JAGUAR XFR 2010 1.G Workshop Manual

18.























19.
20. WARNING: Do not probe supplemental restraint
system (SRS) electrical connectors.




















21.
Refer to: Front Seat Backrest Cover (501-10 Seating, Removal and Installation).

22. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Supplemental Restraint System - Passenger Air Bag Module
Removal and Installation Published: 11-May-2011


Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Steering Wheel (211-04 Steering Column, Removal and Installation).

3. Refer to: Driver Side Register (412-01 Climate Control, Removal and Installation).

4. Refer to: Information and Entertainment Display (415-01A Information and Entertainment System, Removal and Installation).

5. Refer to: Instrument Panel Speaker (415-01A Information and Entertainment System, Removal and Installation).

6. Refer to: A-Pillar Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

7. Refer to: Audio and Climate Control Assembly (415-01A Information and Entertainment System, Removal and Installation). 211-326
Locking Tool, Clockspring Special Tool(s)

www.JagDocs.com

12.


































13. CAUTION: Take extra care not to damage the
instrument cluster face.

































Special Tool(s): 211-326

19.
















20.
21. CAUTION: Fixings must be started by hand to avoid
damaging threads.
Torque:
M8 2.5 Nm T27 9 Nm www.JagDocs.com

22.























23.
CAUTION: Fixings must be started by hand to avoid
damaging threads.
Torque:
M8 2.5 Nm T27 9 Nm
