lexus LC500 2018 Owner's Manual

131
3
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk
Before driving

132
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk

133
3
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk
Before driving

134
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk

135
3
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk
Before driving

136
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk

137
3
-$@-$I@0.@0.&@ &&

3-2. Opening, closing and locking the doors and trunk
Before driving
WARNING
■Caution regarding interference with electronic devices
●People with implantable cardiac pace-makers, cardiac resynchronization therapy-pacemakers or implantable
cardioverter defibrillators should maintain a reasonable distance between themselves and the smart
entry & start system antennas. ( P.122) The radio waves may affect the opera-
tion of such devices. If necessary, the entry function can be disabled. Ask any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer for details, such as the fre-quency of radio waves and timing of
the emitted radio waves. Then, consult your doctor to see if you should dis-able the entry function.
●Users of any electrical medical device
other than implantable cardiac pace- makers, cardiac resynchronization therapy-pacemakers or implantable
cardioverter defibrillators should con- sult the manufacturer of the device for information about its operation under
the influence of radio waves. Radio waves could have unexpected effects on the operation of such medi-
cal devices.
Ask any authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer for details on disabling the entry
function.

138
-$@-$I@0.@0.&@ &&

3-3. Adjusting the seats
3-3.Adjusting the seats
Seat position adjustment
Seatback angle adjustment
Head restraint height adjustment (if
equipped) ( P.143)
Seat cushion (front) angle adjust-
ment
Vertical height adjustment
Lumbar support adjustment
■When adjusting the seat
●Make sure that any surrounding passen- gers or objects are not contact the seat.
●Take care when adjusting the seat so that the head restraint does not touch the ceil-ing.
■Seat-linked function
●This function operates when the seat is
moved forward, backward or in the reclining direction a certain distance or more.
●Vehicles with power head restraint: When the seat is adjusted forward a cer-
tain distance or more, the head restraint moves down.
●Vehicles with power head restraint: When the seat is raised a certain distance or more, the seat stops and the head
restraint moves down.
Front seats
The seats can be adjusted (longitu-
dinally, vertically, etc.).
Adjust the seat to ensure the cor-
rect driving posture.
Adjustment procedure
A
B
C
D
E
F
WARNING
■When adjusting the seat position
●Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
●Do not put your hands under the seat or near the moving parts to avoid
injury. Fingers or hands may become jammed in the seat mechanism.
●Make sure to leave enough space
around the feet so they do not get stuck.
■Seat adjustment
To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your
neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Adjustments should not be made while driving as the seat may unexpectedly move and cause the driver to lose control
of the vehicle.

139
3
-$@-$I@0.@0.&@ &&

3-3. Adjusting the seats
Before driving
■Before entering/exiting the rear
seats
 Remove the seat belt from the seat
belt guide. ( P.32)
 Stow the sun visor.
■Entering/exiting the rear seat
1 Pull the lever.
The front seat will lower automatically.
2Fold the seatback completely for-
ward.
The front seat will move forward and the
head restraint will move downward* auto- matically.
*: Power type only
■Returning the front seat to its origi-
nal position
Move the seatback backward until it
locks. The front seat will return to its
original position automatically.
■Lever-operated “Front, Fold & Return” seat
●After the front seat is moved forward by operating the “Front, Fold & Return” seat
lever, if a power seat adjusting switch or a driving position memory switch is pressed, the front seat will not return to its
original position even if the front seatback is moved backward until it locks.
●The lever-operated “Front, Fold & Return” seat will not operate in the follow-
ing situations: • The seat belt of the seat to be operated is fastened.
• The engine switch is in IGNITION ON mode and the shift position is in a position other than
P.
●Operation of the lever-operated “Front,
Fold & Return” seat will stop in the follow- ing situations:• A power seat adjusting switch or a driv-
ing position memory switch is pressed. • The seat belt of the seat which is operat-ing is fastened.
• The engine switch is in IGNITION ON mode and the shift position is changed to a position
other than P.
■Jam protection function
While the driving positi on is recalling or the
lever-operated “Front, Fold & Return” seat is operating, if an object is stuck either in front of or behind the front seat, the front
seat will stop and then move in the opposite direction slightly.
When the jam protection function operates, the seat stops at a po sition other than the set seat position. Check the seat position.
Entering/exiting the rear seats
(lever-operated “Front, Fold &
Return” seat)

140
-$@-$I@0.@0.&@ &&

3-3. Adjusting the seats
1Turn the engine switch switch> to IGNITION ON mode
.
2 Check that the shift position is in P.
3 Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display to the desired
positions.
4 While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.
If the selected button has already been preset, the previously recorded position
WARNING
■Lever-operated “Front, Fold & Return” seat
●Before operating the lever-operated “Front, Fold & Return” seat, ensure that any surrounding passengers or objects
will not contact the seat.
●Make sure the seatback is locked securely before driving.
●Never operate the lever-operated “Front, Fold & Return” seat while the
vehicle is moving.
■Jam protection function
Do not use a hand, foot, or any other part
of your body to intentionally activate the jam protection function.
Driving position memory
This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to suit your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key can be regis-
tered to recall your preferred driv-
ing position.
Recording a driving position into
memory
