MITSUBISHI COLT 2006 Service Repair Manual

GROUP 52A
INTERIOR
CONTENTS
GENERAL INFORMATION . . . . . . . .52A-2
INSTRUMENT PANEL . . . . . . . . . . . .52A-3
SEAT . . . . . . . . . . . . . . . . . . . . . . . . .52A-5
FRONT SEAT . . . . . . . . . . . . . . . . . . . . . . . 52A-5
REAR SEAT . . . . . . . . . . . . . . . . . . . . . . . . 52A-8
MULTI SEAT ARRANGE . . . . . . . . . . . . . . 52A-9
SEAT BELT . . . . . . . . . . . . . . . . . . . .52A-10
TRIMS . . . . . . . . . . . . . . . . . . . . . . . . .52A-12
INTERIOR TRIM . . . . . . . . . . . . . . . . . . . . . 52A-12
DOOR TRIM . . . . . . . . . . . . . . . . . . . . . . . . 52A-13
HEADLINING . . . . . . . . . . . . . . . . . . .52A-14
LUGGAGE ROOM . . . . . . . . . . . . . . .52A-15
FLOOR CARPET . . . . . . . . . . . . . . . .52A-16

GENERAL INFORMATION
INTERIOR52A-2
GENERAL INFORMATION
M2520000100850
Functionality, interior comfort, and safety have been
emphasised, providing the interior design with ele
-
gance and comfortable space. Various measures
have been taken actively to protect the environment
and recycle resources.
FEATURES
Quality improvement
•Full interior trim
•Two-tone interior
•Cloth covered part door trim
Usability improvement
•Movable ashtray
•Front RECARO seat (Option)
•Cup holder of right/left separation type (for front
seats)
•Convenience hook (passenger’s side)
•Wide variety of seat arrangement
•Reclining adjustment, slide adjustment
•Luggage hook
Convenient boxes
•Centre panel box
•Glove box
•Seatback pocket
•Bottle holder (front door trim)
•Door pocket (front door trim)
Safety improvement
•ELR three-point seat belt (front)
•Front seat belt with force limiter mechanism
•ELR three-point seat belt/child seat fastening
mechanism (ALR) switching seat belt (rear)
•Floor carpet with heel stopper structure
•Instrument panel and trims which adopt
fire-retarding materials
Consideration for the optimum driving position
•Seat height adjustment (driver’s seat)
•Head restraint with height adjustment (front, rear)
•One-touch adjustable seat belt anchor (front seat
belt)
Measures for resource recycling
Aggressively use PP materials that are easy to recy-
cle and easy to stamp material symbols on the plas-
tic (resin) parts.

INSTRUMENT PANEL
INTERIOR52A-3
INSTRUMENT PANEL
M2520001100198
AC400582
Glove boxCentre panel box
Cup holderUnder tray
Cup holder
System up tray
Ashtray
Cup holder
AB
The in strument p a n e l ha s the following f eatures:
•The instrume nt p anel is two - toned .
•Higher instrument p ane l height ha s improved fo r-
ward (downward) visibili ty . The instrume nt p anel
has bee
n angled acutely , giving of f a n open -plan
fee
l .
•Sep a rate -type cup h o lde r s (for 500-mL pla s tic
bot
tle) ha ve b een pro v id ed to f a cilit ate u s e o f
ashtray and cup ho
lders.
•The instrume nt p anel and th e front p a sse nger's
airbag flap ha
ve be en in tegrate d for impro v ed
app
earance and quality . Fu rther , re duce d noise
and
we ight have also bee n ach i eved.
•Glove b o x, un der-t ra y , an d ce nt re p ane l bo x h a ve
bee
n provide d for conve n ien t stora ge of sma ll
it
ems to improve ease of use.
•Switches an d di als ha ve be en en la rg ed fo r ea sie r
ope
ration .
•The system up tra y ha s bee n inst alle d as a qua l-
ity enhan cement. It has a power slide mechanism
for t
he cu p holder which is de sign ed for 500mL
plastic bo
ttles and p a p e r p a ckages. The system
up
tray is cap able of holdin g lug gage like bags
when
removing the slid ing cup ho lder .

AC601598AC

Floor consoleRear seat cup holder
Front seat cup holder Movable ashtray
INS
T R U MENT P ANE L
INT E RI OR52A-4
•The floor console for M/T veh i cle has bee n
in
st alled. The remo vable ashtray has been
in
st alled for convenie n t use.

SEAT
INTERIOR52A-5
SEAT
FRONT SEATM2520004000866
AC602124
Reclining adjustmentHeadrestraint
vertical adjustment
Slide adjustment
Reclining adjustment Headrestraint
vertical adjustment
Slide adjustment
Height adjustment
(Driver's side)
Convenience hook
(Passenger's side)
Seatback pocket
Cross frameRear-end
collision
protection
seat frame


AB

Height adjustment
(Driver's side)
RALLIART tag

Armrest (Driver's side)
The seat s of fer the following a d van t a ges.
•The seat s are de sig ned to be adjust able in the
reclin
ing a nd sliding direct ions.
•A large se e-throu gh type for t he hea drest r aint
has bee
n inst a lle d.
•Head re straint with vertical adjustment h a s be en
in
st alled.
•Seat h e igh t adju s tment fu nction has bee n intr o-
duced to the driver ’ s se at. Since this fu nction
raises and lowers
the seat cushion tog e ther with
the
seat back, the driver ’ s waist po sition in rela
-
tion to the seatba ck is always kept const a n t. This
enh
ance s riding comfort an d ach i eves o p timum
drivin
g positio n. Pump typ e sea t height ad just
-
ment lever h a s be en ad opted f o r con v en ient u s e.
•The p a sse nger's sea t has con v enient h ooks for
conve
n ient use.
•The driver ’ s an d p a ssenge r's seat ha s se atback
pocke
t for conve n ient use .
•The rear-end collision protection sea t stru cture
(backward
layout of seatb a ck frame and optimi
-
sation of hea drest r aint p o sition) has b een
ado
pted to improve safe ty du ring r ear-end colli
-
sion at lower vehicle sp eed. Th e cro s s frame has
bee
n inst alle d below the seat cush ion to reduce
the
fo rwa r d trave l dist a n ce of th e p a sse ngers d u r
-
ing front al collision and ha s improved safety .

SEAT
INTERIOR52A-6
•The seat structure is modified to dramatically
improve support function. Also, the RALLIART
special tag is attached to the front seat shoulder
to improve the marketability. -
sion-R>
RECARO SEAT
AC600741
Reclining adjustment
Slide adjustment
AD
The RECARO sea t has been adopte d for th e front
seat
as an option.

SEAT
INTERIOR52A-7
HEIGHT ADJUSTMENT
AC208192AB
Pump type height lever
Sector gear
Pinion gear
Frame
Slide rail
Front link Rear link
The frames are connected to
the slid e rail with th e
front link a
nd rear link. When the height lever is op er
-
ated, the pin i on g ear rot a te s and engag es with the
sector gea
r . The sector gear rot a tion operate s the
rea
r link. Th e rea r link rot a tion o p e r at es t h e f r on t link,
and the
n adjust s t he seat height.

SEAT
INTERIOR52A-8
REAR SEAT
M2520007000285
AC400593

Forward folding of seatback Headrestraint
vertical adjustment
Reclining
adjustment
Slide adjustment
Rear seat
AC
The ben ch seat h a s b een inst alled for the rea r seat .
This rear seat
s ha ve th e following feature s .
•Reclining adjustment and slid e adjustment h a ve
bee
n adop ted to imp r ove amen ity .
•A large see-throu gh type for t he hea d restraint
has bee
n inst a lle d.
•The headre s traint can be adjusted u p and down.
•Foldable seat back an d tu mble mechanism have
ena
bled wide variet y of seat a rrangement.

SEAT
INTERIOR52A-9
MULTI SEAT ARRANGE
M2520008000158
This vehicles offers a wide variety of seat arrange-
ment as usage.
Item
Normal
AC206055
Flat arrangement
AC206059
Rear sea t back folded f o rward
AC206063
Re ar s e at t u mb l e d2 pa sseng ers
AC206067

SEAT BELT
INTERIOR52A-10
SEAT BELT
M2520010000575
AC601600
Seat belt warning lampSeat belt warning lampSeat belt warning lamp
One-touch push bottom type
adjustable seat belt anchorThree-point seat belt
with ELR
Seat belt retractor
with pre-tensioner
and force limiter
Buckle integrated with seat
Centre seat belt
Seat belt with ELR/ALR
switching mechanism
Seat belt retractor
AC


•An ELR three-point se at belt s used.
•Seat be lt re tracto r has a pre-te nsioner a nd force
li
mi ter .
•One-touch pu sh bu tton st yle adjust able se at belt
anchors and seat-inco
r porated buckle s ensure
opt
imu m belt fit t ing a nd placement.
•A warning lamp is included o n the combinat ion
meter to e
n cou r age th e driver to faste n the seat
belt when t
he belt is not conne cted.

•Three -point se at belt with Au tomat i c L o cking
Retractor (ALR)/ELR change
over mechanism
(LH/RH), two-point seat be
lt (Centre ) have been
in
st alled.
