LAND ROVER FREELANDER 2001 Workshop Manual

HARNESSES
86-7-16 REPAIRS
Harness - rear door
$% 86.70.66
Remove
1.Remove rear door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
rear door.
2.Disconnect multiplugs from door latch and
window lift motor.
3.Release 7 clips securing door harness to door.
4.Release 'B/C' post upper finisher from 6 clips
and position aside.5.Release multiplug from location at base of 'B/C'
post and disconnect multiplug.
6.Release harness sheath from 'B/C' post and
pull door harness through 'B/C' post.
7.Release sheath from front edge of door and pull
harness into door.
8.Remove door harness.
Refit
1.Position harness to door and secure with clips.
2.Connect multiplugs to door latch and window lift
motor.
3.Feed harness through front edge of door and
secure sheath to door.
4.Feed harness into 'B/C' post and secure sheath
to 'B/C' post.
5.Connect and secure multiplug at base of 'B/C'
post.
6.Position 'B/C' post upper finisher and secure
with clips.
7.Fit rear door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
rear door.

DRIVER CONTROLS
REPAIRS 86-8-1
DRIV ER CONTROLS REPAIRS
Switch - remote control - audio system
$% 86.50.13
Remove
1.Remove drivers airbag.

+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - steering wheel.
2.Release remote control switch leads and
disconnect multiplug.
3.Remove 2 screws securing remote control
switch and remove switch.
Refit
1.Fit remote control switch and secure with
screws.
2.Connect switch multiplug and fit leads in clip.
3.Fit drivers airbag.

+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - steering wheel.
Switch - park distance control (PDC) -
from 04 MY
$% 86.54.02
Remove
1.Release 2 clips and remove fascia mounted
switch cover.
2.Remove 2 screws securing switch carrier to
fascia.
3.Release switch carrier from fascia and
disconnect PDC multiplug.
4.Remove switch assembly from carrier.
Refit
1.Fit PDC switch to carrier.
2.Connect multiplug to PDC switch.
3.Secure switch carrier to fascia with screws.
4.Fit and secure switch cover.

DRIVER CONTROLS
86-8-2 REPAIRS
Control unit (ECU) - parking aid - from
04MY
$% 86.54.10
Remove
1. 3 door models: Remove RH rear lower quarter
trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.
2. 5 door models: Remove RH rear lower quarter
trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
3.Disconnect 2 multiplugs from parking aid ECU.
4.Remove 2 nuts securing parking aid ECU to
mounting bracket and remove ECU.
Refit
1.Position parking aid ECU to mounting bracket,
fit nuts and tighten to 4 Nm (3 lbf.ft).
2.Connect multiplugs to parking aid ECU.
3.Fit RH rear lower quarter trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.
Sensor - parking aid - rear - from 04MY
$% 86.54.14
Remove
1.Remove rear bumper assembly.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper valance - rear - from 04MY.
2.Disconnect multiplug from parking aid sensor.
3.Release 2 retaining clips and remove parking
aid sensor from finisher.
4.Remove parking aid sensor finisher from
bumper valance.
Refit
1.Fit parking aid sensor finisher to bumper
valance.
2.Fit parking aid sensor to finisher and connect
multiplug.
3.Fit rear bumper assembly.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper valance - rear - from 04MY.
M86 6118

DRIVER CONTROLS
REPAIRS 86-8-3
Sounder - parking aid - rear - from 04MY
$% 86.54.19
Remove
1. 3 door models: Remove RH rear lower quarter
trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.
2. 5 door models: Remove RH rear lower quarter
trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
3.Disconnect multiplug from parking aid sounder.
4.Remove 2 nuts securing parking aid sounder to
mounting bracket and remove sounder.
Refit
1.Position parking aid sounder to mounting
bracket and secure with nuts.
2.Connect multiplug to parking aid sounder.
3. 5 door models: Fit RH rear lower quarter trim
casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
4. 5 door models: Fit RH rear lower quarter trim
casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.
Switch - handbrake warning
$% 86.65.45
Remove
1.Remove rear console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - rear.
2.Disconnect Lucar from handbrake warning
switch.
3.Release switch from handbrake.
Refit
1.Fit switch to handbrake and connect Lucar.
2.Fit rear console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - rear.
M86 6117

DRIVER CONTROLS
86-8-4 REPAIRS
Switch - hazard warning - from 04MY
$% 86.65.50
Remove
1.Remove fascia cup holder.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Cup holder - fascia - from 04MY.
2.Release hazard switch from fascia carrier.
3.Disconnect multiplug and remove hazard
warning switch.
Refit
1.Position hazard warning switch and connect
multiplug.
2.Fit switch to fascia carrier.
3.Fit fascia cup holder.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Cup holder - fascia - from 04MY.
Cigar lighter - front
$% 86.65.60
Remove
1.Remove front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
2.Remove cigar lighter element.
3.Remove bulb holder from lighter.
4.Release cigar lighter body from console and
remove.
Refit
1.Fit and secure cigar lighter body to console.
2.Fit bulb holder to lighter.
3.Fit lighter element.
4.Fit front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.

DRIVER CONTROLS
REPAIRS 86-8-5
Switch - control - exterior mirror
$% 86.65.75
Remove
1.Release mirror switch from fascia and
disconnect multiplug.
Refit
1.Position switch, connect multiplug and secure
switch to fascia.

NAVIGATION SYSTEM
REPAIRS 87-1
NAVIGATION SYST EM REPAIRS
Interface unit - remote control
$% 86.53.15
Remove
1.Remove front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
2.Release interface ECU from bracket,
disconnect multiplug and remove ECU.
Refit
1.Secure interface ECU in bracket and connect
multiplug.
2.Fit front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
Display unit - navigation system
$% 86.53.20
Remove
1.Fit tool LRT-86-009 into slots, ensuring correct
handed tool is in correct slot.
The tools are stamped with 'TOP L' and 'TOP
R', ensure the stampings are facing upwards
when removing the unit.
2.Pull unit from fascia.
3.Disconnect 3 multiplugs and 2 coax cables,
remove unit.
4.Push retaining clips inwards and remove keys.
Refit
1.Position unit to fascia, connect multiplugs and
coax cables.
2.Slide unit in fascia until retaining clips engage.
3.Enter security code, check system is
operational.
M86 5745
M86 5741

INSTRUMENTS
REPAIRS 88-1
INS TRUMENTS REPAIRS
Clock
$% 88.15.07
Remove
1.Remove clock finisher from fascia.
2.Remove 2 screws securing clock to fascia.
3.Release clock to gain access to multiplug.
4.Disconnect multiplug and remove clock.Refit
1.Position clock to fascia and connect multiplug.
2.Fit and tighten screws securing clock to fascia.
3.Fit clock finisher to fascia.
