LAND ROVER FREELANDER 2001 Workshop Manual

HARNESSES
86-7-6 REPAIRS
53.Release fuse box, disconnect 11 multiplugs
and remove fuse box.
54.Disconnect multiplug from steering column
switch.
55.Release harness clip from steering column.
56.Disconnect multiplug from throttle position
sensor.
57.Disconnect multiplugs from brake light switch
and brake pedal position switch.58.Disconnect multiplug from airbag ECU.
59.Remove airbag ECU securing bolt and release
earth lead.
60.Remove nut from earth header and release
header from floor tunnel.

HARNESSES
REPAIRS 86-7-7
61.Disconnect heated oxygen sensor multiplug.
62. Automatic gearbox only: Disconnect
multiplugs from gear selector.
63.Disconnect multiplug from accelerometer.
64. Manual gearbox only: Disconnect multiplug
from gear lever hill descent switch.
65.Disconnect Lucar from handbrake switch.
66.Release 2 relays from bracket and remove
bracket.
67.Release 4 clips securing harness to air ducting.
68.Remove nut from rear heater ducting and
remove ducting.
69.Remove 4 nuts securing steering column to
bracket and lower column.
70.Remove face level vent ducting to access main
harness clips.71.Disconnect multiplug from window lift ECU.
72.Remove nut securing earth header to RH 'A'
post and release header.
73.Release multiplugs and earth header from LH
lower 'A' post.

HARNESSES
86-7-8 REPAIRS
74.Release all harness clips from interior of
vehicle.
75.Release and disconnect multiplugs from base
of 'B/C' posts.
76.Remove luggage compartment carpet.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Carpet - luggage compartment.77.Remove 6 screws from fuel pump access cover
and remove cover.
78.Disconnect multiplug from fuel pump.
79.Release both rear ABS speed sensor
harnesses and disconnect multiplugs.
80.Pull harness into vehicle interior.

HARNESSES
REPAIRS 86-7-9
81.Release and disconnect rear window lift and
wash/wipe relays.
82.Disconnect 3 multiplugs from tail door harness.
83.Disconnect rear screen washer tube.
84.Disconnect multiplug from towing electrics.
85.Remove nut from RH rear earth header and
release header.86.Remove 3 Torx screws securing RH tail lamp to
body.
87.Disconnect multiplugs and remove tail lamp.
88.Disconnect multiplugs from LH tail lamp.
89.Remove nut from LH rear earth header and
release header.

HARNESSES
86-7-10 REPAIRS
90.Remove 4 screws from rear bumper lamps,
release lamps and disconnect multiplugs.
91.Release harness clips and pull harness into
luggage compartment.
92.Release main harness retaining clips and pull
harness into vehicle interior.
93.Remove main harness.Refit
1.Lay main harness in vehicle.
2.Locate rear section and secure in retaining
clips.
3.Feed harness to rear bumper lamps, secure in
clips and grommets.
4.Connect multiplugs to rear bumper lamps, fit
rear lamps and secure with screws.
5.Fit LH rear earth header and secure with nut.
6.Connect multiplugs to LH tail lamp.
7.Position RH tail lamp and connect multiplugs.
8.Fit RH tail lamp and secure with Torx screws.
9.Fit RH rear earth header and secure with nut.
10.Connect multiplug to towing electrics.
11.Connect rear screen washer tube.
12.Connect tail door harness multiplugs.
13.Connect and fit rear window lift and wash/wipe
relays.
14.Position harness into luggage compartment.
15.Connect both rear ABS speed sensor
multiplugs and secure harness grommets.
16.Connect multiplug to fuel pump.
17.Fit fuel pump access cover and secure with
screws.
18.Fit luggage compartment carpet.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Carpet - luggage compartment.
19.Connect multiplugs at the base of 'B/C' Posts.
20.Fit all harness clips to interior of vehicle.
21.Fit multiplugs and earth header to LH lower 'A'
post.
22.Fit earth header to RH lower 'A' post.
23.Connect multiplug to window lift ECU.
24.Fit face level vent ducting.
25.Fit steering column to bracket and secure with
nuts.
26.Fit rear heater ducting and secure with nut.
27.Secure harness to rear heater ducting with
clips.
28.Position mounting bracket and secure relays.
29.Connect Lucar to handbrake switch.
30. Manual gearbox only: Connect multiplug to
gear lever hill descent switch.
31.Connect multiplug to accelerometer.
32. Automatic gearbox only: Connect multiplugs
to gear selector.
33.Connect heated oxygen sensor multiplug.
34.Fit earth header to floor tunnel and secure with
nut.
35.Fit earth lead to airbag ECU and secure with
bolt.
36.Connect multiplug to airbag ECU.
37.Connect multiplugs to brake light switch and
brake pedal position switch.
38.Connect multiplug to throttle position sensor.
39.Fit harness clip to steering column.
40.Connect multiplug to steering column switch.

HARNESSES
REPAIRS 86-7-11
41.Position fuse box to body and connect
multiplugs.
42.Fit relays to fuse box bracket.
43.Connect coaxial cable.
44.Fit and connect multiplug to RH 'A' post.
45.Fit passenger compartment fuse box and
secure with bolts.
46.Position side repeater lamps, connect
multiplugs and fit to wings.
47.Secure rear edge of front wheel arch liners.
48.Fit front mud flaps and secure with screws.
49.With assistance feed harness through bulk
head into engine bay.
50.Position harness to wiper motor and connect
multiplug.
51.Fit air intake plenum.

+ HEATING AND VENTILATION,
REPAIRS, Plenum - air intake.
52.Secure harness to LH side of engine bay and
secure fixings.
53.Connect multiplug to inertia switch.
54.Connect multiplugs to underside of fuse box.
55.Fit nuts securing fuse box to brackets.
56.Fit battery connections and multiplug to fuse
box.
57.Fit fuse box cover.
58.Connect 'E' box cooling fan multiplug.
59.Connect 'E' box temperature sensor multiplug.
60.Connect engine harness multiplugs to main
harness.
61. Automatic gearbox only:Connect multiplug to
gearbox ECU.
62.Fit 'E' box cover and secure with Allen screws.
63.Connect engine harness multiplugs to main
harness.
64.Fit harness retaining clips.
65. Models with cruise control: Connect
multiplug to vacuum pump.
66.Connect Lucar connector to starter motor.
67.Connect multiplug to LH ABS speed sensor.
68.Fit LH earth header and secure with nut.
69.Connect multiplug to harness.
70.Connect multiplugs to LH headlamp and
headlamp levelling motor.
71.Secure harness to cooling fan clips.
72.Connect multiplugs to cooling fan pack and
cooling fans.
73.Position bonnet release cable to harness and
secure with cable ties.
74.Fit battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
75.With assistance feed harness through bulk
head into engine bay.
76.Fit earth header to bulk head and secure with
nut.
77.Fit front screen washer tube to harness.
78.Fit harness retaining clips.79.Fit PAS and coolant reservoir support bracket
and secure with bolt and nuts.
80.Connect multiplug to bonnet switch.
81.Connect multiplug to brake fluid low level
indicator switch.
82.Fit jack to holder in engine bay.
83.Connect multiplugs to horn, refrigerant
pressure sensor and compressor.
84.Connect multiplugs to RH headlamp and
headlamp levelling motor.
85.Connect multiplug to RH ABS speed sensor
and secure to clips.
86.Connect multiplug to ABS modulator.
87.Fit earth header to RH inner wing and secure
with nut.
88.Position harness to windscreen washer
reservoir.
89.Fit windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
90.Fit engine acoustic cover.

+ ENGINE - Td4, REPAIRS, Cover -
engine acoustic - Up to 02.5 Model Year.
91.Fit carpet.

HARNESSES
86-7-12 REPAIRS
Harness - tailgate
$% 86.70.19
Remove
1.Remove RH rear quarter lower trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
2.Remove tail door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
tail door.
3.Remove 3 nuts and remove spare wheel.
4.Remove 3 screws securing CHMSL,
disconnect multiplug and remove CHMSL.
5.Release 2 harness clips.6.Disconnect rear washer tube from behind the
spare wheel carrier.
7.Remove 3 nuts from number plate lamp
housing and release housing.
8.Disconnect 2 Lucars and multiplug from
housing.
9.Collect 2 spacers and housing seal.
10.Remove housing.

HARNESSES
REPAIRS 86-7-13
11.Disconnect 2 Lucars from rear screen element.
12.Remove 4 screws from door latch, release door
latch to access multiplugs and harness clips.
13.Disconnect 2 multiplugs from door lock.14.Disconnect multiplug from rear wiper motor.
15.Disconnect multiplug from rear window motor.
16.Release and disconnect 3 multiplugs and
washer tube from main harness at 'E' post.

HARNESSES
86-7-14 REPAIRS
17.Release tail door harness from 13 retaining
clips.
18.Release harness sheath from tail door and 'E'
post.
19.Remove harness from vehicle.Refit
1.Position harness to vehicle and secure in
retaining clips.
2.Secure harness sheath to tail door and 'E' post.
3.Connect multiplugs and washer tube to main
harness, secure multiplugs to body.
4.Connect multiplugs to window motor, wiper
motor and door lock.
5.Position door latch, fit and tighten screws.
6.Connect Lucars to heated rear screen.
7.Position number plate lamp housing, locate
seal and fit spacers.
8.Connect multiplug and Lucars to housing.
9.Fit housing and secure with nuts.
10.Connect washer tube behind spare wheel
carrier.
11.Secure harness clips to spare wheel carrier,
connect multiplug to CHMSL, fit CHMSL and
secure with screws.
12.Fit spare wheel and secure with nuts.
13.Fit tail door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
tail door.
14.Fit rear lower trim casing .

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.

HARNESSES
REPAIRS 86-7-15
Harness - interior lights - 5 door
$% 86.70.44
Remove
1.Remove fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
2.Remove headlining.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Headlining - 5 door.
3.Disconnect aerial connection and interior light
harness from main harness.
4.Disconnect multiplug from volumetric sensor.
5.Release 10 harness clips.
6.Remove harness.
Refit
1.Position harness and secure harness clips.
2.Connect multiplug to volumetric sensor.
3.Connect multiplug and aerial connection to
main harness.
4.Fit headlining.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Headlining - 5 door.
5.Fit fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
Harness - front door - 5 door
$% 86.70.65
Remove
1.Remove front door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
front door - 5 door.
2.Disconnect multiplugs from door lock, door
mirror and window motor.
3.Release 8 clips securing door harness to door.
4.Release 2 multiplugs from location at base of
'A' post and disconnect multiplugs.
5.Release sheath from front edge of door, and
pull harness from door.
6.Release sheath from 'A' post and pull harness
from 'A' post.
7.Remove door harness.
Refit
1.Position harness to 'A' post and feed harness
partly into 'A' post.
2.Feed sheath onto harness and locate sheath to
'A' post.
3.Feed harness through front edge of door and
secure sheath to door.
4.Connect and secure multiplugs at base of 'A'
post.
5.Position harness to door and secure with clips.
6.Connect multiplugs to door mirror, door lock
and window motor.
7.Fit front door plastic sheet.

+ DOORS, REPAIRS, Plastic sheet -
front door - 5 door.
