HOW TO READ THE WIRING DIAGRAMS -Abbreviation SymbolsHOW TO READ THE WIRING DIAGRAMS -Abbreviation SymbolsA-11
Name of switches and
relaysOperation Abbreviation
symbols
Dimmer passing
switch
LOLow beams ON
switch
HIHigh beams ON
PASS
Door lock actuatorLOCKDoor lock
UNLOCKDoor unlock
Headlamp leveling
switch
1Low beam light axis drops by one step
switch
2Low beam light axis drops by two step
3Low beam light axis drops by three step
4Low beam light axis drops by four step
Ignition switchACCWhen turned to the ACC (ACCESSORY) or ON position, the power
circuit will start
IG1Even when at the ST (START) position, the power circuit will start
IG2When at the ST (START) position, the power circuit will not start
functioning
Intercooler water spray
switch
MANUALWater is sprayed while the switch is being pressed
switch
AUTOWater is sprayed automatically according to driving conditions
Lighting switchTAILPosition, tail, licence plate and illumination lamps ON
HEADHeadlamps ON
OthersOFFSwitched OFF
ONSwitched ON
Power window switchUPWindow closes
DOWNWindow opens
AUTO UPWindow is easily closed with one action
AUTO DOWNWindow is easily opened with one action
LOCKPrevents all switches other than the main switch from operating the
power windows
Remote controlled
mirrorswitch
LHL.H. mirror operates
mirror switch
RHR.H. mirror operates
Room lamp switchDOORRoom lamp ON when a door is open
Turn signal switchLHL.H. signal lamps ON
RHR.H. signal lamps ON

B-2
S
PWGEE
IGNITION SYSTEM
L.H. drive vehicles 82.......................
R.H. drive vehicles 83.......................
CHARGING SYSTEM 84...................
ENGINE CONTROL SYSTEM
L.H. drive vehicles 86.......................
R.H. drive vehicles 94.......................
COOLING SYSTEM 102...................
HEADLAMP
L.H. drive vehicles 103......................
R.H. drive vehicles 106......................
TAIL LAMP, POSITION LAMP, LICENCE
PLATE LAMP AND LIGHTING MONITOR
BUZZER
L.H. drive vehicles 110......................
R.H. drive vehicles 114......................
ROOM LAMP AND LUGGAGE
COMPARTMENT LAMP
L.H. drive vehicles 118......................
R.H. drive vehicles 121......................
REAR FOG LAMP
L.H. drive vehicles 124......................
R.H. drive vehicles 127......................
HEADLAMP LEVELING SYSTEM
L.H. drive vehicles 130......................
R.H. drive vehicles 132......................
TURN-SIGNAL LAMP AND HAZARD
WARNING LAMP
L.H. drive vehicles 134......................
R.H. drive vehicles 138......................
BACK-UP LAMP
L.H. drive vehicles 142......................
R.H. drive vehicles 143......................
STOP LAMP
L.H. drive vehicles 144......................
R.H. drive vehicles 145......................
HORN 146................................
METER AND GAUGE
L.H. drive vehicles 148......................
R.H. drive vehicles 152......................
FUEL WARNING LAMP 156...............
OIL PRESSURE WARNING LAMP 157.....
BRAKE WARNING LAMP 157.............
POWER WINDOWS
L.H. drive vehicles 158......................
R.H. drive vehicles 164......................
CENTRAL DOOR LOCKING SYSTEM
L.H. drive vehicles 170......................
R.H. drive vehicles 172......................
HEATER AND MANUAL AIR CONDITIONER
L.H. drive vehicles 174......................
R.H. drive vehicles 180......................
DEFOGGER 185..........................
WINDSHIELD WIPER AND WASHER
L.H. drive vehicles 186......................
R.H. drive vehicles 189......................
REMOTE CONTROLLED MIRROR
L.H. drive vehicles 192......................
R.H. drive vehicles 193......................
CLOCK 194..............................
CIGARETTE LIGHTER AND ASHTRAY
ILLUMINATION LAMP 195.................
AUDIO SYSTEM 196......................

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
A
A-01
A-37
A-36
A-48
A-40
A-31
A-28A-47A-46A-45
1
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-6
ENGINE COMPARTMENT
L.H. drive vehicles
A-01 (2-GR) Side turn signal lamp (RH)
A-02 (2-GR) Side turn signal lamp (LH)
A-03 (2-B) Wheel speed sensor (Front: LH)
A-04X (4) Spare connector (for front fog lamp relay)
A-05X (4) Horn relay
A-06X (4) Condenser fan relay (LO)
A-07X (4) Condenser fan relay (HI)
A-08X (4) No connectionA-09X (4) Radiator fan relay
A-10X (11) Front-ECU
A-11X (11) Front-ECU
A-12 (2-B) Front wiring harness (LH) and control
wiring harness combination
A-13 (8-B) Front wiring harness (LH) and control
wiring harness combination
A-16 (2-B) Headlamp (HI: LH)

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-13
A-43
A-39
A-44
A-21A-23A-16
14
B-7
A-21 (3-GR) Fan controller
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-43 (8-B) Front wiring harness (LH) and control
wiring harness combination
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
A
A-01
A-37
A-36
A-34
A-48
A-40
A-31
A-28
A-47A-46A-45
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
1
B-8
ENGINE COMPARTMENT
R.H. drive vehicles
A-01 (2-GR) Side turn signal lamp (RH)
A-02 (2-GR) Side turn signal lamp (LH)
A-03 (2-B) Wheel speed sensor (Front: LH)
A-04X (4) Spare connector (for front fog lamp relay)
A-05X (4) Horn relay
A-06X (4) Condenser fan relay (LO)
A-07X (4) Condenser fan relay (HI)
A-08X (4) No connectionA-09X (4) Radiator fan relay
A-10X (11) Front-ECU
A-11X (11) Front-ECU
A-12 (2-B) Front wiring harness (LH) and control
wiring harness combination
A-16 (2-B) Headlamp (HI: LH)
A-21 (3-GR) Fan controller

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-39
A-44
A-16
A-21A-23
14
B-9
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-34 (2) No connection
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
C-08
C-16
C-10
C-14
2
3
Y
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
C-44C-43
B-19
C-26 (22-B) J/C (4)
C-29 (22-B) J/C (5)
C-32 (16-B) A/C-ECU or heater control unit
C-36 (6-GR) Headlamp leveling switch
C-41 (22-Y) SRS-ECU
C-42 (1) Instrument panel wiring harness and
control wiring harness combination
C-43 (22-Y) 4WD-ECU
C-44 (26-Y) 4WD-ECU
C-45 (1) Instrument panel wiring harness and floor
wiring harness (LH) combination

WIRING HARNESS CONFIGURATION DIAGRAMS
C-22C-23C-34
C-01C-08C-02C-26
C-36
2
7
J/B
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-25
C-26 (22-B) J/C (4)
C-28 (13) J/C (5)
C-32 (12-B) A/C-ECU or heater control unit
C-34 (2) No connection
C-35 (3) Instrument panel wiring harness and
instrument panel wiring harness com-
bination
C-36 (6-GR) Headlamp leveling switchC-41 (22-Y) SRS-ECU
C-43 (22) 4WD-ECU
C-44 (26) 4WD-ECU
C-46 (1-GR) Control wiring harness and floor wiring
harness (LH) combination

CIRCUIT DIAGRAMSB-69
DEDICATED FUSE
Power supply
circuitNo.Rated
capacity (A)Identification
colourCircuit
Battery/alternator
(FusiblelinkNo6)
115BlueSpare connectors
(FusiblelinkNo.6)210RedHorn relay
320YellowEngine control relay and ignition control relay
410RedA/C compressor
515BlueABS-ECU, 4WD-ECU, high-mounted stop lamp and rear
combination lamp
630GreenCondenser fan motor
77.5BrownAlternator
810RedETACS-ECU
9---
1015BlueFuel pump
Front-ECU
(Headlamprelay:
1110RedHeadlamp
(Headlamp relay:
HI)1210RedHeadlamp
Front-ECU
(Headlamprelay:
1310RedFront combination lamp
(Headlamp relay:
LO)1410RedFront combination lamp
Front-ECU
(Tail lamp relay)157.5BrownHeater control unit or A/C-ECU, clock, combination
meter, fog lamp switch, hazard warning switch, radio,
rear combination lamp, headlamp leveling switch, front
combination lamp, cigarette lighter illumination lamp,
ashtray illumination lamp, ACD mode changeover switch
and inter cooler water splay switch
167.5BrownFront combination lamp, licence plate lamp and rear
combination lamp
Ignition switch
(ACC)1710RedClock
Battery/alternator
(Fusible link No. 6)1810RedEngine-ECU, ETACS-ECU, front-ECU and combination
meter
-19---
Fusible link No. 52120YellowIntercooler water splay
-22---
Ignition switch
(IG2)23---
-24---
Battery/alternator
(Fusible link No. 6)2530GreenCondenser fan motor

CIRCUIT DIAGRAMS
H1J08X20AA
B-103
HEADLAMP
L.H. drive vehicles
