Speaker - tweeter - front
$% 86.50.34
Remove
1.Release cheater panel from front door.
2.Disconnect Lucars from tweeter speaker.
3. 04MY: Disconnect multiplug from tweeter
speaker.
4.Remove cheater panel.
5.Remove tweeter.Refit
1.Fit tweeter to cheater panel.
2.Position cheater panel and connect Lucars.
3. 04MY: Position cheater panel and connect
tweeter speaker multiplug.
4.Fit cheater panel to door.

IN CAR ENTERTAINMENT
REPAIRS 86-6-9
Speaker - tweeter - rear - 3 door
$% 86.50.35
The procedure to remove the tweeter on 5 door
models is the same as shown for a 3 door, except
that the rear door trim casing has to be removed and
not the body side rear trim casing.
Remove
1.Remove body side rear trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - body side - rear - 3
door.
2.Remove ring securing tweeter and remove
tweeterRefit
1.Fit tweeter, ensuring lug on tweeter is aligned
with cut-out in trim casing, fit and tighten
securing ring.
2.Fit body side rear trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - body side - rear - 3
door.

IN CAR ENTERTAINMENT
86-6-10 REPAIRS
Amplifier - power
$% 86.50.36
Remove
1.Slide LH front seat fully rearwards.
2.Remove 2 bolts securing power amplifier cradle
to bracket.
3.Withdraw power amplifier and cradle assembly,
disconnect multiplug from power amplifier and
remove assembly.4.Remove 3 bolts securing power amplifier to
cradle and remove power amplifier.
Refit
1.Locate power amplifier to cradle and fit and
tighten bolts.
2.Connect multiplug and locate power amplifier
and cradle assembly to bracket.
3.Fit and tighten bolts securing cradle to bracket.
4.Position seat to mid position.

IN CAR ENTERTAINMENT
REPAIRS 86-6-11
Sub-woofer assembly
$% 86.50.51
Remove
1.Release 2 turnbuckles and raise luggage
compartment companion box lid.
2.Remove 16 screws securing sub-woofer cover
and remove the sub-woofer cover.3.Identify position of Lucars for refitting and
disconnect 4 Lucar connectors from the sub-
woofer.
4.Remove 4 nuts securing sub-woofer and
remove the sub-woofer.
Refit
1.Fit sub-woofer and tighten nuts to 2 Nm (1.5
lbf.ft).
2.Connect Lucar to sub-woofer.
3.Fit sub-woofer cover and secure with screws.
4.Close companion box and secure with
turnbuckles.
M86 5973

IN CAR ENTERTAINMENT
86-6-12 REPAIRS
Coaxial lead - extension
$% 86.50.65
Remove
1.Remove radio.

+ IN CAR ENTERTAINMENT,
REPAIRS, Radio - up to 04MY.
2.Disconnect coaxial link lead from aerial lead.
3.Release coaxial link lead from harness.
4.Remove coaxial link lead.
Refit
1.Fit coaxial link lead and secure to harness.
WARNING: Ensure link lead does not foul
control pedals or steering column.
2.Connect link lead to aerial lead.
3.Fit radio.

+ IN CAR ENTERTAINMENT,
REPAIRS, Radio - up to 04MY.

HARNESSES
REPAIRS 86-7-1
HARNESSES REPAIRS
Fuse box - passenger compartment
$% 86.70.01
Remove
1.Disconnect battery earth lead.
2.Open glove box.
3.Remove hinge pins and lid.
4.Remove fuse box cover.
5.Remove relays from fuse box mounting plate.
6.Remove bolt securing fuse box mounting plate
to steering column bracket.
7.Remove 2 bolts securing mounting plate to
body.
8.Remove 2 bolts securing fuse box to mounting
plate.
9.Disconnect 3 multiplugs from CCU in rear of
fuse box.
10.Release fusebox and disconnect 8 multiplugs.
11.Remove fusebox.
12.Remove fuses and relays from fuse box.Refit
1.Identify and fit fuses.
2.Fit relays.
3.Fit fuse box.
4.Connect multiplugs to fusebox.
5.Connect multiplugs to CCU.
6.Fit bolts securing fuse box to mounting plate
and tighten to 8 Nm (6 lbf.ft).
7.Fit bolts securing fuse box mounting plate to
body and tighten to 8 Nm (6 lbf.ft).
8.Fit relays to mounting plate.
9.Fit fuse box cover.
10.Fit glove box lid and hinge pins.
11.Close lid.
12.Connect battery earth lead.

HARNESSES
86-7-2 REPAIRS
Harness - main
$% 86.70.07
Remove
1.Make the SRS system safe.

+ GENERAL INFORMATION,
Supplementary restraint system
precautions.
2.Remove carpet.
3.Remove engine acoustic cover.

+ ENGINE - Td4, REPAIRS, Cover -
engine acoustic - Up to 02.5 Model Year.
4.Remove windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
5.Pull reservoir harness and washer tubes into
engine bay.
6.Remove nut and release earth header from RH
inner wing.
7.Disconnect multiplug from ABS modulator.
8.Disconnect multiplug from RH ABS speed
sensor and release harness from clips.
9.Disconnect 2 multiplugs from RH headlamp
and headlamp levelling motor.10.Disconnect multiplugs from horn, refrigerant
pressure sensor and compressor.
11.Remove jack from holder in engine bay.
12.Disconnect multiplug from brake fluid low level
indicator switch.
13.Disconnect multiplug from bonnet switch.
14.Remove bolt and 2 nuts securing PAS and
coolant reservoir support bracket and position
aside.
15.Release 5 harness retaining clips.
16.Release front screen wash tube from harness
and position aside.
17.Remove nut securing earth header to bulk head
and remove earth header.

HARNESSES
REPAIRS 86-7-3
18.With assistance feed harness through bulk
head into vehicle.
19.Remove battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
20.Remove 3 cable ties and release bonnet
release cable from harness.
21.Disconnect multiplug from cooling fan pack and
2 multiplugs from cooling fans.
22.Release 4 clips securing harness to cooling
fans and release harness from cooling fans.
23.Disconnect 2 multiplugs from LH headlamp and
headlamp levelling motor.
24.Disconnect multiplug from harness.25.Remove nut securing LH earth header and
release header.
26.Disconnect multiplug from front LH ABS speed
sensor.
27.Disconnect Lucar connector from starter motor.
28. Models with cruise control:Disconnect
multiplug from cruise control vacuum pump.
29.Release 5 harness retaining clips.
30.Disconnect 2 engine harness to main harness
multiplugs.
31.Release 5 Allen screws securing 'E' box cover
to 'E' box.
32.Remove 'E' box cover

HARNESSES
86-7-4 REPAIRS
33. Automatic gearbox only: Disconnect
multiplug from automatic gearbox ECU.
34.Disconnect 2 engine harness to main harness
multiplugs.
35.Disconnect 'E' box temperature sensor
multiplug.
36.Disconnect 'E' box cooling fan multiplug.
37.Remove fuse box cover.
38.Remove 2 bolts securing battery connections to
fuse box and disconnect multiplug from fuse
box.
39.Remove 3 nuts securing fuse box to brackets.40.Disconnect 6 multiplugs from the underside of
fusebox.
41.Disconnect multiplug from inertia switch.
42.Release 2 fixings securing harness to LH side
of engine bay.
43.Remove air intake plenum.

+ HEATING AND VENTILATION,
REPAIRS, Plenum - air intake.

HARNESSES
REPAIRS 86-7-5
44.Disconnect multiplug from wiper motor and pull
into engine bay.
45.With assistance pull main harness into vehicle
interior.
46.Remove 6 screws securing front mud flaps and
remove mud flaps.
47.Release rear edges of front wheel arch liners.48.Release side repeater lamps, disconnect
multiplugs and remove lamps.
49.Remove 3 bolts from passenger compartment
fuse box and pull fuse box forward.
50.Release and disconnect multiplug from RH 'A'
post.
51.Disconnect coaxial cable.
52.Release relays from fuse box bracket.
