Lexus IS300h 2013 Owner's Manual

4677-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
CAUTION
Proper inflation is critical to save tire performance
Keep your tires properly inflated. Otherwise, the following conditions may
occur and result in an accident causing death or serious injury:
Excessive wear
Uneven wear
Poor handling
Possibility of blowouts resulting from overheated tires
Poor sealing of the tire bead
Wheel deformation and/or tire separation
A greater possibility of tire damage from road hazards
NOTICE
When inspecting and adjusting tire inflation pressure
Be sure to put the tire valve caps back on.
Without the valve caps, dirt or moisture could get into the valve and cause air
leakage, which could result in an accident. If the caps are lost, replace them as
soon as possible.

4687-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
When replacing wheels, care should be taken to ensure that they are
equivalent to those removed in load capacity, diameter, rim width and
inset
*.
Replacement wheels are available at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
*: Conventionally referred to as “off-
set”.
Lexus does not recommend using the following:
Wheels of different sizes or types
Used wheels
Bent wheels that have been straightened
Use only Lexus wheel nuts and wrenches designed for use with your
aluminum wheels.
When rotating, repairing or changing your tires, check that the wheel
nuts are still tight after driving 1600 km (1000 miles).
Be careful not to damage the aluminum wheels when using tire chains.
Use only Lexus genuine balance weights or equivalent and a plastic or
rubber hammer when balancing your wheels.
When replacing wheels
The wheels of your vehicle are equipped with tire pressure warning valves and
transmitters that allow the tire pressure warning system to provide advance warn-
ing in the event of a loss in tire inflation pressure. Whenever wheels are replaced,
tire pressure warning valves and transmitters must be installed. (P. 451)
Wheels
If a wheel is bent, cracked or heavily corroded, it should be replaced.
Otherwise, the tire may separate from the wheel or cause a loss of han-
dling control.
Wheel selection
Aluminum wheel precautions

4697-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
CAUTION
When replacing wheels
Do not use wheels that are a different size from those recommended in the
Owner’s Manual, as this may result in a loss of handling control.
Never use an inner tube in a leaking wheel which is designed for a tubeless
tire. Doing so may result in an accident, causing death or serious injury.
NOTICE
Replacing tire pressure warning valves and transmitters
Because tire repair or replacement may affect the tire pressure warning valves
and transmitters, make sure to have tires serviced by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional or
other qualified service shop. In addition, make sure to purchase your tire pres-
sure warning valves and transmitters at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Ensure that only genuine Lexus wheels are used on your vehicle.
Tire pressure warning valves and transmitters may not work properly with
non-genuine wheels.

4707-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
Turn the power switch off.
Open the glove box. Lift up the
side with the stay, disconnect the
stay tabs and remove the partition
by pulling horizontally.
Press the tabs and remove the fil-
ter cover.
Press the tabs and remove the fil-
ter case.
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air con-
ditioning efficiency.
Removal method
1
2
3
4

4717-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
Remove the air conditioning fil-
ter from the filter case and
replace it with a new one.
The “UP” marks shown on the fil-
ter and the filter case should be
pointing up.
Checking interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement may
be required. (For scheduled maintenance information, please refer to the “Lexus
Service Booklet” or “Lexus Warranty Booklet”.)
If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
5
NOTICE
When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the sys-
tem.

4727-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
Flathead screwdriver
Small flathead screwdriver
Lithium battery CR2032
Take out the mechanical key.
Remove the cover.
To prevent damage to the key, wrap
the tip of the screwdriver with tape.
Remove the battery cover.
To prevent damage to the key, wrap
the tip of the screwdriver with tape.
Electronic key battery
Replace the battery with a new one if it is depleted.
You will need the following items:
Replacing the battery
1
2
3

4737-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
Remove the depleted battery.
Insert a new battery with the “+” ter-
minal facing up.
Use a CR2032 lithium battery
Batteries can be purchased at any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional, local electrical appliance
shops or camera stores.
Replace only with the same or equivalent type recommended by the manufac-
turer.
Dispose of used batteries according to local laws.
When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer
can replace the battery for you.
If the electronic key battery is depleted
The following symptoms may occur:
The smart entry & start system and wireless remote control will not function
properly.
The operational range will be reduced.
Certification for the key battery
Replace only with the same or equivalent type recommended by the manufac-
turer.
Dispose of used batteries according to local laws.
4

4747-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
CAUTION
Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking.
Keep away from children. Failure to do so could result in death or serious
injury.
Lithium battery precautions
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
NOTICE
For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
Always work with dry hands.
Moisture may cause the battery to rust.
Do not touch or move any other component inside the remote control.
Do not bend either of the battery terminals.

4757-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
Turn the power switch off.
Open the fuse box cover.
Engine compartment:
Remove the clips.
Push the tabs on either side to
detach the lock and lift the lid off
while pulling the lock plate.
When installing the lid, check that
the lock plate and the tabs on
either side are connected cor-
rectly.
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
1
2

4767-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
Left side instrument panel (left-hand drive vehicles)
Remove the lid.
Left side instrument panel (right-hand drive vehicles)
Remove the lid.
Remove the fuse with the pullout
tool.
Only type A fuses can be removed
using the pullout tool.
3
