VIN Digit 1-10, VIN Digit 11-17.
NOTE
Further information about the Data Display mode
and the data parameter is contained in
3.2 Data Display.
Snapshot
In this test mode, Tech 2 captures TCM data before and after a forced manual trigger.
Additional Functions
If Additional Functions is selected, a selections list is displayed which contains:
• System Identification – In this mode, Tech 2 will display the transmission identification screen. The following items
will be displayed; Identifier, Partnumber, Hardware Partnumber, Alpha Code, Software Version Number, Software
Partnumber.
Miscellaneous Tests
If Miscellaneous Functions is selected, a selections list is displayed which contains:
• TCC Solenoid –Tech 2 can command the TCC solenoid on and off. Tech 2 will display whether the TCC solenoid
is active or inactive.
• TCC PWN Solenoid – Tech 2 can command the TCC PWM solenoid on and off. Tech 2 will display whether the
TCC PWM solenoid is active or inactive and torque percentage.
• TCC Apply – Tech 2 can command the TCC on when the vehicle is above 50 km/h.
• Shift Solenoid A – Tech 2 can command the shift solenoid A (1-2 shift solenoid) on and off.
• Shift Solenoid B – Tech 2 can command the shift solenoid B (2-3 shift solenoid) on and off.
• 3/2 Downshift Solenoid – Tech 2 can command the 3/2 downshift solenoid (3-2 shift solenoid) on and off.
• Gear Control – Tech 2 can incrementally command shift solenoid states to correspond to relative gear states. The
TCM will only allow single shift increments or decrements and does not allow a shift if it causes the engine RPM to
exceed a calibrated limit.
• Pressure Control Solenoid – This function allows the user to control state of the pressure control solenoid in
increments of 100 mA.
NOTE
For operating parameters of the
Miscellaneous Test, refer to 3.4 Miscellaneous Tests.
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
Page 3803 of 6020
Automatic Transmission – 4L60E – Electrical Diagnosis Page 7C2–17
Tech 2 Parameter Units Displayed Typical Data Value
High Side Driver 1 N/A N/A
TCC Solenoid On / Off Varies
TCC PWM Solenoid Percent 0%
TCC Slip Speed RPM +/-50 RPM from Engine Speed
Transmission Range (TR) Park/Neutral, Reverse, Drive4,
Drive3, Drive2, Drive1 or Invalid Park/Neutral
TR Switch A
Open 12 V / Closed 0 V Varies
TR Switch B Open 12 V / Closed 0 V Varies
TR Switch C Open 12 V / Closed 0 V Varies
TR Switch P Open 12 V / Closed 0 V Varies
Latest Shift Seconds Varies
1-2 Shift Time Seconds Varies
2-3 Shift Time Seconds Varies
3-4 Shift Time Seconds Varies
Cruise Control Active / Inactive Varies
A/C Clutch On / Off Varies
Ignition Voltage Volts 12-14 V
Shift Pattern Normal / Power / Cruise Varies
4 Wheel Drive Low Active / Inactive Inactive
TCC Data
Once this mode is selected, displays specific parameter information about the torque converter clutch controlling devices
and their circuits.
TCC Data Parameters
For definitions of the parameters in this table, refer to 3.3 Tech 2 Data Definitions.
Tech 2 Parameter Units Displayed Typical Data Value
TCC Solenoid On / Off Varies
TCC PWM Solenoid Percent 0%
TCC Slip Speed RPM +/-50 RPM from Engine Speed
TCC Duty Cycle Circuit Open or Shorted / Short to Battery /
Okay Okay
Throttle Position
Percent Varies
Engine Speed RPM Varies
AT Input Speed N/A N/A
AT Output Speed RPM Varies
Engine Torque Nm Varies
Vehicle Speed km/h 0
Commanded Gear 1,2,3,4 1
Engine Coolant Temperature °C Varies
BACK TO CHAPTER INDEX
TO MODEL INDEX
ISUZU KB P190 2007
