JAGUAR XFR 2010 1.G Workshop Manual

10.























11. NOTE: Note the position of the wiring harnesses to
aid installation.

12.



































13. CAUTION: Take extra care not to damage the clips.



































NOTE: Note the position of the wiring harnesses to
aid installation.

17.
18.
19.













































WARNING: Do not probe supplemental restraint
system (SRS) electrical connectors. www.JagDocs.com

Installation 20.


1. CAUTION: The front passenger seat occupant
classification sensor is available only as a service kit. No
attempt should be made to replace individual components.
Failure to follow this instruction may result in personal
injury.

2. NOTES:


Make sure that new hog rings are installed.


Use hog ring pliers to close the hog rings. Do not use
any other tool. The hog rings must be closed to overlap as
illustrated.

















3.
4.

8. NOTE: Make sure that the harness is routed to the
position noted on removal.






















9.

10.
11. Torque: 4 Nm

























NOTE: Make sure that the harness is routed to the
position noted on removal. www.JagDocs.com

12.
















13.
14. CAUTION: Make sure that the wiring harness is routed
above the drive bar as shown, to avoid damage to the
wiring harness during movement of the front seat.














NOTES:


An audible click is heard when the clips are fully
latched.


Make sure the electrical connector is securely
connected.









Torque: 1.3 Nm
