Interior MITSUBISHI 380 2005 Manual Online

REAR SEAT BACK TRIM COVER
INTERIOR52A-52
4. Reattach the upper trim holding points including the plastic
clips.
5. Attach the centre lower trim hold points.
6. Attach the clips around the arm rest as shown.

REAR SEAT BACK TRIM COVER
INTERIOR52A-53
7. Pull inner lower arm rest trim through the hole and clip to
retainer attached to the lower part of the trim cover.
8. Pull the upper arm rest trim through the hole over the large
wire and clip to the small wire as shown.
9. Pull the draw string and attach to the wire attachment points
shown.

REAR SEAT BACK TRIM COVER
INTERIOR52A-54
10.Attach all the outer trim attachment points.
11.Work in all the seams, and adjust as required to remove any
creases.
12.Fit seat back to vehicle in reverse order of removal.

REAR SEAT ASSEMBLY
INTERIOR52A-55
REAR SEAT ASSEMBLY
REMOVAL AND INSTALLATIONM1522001800297
INSTALLATION SERVICE POINTS
.
>>A<< INSTALLATION OF REAR SEATBACK
ASSEMBLY
Press the rear seatback assembly in the direction shown in the
illustration and fit the attachment wire into the hook securely to
install the rear seatback assembly.Confirm that back is hooked
and secured by pulling forward.
.
REMOVAL STEPS
>>B<<1. REAR SEAT CUSHION
ASSEMBLY>>A<<2. REAR SEATBACK ASSEMBLY
3. REAR SEAT HOOKREMOVAL STEPS (Continued)

REAR SEAT ASSEMBLY
INTERIOR52A-56
>>B<< INSTALLATION OF REAR SEAT CUSHION
ASSEMBLY
1. Fit the rear seat cushion into the bracket securely.
2. Fit the rear seat cushion into the rear seat hook securely.

REAR SEAT ASSEMBLY
INTERIOR52A-57
DISASSEMBLY AND REASSEMBLYM1522002000357
DISASSEMBLY STEPS
2. SEAT CUSHION COVER
3. SEAT CUSHION PAD
4. ARMREST
5. BUSH6. ARMREST PAD
8. SEATBACK COVER
9. SEATBACK PADDISASSEMBLY STEPS

FRONT SEAT BELT
INTERIOR52A-58
FRONT SEAT BELT
REMOVAL AND INSTALLATIONM1523001300370
SRS: Before removing and installing the seat belts with pre-tensioner, refer to GROUP 52B, Seat
Belt with Pre-tensioner P.52B-250.
NOTE:
*If so equipped
Pre-removal and Post-installation Operation
Turn the ignition key to the LOCK (OFF) position.
Disconnect the negative battery terminal.Post-installation Operation
Adjustment Procedures of Special Function (refer to GROUP
52B, On-Vehicle Service P.52B-250.)
1. EXTENDER SEAT BELT
ASSEMBLY*
OUTER SEAT BELT REMOVAL
STEPS
2. SASH GUIDE COVER
CENTER PILLAR TRIM LOWER
(REFER TO P.52A-11.)
3. OUTER SEAT BELT (REFER TO
GROUP 52B, SEAT BELTS WITH
PRE-TENSIONER P.52B-250.)4. CENTER PILLAR TRIM UPPER
(REFER TO P.52A-11.)
5. ADJUSTABLE SEAT BELT ANCOR
INNER SEAT BELT
6. SEAT BELT SWITCH
CONNECTOR
SHIELD COVER (REFER TO
P.52A-33.)
7. INNER SEAT BELTOUTER SEAT BELT REMOVAL
STEPS (Continued)

REAR SEAT BELT
INTERIOR52A-59
INSPECTIONM1523004400116.
SEAT BELT SWITCH CONTINUITY CHECK
REAR SEAT BELT
REMOVAL AND INSTALLATIONM1523001600371
ITEM TESTER
CONNECTIONSPECIFIED
CONDITION
Fastened seat belt 1
2 Open circuit
Unfastened seat belt 1
2 Less than 2 ohms
REMOVAL STEPS
REAR SEAT CUSHION
ASSEMBLY (REFER TO
P.52A-55.)
1. INNER SEAT BELT
2. CENTER SEAT BELT INNERREAR SHELF TRIM (REFER TO
P.52A-11.)
3. OUTER SEAT BELT
4. CENTER SEAT BELT OUTERREMOVAL STEPS (Continued)

SPECIFICATIONS
INTERIOR52A-60
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONSM1521004100227
ITEM SPECIFICATION
FRONT SEAT
Front seatback assembly bolt 44
10 Nm (33 7 ft-lb)
Front seat cushion assembly bolt 12
2 Nm (102 22 in-lb)
Front seat bolt 44
10 Nm (33 7 ft-lb)
Front seat nut 30
5 Nm (22 4 ft-lb)
REAR SEAT
Seatback assembly bolt 22
4 Nm (16 3 ft-lb)
FRONT SEAT BELT
Adjustable seat belt anchor bolt 44
10 Nm (33 7 ft-lb)
Inner seat belt bolt 44
10 Nm (33 7 ft-lb)
Outer seat belt bolt 44
10 Nm (33 7 ft-lb)
REAR SEAT BELT
Center seat belt outer and inner seat belt bolt 44
10 Nm (33 7 ft-lb)
Inner seat belt bolt 44
10 Nm (33 7 ft-lb)
Seat belt shoulder anchor bolt 44
10 Nm (33 7 ft-lb)
Seat belt lower anchor bolt 44
10 Nm (33 7 ft-lb)
