KIA CARNIVAL 2007 Workshop Manual

6.Pull the rear cable (A) and draw the cable clip (B) to bottom of roller hinge post and then remove the rear cable
(A).
7.Remove the roller hinge bracket assembly (A) as below.
8.Remove the front cable (A) from center roller hinge (B).
9.Loosen the bolts (2EA) and remove the rear pulley bracket (A). And then remove the front pulley bracket (B) after
loosening the mounting bolts (2EA) and nut (1EA).

TORQUE : 7 - 11 N.m (0.7 - 1.1 Kg.m)
10.Loosen the mounting bolt (1EA) and nuts (2EA). And then remove the power sliding door drive unit assembly after
removing the front cable.
TORQUE : 7 - 11 N.m (0.7 - 1.1 Kg.m)
11. Installation is the reverse of removal.
12. When installation, check the grease on the center roller hinge barrel and club contact part (A).
a.A learn cycle must be performed whenever the power is removed.
b. Check the normal operation whenever a power sliding door component is removed or replaced. If the
chime sound is heard, check the DTC, wiring harness and cable connections.

Power Sliding Door Control Module

2007 > 2.7L V6 GASOLINE >
REPLACEMENT
1.Disconnect the negative ( - ) battery terminal..
2. Remove the rear trim panel (Refer to the Body group - interior trim)
3. Remove the connectors and mounting bolts (2EA) from the power sliding door unit(A). And then remove the power
sliding door control module (B).
TORQUE 0.25 - 0.35N.m(0.025- 0.035Kg.m)
4.Installation is the reverse of removal.
a.A learn cycle must be performed whenever the power is removed.
b. Check the normal operation whenever a power sliding door component is removed or replaced. If the
chime sound is heard, check the DTC, wiring harness and cable connections.

Power Sliding Door Buzzer

2007 > 2.7L V6 GASOLINE >
REPLACEMENT
1.Remove the rear side trim (Refer to the Body group - interior trim).
2. Disconnect the sliding door chime connector (A) from chime (B).
3.Remove the chime from drive unit and replace it with a new one.

Detent Switch

2007 > 2.7L V6 GASOLINE >
INSPECTION
1.Detent switch detect the latch position within latch assembly.
2.Check the power sliding door control module input/output value by using the diagnostic tool.
3. When checking the detent switch, select a vehicle type and "POWER SLIDING/TAIL GATE" menu.
4.Select the "POWER SLIDING DOOR".
5.Select the detent sensor output. And then check the detent switch output with operating power sliding door.

※ Above voltage and numerical value may be different from the real value.
6. If there is no change in output, change the latch assembly.

Latch Switch
