JAGUAR XFR 2010 1.G Workshop Manual

3. NOTE: Make sure correct alignment is maintained.

Slowly push the bush into the shock absorber until the tool
reaches the stop.










4. Install the shock absorber and spring assembly.
For additional information, refer to: Shock Absorber and Spring Assembly (204-02 Rear Suspension, Removal and Installation).

Rear Suspension - Rear Stabilizer Bar
Removal and Installation Published: 06-Jun-2013



Removal

1. Disconnect the battery ground cable.
For additional information, refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Remove both rear wheels and tires.
For additional information, refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation).

4. Drain the fuel tank.
For additional information, refer to: Fuel Tank Draining (310-00 Fuel System - General Information, General Procedures).

5. Remove the exhaust system.
For additional information, refer to: Front Muffler (309-00B Exhaust System - V6 3.0L Petrol, Removal and Installation).


6. CAUTION: Always plug any open connections to
prevent contamination.
NOTES:


To prevent the loss of brake fluid, using the special
tool apply the brake pedal and set to 40mm ( 1.6 in ) below
the rest position.


RH illustration shown, LH is similar.
Disconnect the brake hose from the brake caliper.
Using the special tool, press and hold the brake
pedal.
Remove and discard the two sealing washers. Powertrain Assembly Jack, HTJ
1200-2 Special Tool(s)

7. NOTE: Left-hand shown, right-hand similar.

Release the brake caliper.
Remove and discard the 2 bolts.
Tie the brake caliper aside.












8. NOTE: Left-hand shown, right-hand similar.
Disconnect the rear wheel speed sensor.











9. Disconnect the electronic parking brake actuator electrical
connector.













10. NOTE: Left-hand shown, right-hand similar.

Disconnect both parking brake cables from the rear brake
calipers.

11.















12.
13.
14. NOTE: Left-hand shown, right-hand similar.

Detach the shock absorber.













Detach the fuel filler hose.

















CAUTION: Under no circumstances must the flexible
coupling (or its fixings) be loosened or removed from the
driveshaft.
Detach the driveshaft from the rear drive axle flange.
Mark the position of the driveshaft in relation to the
rear drive axle flange.
Mark the position of the balance nut in relation to the
rear drive axle flange. (if fitted).
Mark the position of each nut and bolt in relation to the
driveshaft flexible joint.







NOTE: Left-hand shown, right-hand similar.

Remove the rear subframe reinforcement plate retaining bolts. www.JagDocs.com

15.

16.
17.
18. Install the special tool to support the rear subframe.

















NOTE: Left-hand shown, right-hand similar.
Remove the rear subframe rear retaining bolt.














NOTE: Left-hand shown, right-hand similar.
Remove the rear subframe front retaining bolt.












Remove the rear subframe.

2. Install new nuts to the stabilizer bar links.
Tighten to 48 Nm.















3. Install the rear subframe.
4. NOTE: Left-hand shown, right-hand similar.
Loosely install the rear subframe front bolt.













5. Loosely install the rear subframe rear bolt.

6. NOTE: Left-hand shown, right-hand similar.

Loosely install the rear subframe reinforcement plate bolts.













7. Tighten the subframe bolts.
Tighten to 80 Nm + 240°.















8. Remove the special tool.
9. Tighten the rear subframe reinforcement plate retaining bolts.
Tighten to 47 Nm.

10.















11.
12. NOTE: Left-hand shown, right-hand similar.

Install the shock absorber.
Tighten to 133 Nm.














NOTE: Install the components to their original fitted
positions.
Attach the driveshaft to the rear drive axle flange.












Attach the fuel filler hose to the fuel tank.













13.
Connect both park brake cables to the rear brake calipers. www.JagDocs.com
