MITSUBISHI LANCER EVOLUTION 2007 Service Repair Manual

WIRING HARNESS CONFIGURATION DIAGRAMS
D-27
D-13
D-08
D-09
D-10
D-12
D-28
9
10
Y
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-33
D-18 (1) Cigarette lighter
D-19 (1-B) Cigarette lighter
D-20 (2-B) Ashtray illumination lamp
D-21 (2-B) Cigarette lighter illumination lamp
D-22 (4) Oxygen sensor (Rear)
D-23 (1-B) Parking brake switch
D-26 (2-R) Seat belt pretensioner (RH)
D-27 (2) Fuel gauge unit (Sub)
D-28 (2-R) Seat belt pretensioner (LH)D-29 (1) Floor wiring harness (RH) and fuel wiring
harness combination
D-30 (8) Floor wiring harness (RH) and fuel wiring
harness combination
D-32 (3-B) G sensor (Longitudinal)
D-33 (3-B) G sensor (Lateral)
D-34 (6) Intercooler water spray switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
E
Driver’s side
Front door
Rear door
E-02
E-08E-07E-05E-04
E-12E-11E-10
B-34
DOOR
L.H. drive vehicles
E-02 (3) Remote controlled mirror (LH)
E-04 (2) Spare connector (LH)>
E-05 (6-GR) Power window motor (Front: LH)
E-07 (10) Power window main switchE-08 (6-B) Door lock actuator (Front: LH)
E-10 (6-GR) Power window motor (Rear: LH)
E-11 (8) Power window sub switch (Rear: LH)
E-12 (6-B) Door lock actuator (Rear: LH)
E-13 (3) Remote controlled mirror (RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Passenger’s side
Front door
Rear door
E-13E-16
E-21E-20E-19E-18
E-25E-24E-23
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-35
E-16 (3-B) Door lock key cylinder switch (RH)
E-18 (6-B) Door lock actuator (Front: RH)
E-19 (8) Power window sub switch (Passenger’s
side)
E-20 (6-GR) Power window motor (Front: RH)E-21 (2) Spare connector (RH)>
E-23 (6-B) Door lock actuator (Rear: RH)
E-24 (8) Power window sub switch (Rear: RH)
E-25 (6-GR) Power window motor (Rear: RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
E
Driver’s side
Front door
Rear door
E-07
E-21E-20
E-18
E-13
E-25E-24E-23
B-36
DOOR
R.H. drive vehicles
E-02 (3) Remote controlled mirror (LH)
E-04 (2) Spare connector (LH)>
E-05 (6-GR) Power window motor (Front: LH)
E-07 (10) Power window main switchE-08 (6-B) Door lock actuator (Front: LH)
E-10 (6-GR) Power window motor (Rear: LH)
E-11 (8) Power window sub switch (Rear: LH)
E-12 (6-B) Door lock actuator (Rear: LH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Passenger’s side
Front door
Rear door
E-17E-19E-02
E-08E-05E-04
E-12E-11E-10
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-37
E-13 (3) Remote controlled mirror (RH)
E-17 (3-B) Door lock key cylinder switch (LH)
E-18 (6-B) Door lock actuator (Front: RH)
E-19 (8) Power window sub switch (Passenger’s
side)
E-20 (6-GR) Power window motor (Front: RH)E-21 (2) Spare connector (RH)>
E-23 (6-B) Door lock actuator (Rear: RH)
E-24 (8) Power window sub switch (Rear: RH)
E-25 (6-GR) Power window motor (Rear: RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
F
F-01F-04F-05F-06F-08
F-19
F-16
F-28
F-27F-26F-25F-24F-23F-14
F-21
F-09
F-10
F-12
F-13
F-29
B-38
LUGGAGE COMPARTMENT
L.H. drive vehicles
F-01 (2) Spare connector
F-04 (2) Luggage compartment lamp
F-05 (2-B) High mounted stop lamp
F-06 (1-B) Defogger ( - )
F-08 (2) Spare connector
F-09 (6-B) Rear combination lamp (RH)
F-10 (1-B) Trunk lid latch switch
F-12 (2-GR) Licence plate lamp (RH)
F-13 (2-GR) Licence plate lamp (LH)
F-14 (2-GR) Floor wiring harness (LH) and bumper
wiring harness combinationF-16 (6-B) Rear combination lamp (LH)
F-19 (1) Defogger (+)
F-21 (2) Windshield washer motor
F-23 (2-B) Electric pump
F-24 (8-GR) Floor wiring harness (LH) and 4WD wiring
harness combination
F-25 (2-B) Direction valve (LH)
F-26 (2-B) Direction valve (RH)
F-27 (3-B) Proportioning valve (for ACD control)
F-28 (3-B) Proportioning valve (for AYC control)
F-29 (3-B) Pressure sensor

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
F
F-01F-04F-05F-08F-19
F-27F-26F-25F-24F-23F-14
F-21
F-09
F-10
F-12
F-13
F-06
F-16
F-29
F-28
B-39
LUGGAGE COMPARTMENT
R.H. drive vehicles
F-01 (2) Spare connector
F-04 (2) Luggage compartment lamp
F-05 (2-B) High mounted stop lamp
F-06 (1-B) Defogger ( - )
F-08 (2) Spare connector
F-09 (6-B) Rear combination lamp (RH)
F-10 (1) Trunk lid latch switch
F-12 (2-GR) Licence plate lamp (RH)
F-13 (2-GR) Licence plate lamp (LH)
F-14 (2-GR) Floor wiring harness (LH) and bumper
wiring harness combinationF-16 (6-B) Rear combination lamp (LH)
F-19 (1) Defogger (+)
F-21 (2) Windshield washer motor
F-23 (2-B) Electric pump
F-24 (8-GR) Floor wiring harness (LH) and 4WD wiring
harness combination
F-25 (2-B) Direction valve (LH)
F-26 (2-B) Direction valve (RH)
F-27 (3-B) Proportioning valve (for ACD control)
F-28 (3-B) Proportioning valve (for AYC control)
F-29 (3-B) Pressure sensor

SINGLE PART INSTALLATION POSITION -Relay
A
Electric
pump relay
Hydraulic unit
Fuel pump
relay 3
B
Electric pump relay
Fuel pump
relay 3
C
Ignition coil relay
Radiator fan relay
A/C compressor relay
Engine control relay
Condenser fan relay (HI)
Condenser fan relay (LO)
Horn relay
B-40
SINGLE PART INSTALLATION POSITION
RELAY
NameSymbolNameSymbol
A/C compressor relayCFuel pump relay 2D
Blower relayDFuel pump relay 3L.H. drive vehiclesA
Condenser fan relay (HI)CR.H. drive vehiclesB
Condenser fan relay (LO)CHorn relayC
Defogger relayDIgnition coil relay C
Electric pump relay

L.H. drive vehiclesAIntercooler water spray relayD
R.H. drive vehiclesBPower window relayD
Engine control relayCRadiator fan relayC
Fuel pump relay 1DRear fog lamp relayD
ABCD

SINGLE PART INSTALLATION POSITION -Relay/ECU
D
Intercooler water
spray relay
Fuel pump
relay 2
Rear fog
lamp relay
Fuel
pump relay 1
Power
window
relay
Defogger
relay
Blower relay
J/B
B-41
ECU
NameSymbolNameSymbol
4WD-ECU L.H. drive vehiclesLFront-ECUC
R.H. drive vehiclesKHeater control unit H
A/C-ECUHImmobilizer-ECUG
ABS-ECUL.H. drive vehiclesAPower window main switch
(incorporatingECU)
M
R.H. drive vehiclesB(incorporating ECU)
Column switch (incorporating column-ECU)FPower window motor
(incorporatingECU)
FrontN
ETACS-ECUE(incorporating ECU)RearO
Engine-ECUISRS-ECUJ
Fan controllerD
NOTE
*: also equipped at the right side.
ABC
D
EFGHI
JKL
MNO**

SINGLE PART INSTALLATION POSITION -ECU
A
ABS-ECU
B
ABS-ECU
C
Front-ECU
D
Fan controller
E
ETACS-
ECU
J/B
F
Column switch
column-ECU>
G
Ignition key cylinder
Immobilizer-
ECU
H
Heater control unit
A/C> or A/C-ECU

I
Engine-ECU
J
SRS-ECU
