JAGUAR XFR 2010 1.G Workshop Manual

Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Driveshaft - TDV6 3.0L Diesel (205-01 Driveshaft, Removal and Installation).

4. Refer to: Transmission Support Insulator - TDV6 3.0L Diesel (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8
S/C 5.0L Petrol, Removal and Installation).


5. CAUTION: Discard the nut.

Special Tool(s): 205-053













6. Special Tool(s): 303-D121 7. CAUTION: Discard the seal.
Special Tool(s): 100-012, 100-012-01, 308-375

Installation

1. CAUTIONS:


Make sure that the mating faces are clean and free of
foreign material.


Install a new seal.
Special Tool(s): 204-264








2. WARNING: Make sure that a new nut is installed.
Torque: 60 Nm










3. Refer to: Transmission Support Insulator - TDV6 3.0L Diesel (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8
S/C 5.0L Petrol, Removal and Installation).

4. Refer to: Driveshaft - TDV6 3.0L Diesel (205-01 Driveshaft, Removal and Installation).

5. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures). www.JagDocs.com

Published: 11-May-2011
Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Control Module (TCM) and Main Control Valve
Body
Removal and Installation

Removal


NOTE: The transmission control module (TCM) is part of the main control valve body and cannot be serviced separately.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Transmission Fluid Pan, Gasket and Filter (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L
Petrol, Removal and Installation).

4.
5.

6. CAUTION: Discard the component.
















7. CAUTION: Be prepared to collect escaping fluids.

NOTE: Note the position of the manual park brake
release.



















8.

9.
Installation

1. CAUTIONS:


Make sure that when fully fitted, all seals protrude by
the same amount.


Install the new seals.
Install a new seal block.








2. CAUTIONS:


Install the new seals.


Make sure that when fully fitted, all seals protrude by
the same amount.

3. CAUTION: Make sure the manual park release is
correctly engaged.
Torque: 8 Nm




















4. CAUTION: Make sure that a new component is
installed.















5.

Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L
Petrol, Removal and Installation).

8. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

9. If a new component has been installed, configure using Jaguar approved
diagnostic equipment. www.JagDocs.com

Published: 11-May-2011
Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Fluid Pan, Gasket and Filter
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Raise and support the vehicle.

3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Transmission Fluid Drain and Refill (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L
Petrol, General Procedures).

5.
6. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Installation 7. CAUTIONS:


Make sure that the area around the component is
clean and free of foreign material.


Be prepared to collect escaping fluids.

Torque: 8 Nm
1. To install, reverse the removal procedure.

Published: 11-May-2011
Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Support Insulator V8 5.0L Petrol/V8 S/C 5.0L
Petrol
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.


1. WARNING: Make sure to support the vehicle with axle stands.

Raise and support the vehicle.

2. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).







Installation

3. CAUTION: During this procedure the transmission
crossmember is removed, make sure the transmission is
correctly supported to avoid damaging associated
components.

Torque: 48 Nm











4. NOTE: Do not disassemble further if the component is
removed for access only.

Torque: 55 Nm
1. To install, reverse the removal procedure.
