Page 531 of 1500
FRONT SEAT ASSEMBLY
INTERIOR52A-42
REMOVAL SERVICE POINT
.
<> HEADREST REMOVAL
1. Raise the head restraint fully.
2. Insert a probe that is suited to fit into the hole (1) in the right
hand head restraint sleeve (2) as illustrated in the figure
below.
3. Whilst the probe is inserted slightly, apply slight pressure on
the head restraint. Apply and hold pressure upwards.
4. To remove the head restraint, you must depress the sleeve
height adjuster lock (3) on the left-hand head restraint
sleeve as illustrated below.
<> HEADREST SLEEVE REMOVAL
1. To reveal upper portion of the seat back frame or
active head restraint frame (1) as shown in figure
below, push down on the surrounding seat cover.
2. By using a small flat blade screwdriver, depress
the sleeve locking tab (2), and remove the head
restaint sleeve (3) in upwards movement from the
frame as illustrated below.
3. If required, repeat process for the remaining
sleeve.
<> SEAT BACK PANEL REMOVAL
AND FITMENT
1. Move front seat to the most forward position.
2. Pull the lower edge of seat panel towards you, as
shown below (1).
3. Slide the panel downwards (2) as the top section
is held in by 2 locating hooks (lugs).
4. Upon fitment, be sure to firstly locate the top 2
lugs into position (2), as shown above.
5. Approximately square up panel to the seat, so by
doing this you will be able to locate the bottom 2
clips to press in the panel (1), as shown above.
Page 532 of 1500
FRONT SEAT TRIM COVER
INTERIOR52A-43
FRONT SEAT TRIM COVER
REMOVAL AND FITMENT
REMOVAL
.
1. Remove seat from vehicle and cushion or seat back
assembly as required. Remove all seat plastic covers etc.
2. Unclip all the plastic retainer clips at the rear of the trim
cover. This is typical for the cushion and the back of the
seat.
3. Peel cover away from the foam pad.
NOTE: Place a finger on the Blue Velcro strip when peeling
the cover to prevent the strip being pulled out of the foam
pad.
Page 533 of 1500
FRONT SEAT TRIM COVER
INTERIOR52A-44
FITMENT
.
1. Locate the new trim onto the pad by aligning the Velcro strip
with the grooves. Use an intersection in order to align both
directions. Whenever possible work from the centre of the
trim toward the outside.
2. Push the Velcro strips into place along all the grooves.
Page 534 of 1500
FRONT SEAT TRIM COVER
INTERIOR52A-45
3. Pull the cover over the outside of the pad and reattach the
retaining clips where required.
NOTE: It may be necessary to make some adjustment and
work the cover into position to remove creases. Reassemble
seat and fit to vehicle.
Page 535 of 1500
REAR SEAT CUSHION TRIM COVER
INTERIOR52A-46
REAR SEAT CUSHION TRIM COVER
REMOVAL AND FITMENT
REAR SEAT CUSHION TRIM REMOVAL
.
1. Remove rear seat cushion from vehicle.
2. Release the trim cover draw string.
3. Release all outer cover attachment points.
4. Peel cover away from the foam pad.
NOTE: Place a finger on the Blue Velcro strip when peeling
the cover to prevent the strip being pulled out of the foam
pad.
Page 536 of 1500
REAR SEAT CUSHION TRIM COVER
INTERIOR52A-47
REAR SEAT CUSHION TRIM FITMENT
.
1. Locate the new trim onto the pad by aligning the Velcro strip
with the grooves. Use an intersection in order toalign both
directions. Whenever possible work from the centre of the
trim toward the outside.
2. Pull the cover around the sides of the pad.
3. Pull trim through the seat belt slots as shown and attach to
wires
Page 537 of 1500
REAR SEAT CUSHION TRIM COVER
INTERIOR52A-48
4. Pull draw string and attach to the centre wire as shown.
5. Reattach all outer points.
6. Work the trim into all the grooves and adjust if necessary to
remove creases as shown.
Page 538 of 1500
REAR SEAT BACK TRIM COVER
INTERIOR52A-49
REAR SEAT BACK TRIM COVER
REMOVAL AND FITMENT
REAR SEAT BACK TRIM REMOVAL
.
1. Remove rear seat back from the vehicle, and remove arm
rest and arm rest pivot bushes from rear seat back.
2. Release the draw string.
3. Release all outer attachment points. Release all the centre
clips.
Page 539 of 1500
REAR SEAT BACK TRIM COVER
INTERIOR52A-50
4. Peel cover away from the foam pad.
NOTE: Place a finger on the Blue Velcro strip when peeling
the cover to prevent the strip being pulled out of the foam
pad.
Page 540 of 1500
REAR SEAT BACK TRIM COVER
INTERIOR52A-51
REAR SEAT BACK TRIM FITMENT
.
1. Fit the trim over the lower wire brackets.
2. Locate the new trim onto the pad by aligning the Velcro strip
with the grooves. Use an intersection in order to align both
directions. Whenever possible work from the centre of the
trim toward the outside.
3. When all the grooves are aligned pull the cover over the
pad.
