CIRCUIT DIAGRAMSB-73
CENTRALIZED RELAY (relay box in engine compartment)
Connector
No.NameConnector
No.Name
A-04XSpare connector (for front fog lamp relay)B-05XEngine speed detection connector
A-05XHorn relayB-06X-
A-06XCondenser fan relay (LO)B-07X-
A-07XCondenser fan relay (HI)B-08X-
A-08X-B-09XIgnition control relay
A-09XRadiator fan relayB-10X-
A-10XFront-ECUB-11XEngine control relay
A-11XFront-ECUB-12XA/C compressor relay
Front of vehicle
Front of
vehicle
A-04X A-05X A-06X A-07X A-08X
A-09XA-10X
A-11X
B-05XB-06X B-07X B-08X B-09X B-10X B-11X B-12X

CIRCUIT DIAGRAMS
H1J01X08AA
B-74
POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS
H1J01X08AB
B-75

CIRCUIT DIAGRAMS
H1J01X08BA
B-76
POWER DISTRIBUTION SYSTEM (CONTINUED)

CIRCUIT DIAGRAMS
H1J01X08BB
B-77

CIRCUIT DIAGRAMS
H1J01X08CA
B-78
POWER DISTRIBUTION SYSTEM (CONTINUED)

CIRCUIT DIAGRAMS
H1J02X06AA
B-79
STARTING SYSTEM

CIRCUIT DIAGRAMSB-80
STARTING SYSTEM (See P.B-79.)
OPERATION
When the ignition switch is turned to the ST position,
the starter contacts (magnet switch) turns ON and
the starter motor starts turning over.TROUBLESHOOTING HINTS
1. Starter motor does not turn over at all.
DCheck starter (coil).
DCheck battery terminals for proper contact.
2. Starter motor does not stop rotating.
DCheck starter (magnet switch).

CIRCUIT DIAGRAMSB-81
NOTES

CIRCUIT DIAGRAMS
H1J03X08AA
B-82
IGNITION SYSTEM
