CONSTRUCTION DESCRIPTION
ANTI-SKID BRAKE SYSTEM (ABS)35B-11
SERVICE DATA OUTPUT
The following items of the ECU input data can be
read using M.U.T.-III.
Item No.Check itemCheck conditionNormal condition
01FR wheel speed sensorPerform a test run of the vehicle.Speedometer display and
M.U.T.-III display almost agree
with each other.
02FL wheel speed sensor
03RR wheel speed sensor
04RL wheel speed sensor
05Power supply voltageAlways10 V or more
06Stop lamp switchThe brake pedal is depressedON
The brake pedal is released.OFF
07Va l v e r e l a yWhen ABS is operatingON
When ABS is not operatingOFF
10FL inlet valve When ABS is operatingON
When ABS is not operatingOFF
11FL outlet valve When ABS is operatingON
When ABS is not operatingOFF
12FR inlet valve When ABS is operatingON
When ABS is not operatingOFF
13FR outlet valve When ABS is operatingON
When ABS is not operatingOFF
14RL inlet valve When ABS is operatingON
When ABS is not operatingOFF
15RL outlet valve When ABS is operatingON
When ABS is not operatingOFF
16RR inlet valve When ABS is operatingON
When ABS is not operatingOFF
17RR outlet valve When ABS is operatingON
When ABS is not operatingOFF
20Pump motorWhen ABS is operatingON
When ABS is not operatingOFF

CONSTRUCTION DESCRIPTION
ANTI-SKID BRAKE SYSTEM (ABS)35B-12
ACTUATOR TEST
AC300188AD
Activation PatternAB
C Start of
activation
1 s 2 s
On
Off
Note
A:
B:
C: Hydraulic pressure increases
Hydraulic pressure holds
Hydraulic pressure decreases End of
activation
Solenoid
valve
Pump
motor
The M.U.T . -III can be u s ed to force-drive a ll sole noid
valves and th
e pump mo tor .
NOTE: .
•Whe n ABS-ECU is disabled, the actu ator te st
cannot b
e perfo rmed.
•The actu ator test can be p e rformed on ly whe n
the
veh i cle is st a t iona ry . Whe n the ve hicle speed
rea
c h e s 10km/h, the f o rcible a c t uator operation is
disabled.
•During actuator test, the ABS warning lamp illu-
minates , an d ABS contro l is proh ibit ed.
Item No.Check itemDrive Contents
01Solenoid valve for
front-right wheelSolenoid valves
and pump motor in
the hydraulic unit
(simple inspection
mode)
02Solenoid valve for
front-left wheel
03Solenoid valve for
rear-right wheel
04Solenoid valve for
rear-left wheel

GROUP 51
EXTERIOR
CONTENTS
GENERAL INFORMATION . . . . . . . .51-2
RADIATOR GRILLE. . . . . . . . . . . . . .51-3
BUMPER . . . . . . . . . . . . . . . . . . . . . .51-4
OVERFENDER
. . . . . . . . . .51-6
AERO PARTS . . . . . . . . . . . . . . . . . .51-7
GARNISH
. . . . . . . . . .51-8
WIPER AND WASHER . . . . . . . . . . . .51-9
WINDSHIELD WIPER AND WASHER . . . . 51-9
REAR WIPER AND WASHER . . . . . . . . . . 51-11
DOOR MIRROR . . . . . . . . . . . . . . . . .51-12

GENERAL INFORMATION
EXTERIOR51-2
GENERAL INFORMATION
M2510000101603
FEATURES
BETTER APPEARANCE
1. Two kinds of radiator grille have been provided.
2. Exclusive radiator grille and front bumper ART Version-R>
3. Exclusive rear bumper
4. Side air dam
5. Tailgate spoiler
6. Rear wiper with resin arm
BETTER AERODYNAMIC CHARACTERISTICS
7. Front and rear overfenders

8. Side air dam
9. Tailgate spoiler
10. Low air-resistance door mirrors
11. Front under cover
Improvement of cooling efficiency
12. Air guide panels have been installed behind the
front bumper for efficient cooling of the radiator.
BETTER USER-FRIENDLINESS
13. Electric retractable remote controlled door mirror
BETTER PRODUCT PACKAGE
14. Vehicle speed sensitive intermittent time variable
windshield wipers
15. Initial continuous operation and reverse inter-
locked operating rear intermittent wiper
16. Tailgate lower garnish< RALLIART Version-R>
SUPPORT RECYCLING OF RESOURCES
Aggressively uses PP (polypropylene) materials that
are easy to recycle and easy to stamp material sym
-
bols on the plastic (resin) parts.
AC601394

6, 15
10, 13
4, 8
12 14
11
6, 15
16
10, 137
14
5, 9
4, 8
AB
5, 9
3
11
7
2
1

RADIATOR GRILLE
EXTERIOR51-3
RADIATOR GRILLE
M2510001000468
CONSTRUCTION DIAGRAM
AC510290AB

Section A – A
Radiator grille
(1) Chromium plating
(1) (1)
A
A
AA
•T
w o kinds of ra diato r grille ha s be en provide d .
•
AC601298AC
Radiator grille

Chromium plat ing is u s ed t o the a r eas shown in
the
figure to emphasize the luxu rious feel and
sp
ortin e ss .
The radi ator g r ille has been renewed in de sig n to
provide the
robuster fron t face.

BUMPER
EXTERIOR51-4
BUMPER
M2510002000751
FRONT BUMPER CONSTRUCTION DIAGRAM
AC402884AD
Air guide panel (RH)
Air guide panel (LH)
Air guide panel
•The front b u mpe r has overh ung at the right an d
le
f t corners to suppre s s the airflow to the tyres
and
smo o then t he airf low from the bumper to th e
ve
hicle sides.•
AC601475

Front bumper assembly
AB

Overfender construction
The air g u ide p a n e ls have been inst a lled behind
th
e fr on t b u mp er to impro v e t h e co olin g ef ficie n cy
of t
he radiator .
•The front b u mpe r emp hasizes the light ima ge in
fron
t appea rance.•Overfender const r uction from the f r ont bu mper t o
the
wh eel a r ch o f fende r appea ls the sporty and
robu
st whee lin g.< RALLIAR T V e rsion - R>

BUMPER
EXTERIOR51-5
REAR BUMPER CONSTRUCTION DIAGRAM
AC601397
Rear bumper assembly
AB
Overfender
construction

•Rear b
u mpe r emp hasizes the ligh t image in rear
app
earance.•Overfe nder construction from the wh eel a r ch o f
side p
ane l to t he rear bump e r appe als the sporty
and
robust wheeling. < RAL L IAR T V e rsion-R>

OVERFENDER
EXTERIOR51-6
OVERFENDER
M2510000700141
AC600344ABFront overfenderRear overfender
Rear door overfender
T
he o v erf ende r of f e rin g th e ho pes o f all rou nd driving
has b
een ad ded to appea l a sporty and robust
whe
e ling with a sen s e o f con t inuity with front
bump
e r , side air dam and rear bumper .

AERO PARTS
EXTERIOR51-7
AERO PARTS
M2510003000583
CONSTRUCTION DIAGRAM
AC601394
Side air damTailgate spoiler
Side air dam
Tailgate spoiler

Front overfenderRear overfenderA
C
•Side air d a m, t a ilgate spo iler , front/re a r overfend-
ers impro v e a e rody-
namic char acte ristics and a ppeara n ce.

GARNISH
EXTERIOR51-8
GARNISH
M2510008300329
TAILGATE GARNISH
AC601467AB
Tailgate garnish
Ta ilgate garnish ha s be en in st alled on the bod y to
imp
r ove t he app earance and market ability .
