JAGUAR XFR 2010 1.G Workshop Manual

5. CAUTION: Be prepared to collect escaping fluids.


NOTE: Make sure the extended pipe is not kinked or
twisted and is correctly secured with hose clips.

Attach a suitable pipe to the power steering return hose to
allow the fluid to drain.









6. NOTES:


The suitable funnel should have the a capacity of 4
litres and O-ring seal


The suitable funnel must be tightly sealed to the
power steering fluid reservoir to avoid fluid leakage.

Install a suitable funnel onto the power steering fluid
reservoir.












7. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle with the wheels just clear of the ground.

8. CAUTIONS:


Steps 8 and 9 must be carried out within 2 - 3 seconds of each
other. Failure to follow this instruction may result in damage to the
power steering system.


Be prepared to collect escaping fluids.

Using the suitable funnel, top up the power steering system with the
specified fluid. Make sure the fluid level is maintained at two thirds full
in the funnel.

9. CAUTIONS:


Be prepared to collect escaping fluids.


Do not allow the power steering fluid level in the
power steering fluid reservoir to fall below the minimum
power steering fluid level. Failure to follow this instruction
may result in damage to the power steering system.


Make sure the engine is switched off as soon as the
full 4 litres of power steering fluid has entered the power
steering fluid reservoir.
Flush the power steering system.
Start the engine
With assistance turn the steering slowly lock to lock
3 times at approximately 1 revolution every 5
seconds.
Continue to flush the power steering system until 4
litres of power steering fluid has been added to the
power steering reservoir. This should take
approximately 30 seconds.


10.

























11. CAUTION: Be prepared to collect escaping fluids.
Remove the suitable funnel.























CAUTION: Be prepared to collect escaping fluids.

Remove the suitable pipe to the power steering return
hose.












12.
CAUTION: Be prepared to collect escaping fluids.

NOTE: Note the orientation of the clip.

If a quick release coupling is fitted to the power steering return hose,
connect the power steering fluid return hose to the coupling by installing
the clip.

13. Install a new power steering fluid reservoir. For additional information,
refer to: (211-02 Power Steering)
Power Steering Fluid Reservoir - V6 3.0L Petrol (Removal and Installation),
Power Steering Fluid Reservoir - TDV6 3.0L Diesel (Removal and Installation).

Published: 11-May-2011
Steering System - General Information - Power Steering System Filling V8 5.0L Petrol/V8 S/C 5.0L Petrol
General Procedures

Draining

1.















2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).


4. CAUTION: Be prepared to collect escaping fluids.


NOTE: Remove and discard the O-ring seals. www.JagDocs.com

5. CAUTIONS:


Make sure that the area around the component is
clean and free of foreign material.


The blanking plugs must not be removed until the
power steering pipes are ready to be connected.









Filling

1. CAUTIONS:


Make sure that the area around the component is
clean and free of foreign material.


The blanking plugs must not be removed until the
power steering pipes are ready to be connected.









2. CAUTIONS:


Make sure that the area around the component is
clean and free of foreign material.


Install new o-ring seals
Torque: 20 Nm









3. Lower the vehicle.

4. CAUTION: Fluid must always be present in the
reservoir during bleeding.
Fill the power steering reservoir.










5. Install the vacuum hand pump to the power steering fluid reservoir.


6. NOTE: Apply the maximum vacuum possible on the reservoir for 1
minute.
Apply a vacuum to the power steering fluid reservoir.

7. Remove the vacuum hand pump from the power steering fluid reservoir.


8. CAUTION: Fluid must always be present in the
reservoir during bleeding.
Fill the power steering reservoir.










9.
Run the engine for 30 seconds.
Turn the steering fully lock-to-lock, stop the engine.

10. Install the vacuum hand pump to the power steering fluid reservoir.


11. NOTE: Apply the maximum vacuum possible on the reservoir for 1
minute.
Apply a vacuum to the power steering fluid reservoir.

12. Remove the vacuum hand pump from the power steering fluid reservoir.

13. CAUTION: Fluid must always be present in the
reservoir during bleeding.
Fill the power steering reservoir.










14.
Run the engine for 30 seconds.
Turn the steering fully lock-to-lock, stop the engine.

15. Install the vacuum hand pump to the power steering fluid reservoir.


16. NOTE: Apply the maximum vacuum possible on the reservoir for 1
minute.
Apply a vacuum to the power steering fluid reservoir.

17. Remove the vacuum hand pump from the power steering fluid reservoir.


18. CAUTION: Fluid must always be present in the
reservoir during bleeding.
Fill the power steering reservoir.










19.
Run the engine for 30 seconds.
Turn the steering fully lock-to-lock, stop the engine.

Installation).

Lower steering column slider pinch bolt 35 26 - Lower steering column to steering gear pinch bolt 35 26 - Power steering control valve actuator 2 - 18 Power steering fluid cooler retaining bolts 7 - 62 Power steering pump pulley retaining bolts 20 25 - Power steering pump retaining bolts - All except vehicles with diesel engine 25 18 - Power steering pump retaining bolts - Vehicles with diesel engine 22 16 - Power steering pump to steering gear pressure line 25 18 - Steering gear retaining bolts 100 74 - Steering gear supply and return lines 10 - 89 www.JagDocs.com

Power Steering - Power Steering - Component Location
Description and Operation

Published: 11-May-2011














POWER STEERING-COMPONENTLOCATION5.0LV8
ItemDescriptionNOTE:Naturallyaspirated5.0LV8shown,Supercharged5.0LV8similar1Powersteeringfluidcooler2Tie-rodend(2off)3Tie-rod(2off)4Powersteeringpump5Lowpressurefluidreturnhose6Powersteeringfluidreservoir7Feedpipetopump8Highpressurefeedpipetosteeringgear9Servotronictransducervalve10Valveunit11Mountingbolt(3off)12Steeringgear
