Engine JAGUAR XFR 2010 1.G Workshop Manual

5. CAUTION: Install new high-pressure fuel supply lines.
NOTES:
Engine shown removed for clarity.

Remove and discard the blanking caps.

Install the bolt and unions fully finger tight before final
tightening.






















6. CAUTION: Care must be taken when positioning the fuel rail
high-pressure fuel pump cover to one side.

NOTE: Fuel rail high-pressure fuel pump cover shown removed for
clarity.
Torque: 12 Nm





7. Lower the vehicle.
8. NOTES:

Do not tighten at this stage.

Remove and discard the blanking caps.








9. WARNING: Do not work on or under a vehicle supported only by a jack. Always
support the vehicle on safety stands.

Raise and support the vehicle.


10.





































11. CAUTION: Lubricate only the union threads with clean engine oil.

NOTE: Engine shown removed for clarity.
Torque: Unions (1) 21 Nm M6 (2) 11 Nm M8 (3) 25 Nm M5 nut (4) 6 Nm


























NOTE: Engine shown removed for clarity.
Torque: 21 Nm www.JagDocs.com

12.
13.
14. NOTES:

Install the bolt and unions finger tight before final tightening.

Remove and discard the blanking caps.
Torque: Unions 21 Nm M6 11 Nm














Torque: 21 Nm


















NOTE: Engine shown removed for clarity.
Torque: M10 29 Nm M6 11 Nm

15.

















16. NOTE: Engine shown removed for clarity.
















Torque: 25 Nm
















Left-hand drive vehicles

17. Torque: 100 Nm

18. Torque: 35 Nm










All vehicles

19. Refer to: Generator - V8 5.0L Petrol (414-02C Generator and Regulator - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation).

20. Refer to: Engine Mount RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

21. Lower the vehicle.

22.


















23.


















NOTES:

Lubricate
the
union
threads
with
clean
engine
oil.

Do
not tighten
at this
stage.

Remove
and
discard
the
blanking
caps.

Bolts 8 Nm










25. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

26.
27. 28.













29. Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and

Fuel Charging and Controls - V8 S/C 5.0L Petrol - Throttle Body
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 08-Nov-2013


1. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

2. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

3. Refer to: Cooling System Partial Draining, Filling and Bleeding (303-03E,
General Procedures).

4. Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).

5. Refer to: Air Cleaner Outlet Pipe (303-12E, Removal and Installation).

6.

7. CAUTIONS:


Make sure that the accessory drive belt is correctly
aligned to the pulleys. Failure to follow this instruction may
result in damage to the vehicle.


Clean and inspect the accessory drive belt pulleys for
damage.
NOTES:


Some variation in the illustrations may occur, but the
essential information is always correct.


Engine shown removed for clarity.


Note the fitted position.

Installation

1. To install, reverse the removal procedure.

Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Idler Pulley
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).







Installation

4. NOTES:


Note the fitted position.


Engine shown removed for clarity.



















5. Torque: 40 Nm

1. CAUTION: Make sure the supercharger belt is correctly aligned to the
pulleys. Failure to follow this instruction may result in damage to
the vehicle.

To install, reverse the removal procedure.

Published: 11-May-2011
Starting System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Starting System - Component Location
Description and Operation


NOTE: Installation on supercharged engine shown, installation on naturally aspirated engine similar.
COMPONENT LOCATION
