SPARK PLUG
ENGINE ELECTRICAL16-3
SPARK PLUGM2163005000068
Iridium-tipped spark plugs are used.
AK604562AB
Iridium

NOTES

15-1
GROUP 15
INTAKE AND
EXHAUST
CONTENTS
AIR DUCT AND AIR CLEANER . . . .15-2
INTAKE MANIFOLD . . . . . . . . . . . . .15-3
EXHAUST MANIFOLD . . . . . . . . . . . .15-4
EXHAUST PIPE AND MUFFLER . . . .15-4

AIR DUCT AND AIR CLEANER
INTAKE AND EXHAUST15-2
AIR DUCT AND AIR CLEANERM2150004000656
A front air intake system that actively sucks cooling
air from the front through the top of the radiator has
been adopted in order to improve engine perfor
-
mance and reduce air intake noise.
CONSTRUCTION DIAGRAM
AC608342AB
Air cleaner assembly Mass airflow sensor
Air cleaner intake hose
Air cleaner intake duct

INTAKE MANIFOLD
INTAKE AND EXHAUST15-3
INTAKE MANIFOLDM2150005000239
The intake manifold is made of plastic for weight
reduction, and the surface roughness of the inner
walls of the ports has been improved to reduce
intake resistance.
AK502555
Intake manifold
AD
Air intake plenum
tank resonator

EXHAUST MANIFOLD
INTAKE AND EXHAUST15-4
EXHAUST MANIFOLDM2150006000566

A clamshell type exhaust manifold is used.

A SUS pipe type exhaust manifold is used.
EXHAUST PIPE AND MUFFLERM2150003000783
The exhaust system is composed of the front
exhaust pipe, center exhaust pipe, and main muffler,
and it has the following characteristics.•Fewer, more environmentally-friendly rubber
hangers to reduce vibration from exhaust system.
•Straighter exhaust pipe to reduce noise.
CONSTRUCTION DIAGRAM
AK603623

AB
AC608352Front exhaust pipeCenter exhaust pipeMain mufflerAB
Heated oxygen sensor (front)
Heated oxygen sensor (rear)
AC608488Front exhaust pipeCenter exhaust pipeMain mufflerAB
Heated oxygen
sensor (rear)
Heated oxygen sensor (3rd) Heated oxygen
sensor (front)

14-1
GROUP 14
ENGINE COOLING
CONTENTS
GENERAL INFORMATION . . . . . . . .14-2
WATER PASSAGE . . . . . . . . . . . . . .14-3
WATER PUMP . . . . . . . . . . . . . . . . . .14-3

GENERAL INFORMATION
ENGINE COOLING14-2
GENERAL INFORMATIONM2140000100780
The cooling system is a water-cooled pressurized,
forced circulation type which offers the following fea
-
tures.
•To stabilize engine coolant temperature, the ther-
mostat is located at the coolant inlet port from the
radiator.
•To improve engine cooling performance and save
weight, a plastic tank and aluminum radiator fins
are used.
SPECIFICATIONS
CONSTRUCTION DIAGRAM
ItemSpecification
Cooling methodWater-cooled pressurized, forced
circulation with electrical fan
RadiatorTy p ePressurized corrugate type
Performance kJ/h (kcal/h)222,480 (53,148)
Water pumpTy p eCentrifugal impeller
Drive methodDrive belt
ThermostatTy p eWax pellet with jiggle valve
Valve open temperature °C (°F)82 (180)
AC608448
Condenser fan motor Radiator assemblyRadiator upper hose
assembly
Radiator condenser
tank assembly Radiator fan motor
Cooling fan shroud
Radiator lower hose Transmission oil
cooler line hose
and tube assembly
AB

WATER PASSAGE
ENGINE COOLING14-3
WATER PASSAGEM2140004000172
NOTE: EGR: Exhaust Gas Recirculation
CVT: Continuously Variable Transmission
WAT E R P U M PM2140003000168
The water pump is the centrifugal, impeller type that
is installed in front of the cylinder block. It is driven by
the drive belt.
AK603624
Water pump
EGR
AB
Thermostat
Radiator Throttle body
CVT oil
coolerHeater
Water pump
EGR
Thermostat
Radiator Throttle body
CVT oil
cooler Heater
AK503034
Impeller
AD
ItemSpecifications
Discharge volume L/min185
Impeller diameter mm (in)62 (2.4)
Pulley outer diameter mm
(in)137 (5.4)
