JAGUAR XFR 2010 1.G Workshop Manual

Safety Belt System - Front Safety Belt Retractor
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011


1. NOTE: Right-hand shown, left-hand similar.























2. NOTE: Right-hand shown, left-hand similar.
Torque: 40 Nm
















3. Refer to: B-Pillar Upper Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

6. Torque: 40 Nm

Installation


1. CAUTION: Fixings must be started by hand to avoid damaging
threads.
To install, reverse the removal procedure.

Safety Belt System - Rear Center Safety Belt Retractor
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Parcel Shelf (501-05 Interior Trim and Ornamentation, Removal and Installation).




Installation

2. Torque: 40 Nm
1. To install, reverse the removal procedure. www.JagDocs.com

Safety Belt System - Rear Safety Belt Buckle
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.


1. Published: 11-May-2011
















Installation
















2. Torque: 40 Nm
1. To install, reverse the removal procedure.

Safety Belt System - Rear Safety Belt Retractor
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: C-Pillar Lower Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).







Installation

2. Torque: 40 Nm
























3.

1. To install, reverse the removal procedure.

Safety Belt System - Safety Belt Shoulder Height Adjuster
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: B-Pillar Upper Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

2. Torque: 40 Nm














Installation















3. Torque: 25 Nm
1. To install, reverse the removal procedure.

Passenger air bag module retaining nuts 6 - 55 Passenger air bag earth lead retaining bolt 9 - 80 Restraints control module (RCM) retaining nuts 10 - 89 Side air curtain module inflator retaining bolts 9 - 80 Side air curtain module tether straps retaining bolts 9 - 80 Side air bag module retaining nuts 7 - 62 Side impact sensor retaining bolt 10 - 89 Front crash sensor retaining bolt 10 - 89 Clock spring retaining screws 5 - 44

1 LH (left-hand) curtain airbag 2 Front passenger airbag 3 RH (right-hand) curtain airbag 4 Passenger thorax airbag 5 Front passenger seat safety belt pretensioner 6 RCM (restraints control module) 7 Driver's seat safety belt pretensioner 8 Driver's thorax airbag 9 Driver's airbag www.JagDocs.com

1 Occupant classification system pressure pad (NAS only) 2 Safety belt tension sensor (NAS only) 3 Occupant detection system pad (all, except NAS) 4 Occupant classification system control module (NAS only) 5 RH side impact sensor (pressure sensor) 6 RH rear impact sensor 7 LH rear impact sensor 8 Passenger airbag deactivation LED (light emitting diode) 9 Driver's seat position sensor 10 LH side impact sensor (pressure sensor) 11 Instrument cluster 12 LH front impact sensor 13 RH front impact sensor
